This still left the difficulty that Hertz had failed to deflect the
cathode rays by applying an electric field. Thomson was suspicious about
this result, for he knew of two previous experiments in which the rays had
apparently been deflected by electric fields. These experiments, by
Crookes and Goldstein in 1879 and 1880 respectively, used slightly
different apparatus, but the principle was the same. Two cathodes were
placed in the vacuum tube, and wired so they could be switched on or off
independently. With only one cathode active, the rays passed in a straight
line as usual, but when the second was swiched on, the two streams of rays
curved away from each other. Crookes said this showed that the rays were
negatively charged particles, which repelled each other and diverged as
they moved away from the cathodes. This explanation was disproved by
Wiedemann and Ebert in 1891, who showed that the deflection is in fact due
to the intense electric field surrounding the other cathode, not the rays
emanating from it. Once again, Crookes had come to the right conclusion
for the wrong reasons!
This experiment also explained why cathode rays are always emitted
normally from the surface of the cathode. The electric field next to any
perfect conductor is always perpendicular to its surface, and it is this
field that accelerates the rays away from the cathode. Hence the rays are
initially accelerated at right angles from the cathode, then deflected
according by the shape of the cathode or any other electrodes nearby.
Thomson repeated Hertz's experiment to deflect the rays, and
obtained the same result - the electric field between the plates did not
appear to make any difference to the path of the rays, however large he
made the voltage between the plates. The solution to this problem came
from Lenard's old observaion that cathode rays increase the electrical
conductivity of any gas which they pass through. Thomson related this to
his own experiments on gases ionised by X-rays, and concluded that cathode
rays too must generate charged gas molecules. If an electric field is set
up in a gas containing ions, the negative ions will move towards the
positive plate and the positive ions to the negative plate. This will
continue until enough ions have built up near the plates to balance out
the electric field due to the plates themselves. Of course some ions will
be discharged by collisions with the plates, but this will not occur fast
enough to prevent a layer of charged gas building up near the plates.
Hence after a short time the field due to the plates will not be felt at
all by the cathode rays, and they will not show any deflection.
To avoid this problem, the obvious solution was to pump away the
gas so there are no ions to build up on the plates. Thomson was lucky in
that the quality of vacuum pumps had greatly improved since Hertz's
experiments, and he was easily able to test his idea. As he predicted,
the conductivity of the gas dropped rapidly as the air was pumped out, and
the rays were deflected.
(intermediate pressures?)
Now there there were no known properties of the rays that could not
be explained in terms of particles. All that was left for Thomson to do
was to measure the deflections of the rays and calculate the physical
parameters of the particles, namely their velocity, charge and mass. One
attempt to measure the mass:charge ratio of the particles had already been
made by Schuster in the late 1880s, using the magnetic deflection alone as
follows The acceleration of a particle of mass m and charge e travelling
at speed v perpendicular to a magnetic field of magnitude B is given by
Bev
a = ---
m
and directed perpendicular to the velocity and magnetic field. This causes
the rays to travel in a circle of radius r, given by
2
v Bev mv
--- = --- so that r = --
r m Be
Thus by measuring the field B and radius of curvature r, Schuster
found a value for mv/e. To find the mass:charge ratio m/e from this, he
needed a value for the velocity v, which was not so easily measured and
had to be estimated. He did this by wrongly assuming that the particles in
the rays were in thermal equilibrium with the surrounding air molecules.
As Thomson points out this cannot possibly be the case, since the rays
would not travel in straight lines across the tube if they were all
reflecting from air molecules. From this assumption Schuster unfortunately
arrived at the conclusion that the rays must be streams of ionised air
molecules. When Hertz discovered that the rays could pass through solid
aluminium, the particle theory seemed to be in ridicule, since a stream
gas molecules could not possibly pass through an airtight seal and hardly
be attenuated! Some suggested that the impact of molecules on one side of
the sheet somehow stimulated a new emission of rays on the far side,
though it is not clear how this stimulus could travel through the metal.
In 1894 Thomson had obtained his own estimate for the velocity of
the cathode rays, by measuring the time lag between switching on the rays,
and the appearence of the phosphorescence on the end of the tube. This
approach was also flawed, since the time lag is in fact caused by a
process occurring on the phosphorescent surface, not by time needed for
the rays to arrive there. Hence his value for the velocity was again far
too small and the mass:charge ratio was too large.
In his paper of October 1897, Thomson admits that these previous
measurements of the velocity were useless, and he describes two better
methods. Both methods use Schuster's experiment to measure mv/e using the
deflection in a magnetic field, as described above. The methods differ in
how they obtain from this the velocity v and mass:charge ratio m/e.
In the first method, he measures the electric current carried by
the rays. This quantity I is given by
I = ne
where n is the number of particles passing along the rays per second. He
then made use of another well-known property of cathode rays, that they
heat up any surface they strike. Assuming that the particles stop dead
when they strike the surface, Thomson reasoned that the kinetic energy
carried by the particles per second would be equal to the heat W given to
to the surface per second. That is,
1 2
W = - nmv
2
2
Thus, 2W mv
-- = ---
I e
Dividing this quantity by mv/e, which he already knew, would give
the velocity v and hence the mass:charge ratio. Thomson measured the rate
of heating, W, using a thermocouple, and the current I by collecting the
rays in a cylinder connected to an electrometer as in Perrin's experiment.
The resulting values of m/e and v are tabulated in his paper in the
Philosophical Magazine, October 1897. The values of m/e vary through a
factor of about three between the different readings, though they are all
less than a thousanth of the value for the hydrogen ion (proton). This
seemed a very surprising, and perhaps suspicious result, since no particle
was thought to exist with such a small mass:charge ratio.
