After working on a schematic for a while, you may find that you have placed a component in the wrong place. There may not be enough space to add part of the schematic, and in order to rectify the situation you need to move a few parts out of the way, or you may just want to tidy things up neatly. This is where the MOVE facility comes in useful. Click on the component you want to move, to bring up the "Object" menu, and select "Move". The status will change to "Moving", and the cursor will change to a flashing square. Move this square to the new location where you want to put the component, and click again. The part will now have been relocated, and any links automatically updated. If you place a component by accident, or want to remove one at a later date, you can do so using the "Delete" function on the object menu. This will remove the component and any links going to it. As your designs become more complex, you will soon find that the links start to look untidy. They are drawn as straight lines from the two terminals at each end, regardless of what might lie between them. This can cause the links to travel diagonally, which never looks neat, or even worse to cross another component. A simple solution is to define the path taken by the link using a series of nodes. Simply place a node at every corner along the route that you want the link to take, and link each to the next one along the line. INTEGRATED CIRCUITS One of the components available is the integrated circuit. This is different from the other components in that various sizes are avaiable. When you create an integrated cirsuit (ie. click on Add with IC selected at the top of the screen), you must select the size that you require from a menu. Most commonly used sizes are offered. When you click on an IC to bring up the "Object" menu, note that you must click at the TOP of the chip. This must be within the top three terminals on each side, and within the main body of the chip (ie. not on the terminals themselves). If you click elsewhere, it will not register as being a click on the IC. When you link to an IC, the sheer number of terminals makes it impossible to list all of them on a single menu. Therefore you must first select the range into which the terminal you want falls, and then select the exact number on a further menu. For example, to link to pin 4, first select "1-5" and then "4". FILING YOUR SCHEMATICS The File menu is available from both the object and main menus. It has the following items: New - Wipe your current design from memory and start with a fresh page. Open - Load a saved design from disc. Save - Save the current design to disc with the current filename. SaveAs - Save the current design to disc with a new filename. Export - Save the design in a format readable by other programs. Name - Sets the text description given at the top of the screen. MOS - Give you a * prompt with which to access the operating system. Exit - Quit the program and return to BASIC. Cancel - Oops again! The Open and SaveAs options both ask you for a filename and then load/save using that filename. The Save facility does not ask you for a filename, but instead uses the last filename used for this design. For example, if you load a file using Open and then want to save a modified version, you can use Save to avoid typing the filename for a second time. This facility is like that used by most modern PC software. NB: Filenames can be a maximum of 7 characters to ensure DFS compatibility. They are entered via a 7 character text box, as with the component labels (use cursor keys to move left/right; Delete won't work) The Export facility is used if you want to use your schematic in a document, or program other than Advanced CAD. You should note that the files made by Open/Save/SaveAs are data files that are of no use to any program other than Advanced CAD. In contrast, the files made by Export are graphics files, which are useful to other programs, but useless to Advanced CAD. For your information, these are mode 4 screendumps. The MOS facility is useful if you need to communicate with the operating system for any reason. This is necessary to switch filing systems (eg. from DFS to ADFS or vice versa), or to switch directories. NB: DO NOT use this to access to cassette filing system. The tape buffer is used by this program, and consequently any tape activity will crash the software. At the top of the screen there is a box which initially contains "<Untitled>". This box is intended as a 15 character description of what the current schematic is. You can edit the text that it contains using "Name" on the File menu. MEMORY LIMIT The memory limit in Advanced CAD is fairly generous: Maximum 127 components per schematic (includes nodes). Maximum 255 links between components. EXAMPLE FILES Two example files are supplied on this EUG disc - they can be accessed using "Open" on the file menu. They are as follows: Amp - An OpAmp set up as a non-inverting amplifier. PLL - A phase locked loop set up to act as a 410x frequency multiplier. FUTURE DEVELOPMENTS I have a number of ideas for improvements which I could make to Advamced CAD, and it is my intention to release a second version in a few months time. Features may include automatically making links look neat (avoid cutting components), and a larger list of components. If I can find the memory (and the time to do it!) I may even consider some simple PCB layout facilities. The main limiting factor in this version was the memory available, and so I will have to convert the entire program into machine code to make these ideas possible. One feature which is clearly lacking is an "Undo Link" function. Once you have linked two components, the only way to undo your link is to delete one of the components and then make a new one in its place. This can be a bit tedious with ICs, and so I recommend frequent saving. The reason for this ommision is simply lack of memory, and so this is my first priority in any future version. If you have any comments/ideas, please do pass them onto me, either via EUG or if you have the internet, to dominic.ford@cwcom.net Dominic Ford
