Shugart
A new Shugart controller is available in the U.S.A. which can emulate
Xebec S1410 and DTC 510B controllers, new price is around $79 from
companies advertising in BYTE - we just need someone to import them!!
Adaptec (model ACB4000 and ACB4070)
The ACB4000 is used by Acorn in their "official" systems with Rodime or
Seagate drives, it works in MFM only with 32 sectors per track. As the
ACB4000 is used by Acorn it is fully supported and will work with their
SuperForm (Winchester formatter program). Viglen use the ACB4070 which
supports MFM and RLL.
Advantages of Adaptec controller(s) are that they are used by Acorn, and
store the drive parameters on the drive. The Adaptec controllers have a
few opcodes not found on other controllers such as $2F - read drive
parameters. This is not a problem as these are only used during
formatting, and a different format program for a different controller
solves this.
Tame Micro Systems sell Adaptec controllers (ACB4000 = `155, ACB4070 =
`175 both +VAT)
DTC (models 510A/B and 520A/B)
33 sectors per track
Disk Technology Corp. One of the more profuse series of controllers - as
DTC have been in the market a long time their controllers have been used
with a lot of different machines.
The 510 series controllers support two Winchesters, while the 520 series
support two Winchesters and also two floppy disks (using an NEC765 FDC).
Basically the B versions of both are newer than the A versions, the
firmware in the A versions is stored on a 2732 and in the B versions a
2764 is used. The B version of the controllers have some extra opcodes,
but these are not needed for the BBC.
The importer/distributor of DTC controllers is not known so prices can't
be found, but I believe that the current new price for a DTC510A is around
`110+VAT.
Most hobbiests use the DTC controllers as they have been found on the
second hand market at affordable prices (circa `50-`60). With the BBC
micro the drive parameters are put into the controller's Eprom as the
default parameters.
Xebec (model S1410)
32 sectors per track
Another profuse controller - available for around `167+VAT new (Farnell).
Believed to be used in some third party Acorn compatible products for the
BBC, also used in various CP/M and IBM PC type machines.
Advantages of this controller are it's ability to support up to 65535
cylinders and 16 heads for very large drives, and it stores the drive
parameters on the drive.
Xebec S1410a
We have now used this controller and are very impressed. As standard it
comes with a 4k Eprom (2732) with software version 104788. This firmware
is usable but would need a new parameter table for different size drives -
the parameter table is at the end of the eprom -. The main disadvantage
is that the step rate of the drive is not stored in the parameter table
but the controller expects the drive step rate to be supplied in the
control block sent to it by ADFS which is always zero. The controller
interprets this as a 3 msec step rate which, for modern drives such as
Rodime 200 series, is slow! (in fact the DTC controllers default to 3 msec
on reset so they seek track zero at 3msec step rate when you press break).
Optional firmware release 104793
Just under 8k in 2764. The drive parameters are supplied at format time,
including the step rate, and are written to physical track zero. These
parameters are read from the drive at controller reset. The result is that
the drive seeks track zero at the step rate during formatting. Obviously
one cylinder of the winchester is lost to the parameters so the drive has
one cylinder less for the user - ie Rodime 202 has 321 cylinders but when
initialised has 320 available to the user.
Western Digital (models WD1001, WD1002 and WD1003)
32 sectors per track
The WD1001 controller series are believed to be somewhat non standard and
will not work with the Beeb.
The WD1002 is available in two very different versions:
-WX1 suffix, which is a half length plug in card for the IBM PC using SMD
devices (costs around `90) and not suitable for the BBC, and
-SHD suffix, conventional card. The WD1002-SHD will work with the BBC but
there are problems with storing the drive parameters (Solidisk use the
1002 with their Winchester system but you have to use their host adaptor
and their ADFS - I have not found their ADFS particularly reliable!)
The WD1003 is a newer controller, and apparently has a link to make it
Adaptec ACB4000 compatible, but we don't have any more info on it...
WD1002-SHD disadvantages: the drive parameters cannot be stored on the
drive and cannot be programmed into Eprom since the controller does not
have an Eprom (it uses custom chips instead of being microprocessor
based).
Solidisk have got around the drive parameters problem by storing them
inside the ADFS ROM, this means that the ADFS ROM has to be supplied by
Solidisk to match the drive. An Eprom could be written for the Beeb that
detected power up or pressing BREAK and then sent the parameters to the
controller if it was connected - this is being investigated.
You are probably best avoiding WD1001/1002 controllers for a BBC
application because of the problem storing the drive parameters.
NCL NDC 3011
NCL make a small controller that looks like it should work okay with the
BBC, it is sold by Tame MicroSystems for around `120.00, but as yet no one
has tried one.
Winchester disk systems For the BBC micro
To implement a winchester disk system on the BBC micro (model B or
B+) or Master you need the following:
1. A suitable drive (any size upto 4 Giga bytes is supported!!!).
2. Acorn's ADFS (Advanced Disk Filing System) version 1.30 for
the BBC B/B+, or version 1.50 for the Master (already fitted
in the Master 128).
3. A suitable controller card: DTC, Adaptec or Xebec recommended.
4. Host adaptor (detailed later).
5. Power supply - you cannot run this of the internal power
supply!!! (around +5V at 5A and +12V at 5A should suffice)
