Filename: DIAGNOS
Read OK: ✔
File size: 1472 bytes
Load address: FF1900
Exec address: FF8023
Duplicates

There is 1 duplicate copy of this file in the archive:

File contents
   10 REM INTERFACE DRIVER
   15 REM FISCHER COMPUTING <--> ACORN  BBC COMPUTER
   20 REM COPYRIGHT (C) ARTUR FISCHER FORSCHUNG 1984
   30 REM Use the following commands to control your FISCHERTECHNIK model with your Acorn Model B
   35 REM
   40 REM     * * COMMANDS * *
   45 REM
   50 REM - CALL M1,CW%
   55 REM   Rotates Motor #1 clockwise
   60 REM - CALL M1,CCW%
   65 REM   Rotates Motor #1 counter-clockwise
   70 REM - CALL M1,GO%
   75 REM   Switches device connected to M1 on
   80 REM - CALL M1,HALT%
   85 REM   Switches device connected to M1 off
   90 REM Instead of "M1" you may also use M2, M3 or M4
   95 REM - FNUSR (E1)
  100 REM   Returns a '0' or a '1' depending on the current state of the switch
  105 REM Instead of 'E1' you may also use any of the keys 'E2' to 'E8'
  110 REM - FNUSR (EX)
  115 REM   Returns a value depending on the current position of the potentiometer
  120 REM Instead of 'EX' you can also use 'EY' to obtain a value from potentiometer Y
  125 LET drr=&62
  130 LET up=&60
  135 LET til=&68
  140 LET tih=&69
  145 LET tic=&6B
  150 LET avar=&80
  155 LET mask=&81
  160 LET buff=&82
  165 LET asave=&84
  170 LET xsave=&85
  175 LET ysave=&86
  180 DIM M% 500
  185 FOR Z=0 TO 2 STEP 2
  190 P%=M%
  195[
  200 OPT Z
  205 \ * * OUTPUT DRIVER * *
  210 .init:lda #0:beq stvar:lda #3 :bne bout:lda #12:bne bout:lda #&30:bne bout:lda #&C0
  215 .bout :sta mask:lda avar:ora mask:sta avar:jsr check:jmp ok2
  220 .check :lda &0600:cmp #1:beq ok
  225 .err1:brk:]:PROCequb (&FF):PROCequs ("Use exactly one parameter"):PROCequb (0):[OPT Z
  230 .ok:lda&603: cmp #4:beq ok1
  235 .err2:brk:]:PROCequb(&FF):PROCequs("Use integer parameters only"):PROCequb(0):[OPT Z
  240 .ok1:lda &601:sta buff:lda &602:sta buff+1:ldy #0:lda (buff),Y
  245 .back:rts
  250 .ok2:and mask:sta mask: lda avar:eor mask
  255 .stvar:sta avar: tay
  260 .shout:jsr save:ldy #&3F:ldx #drr:jsr write:jsr load:ldx #8
  265 .loop: lda #&30:asl avar: bcc null:ora #4
  270 .null:jsr save:tay:ldx #up:jsr write:jsr load:ora #8:jsr save:tay:ldx #up
  275 jsr write:jsr load:dex:bne loop:jsr save:ldy #&31:ldx #up:jsr write:jsr load:sty avar:rts
  280 .E1:ldx #1:jmp test
  285 .E2:ldx #2:jmp test
  290 .E3:ldx #4:jmp test
  295 .E4:ldx #8:jmp test
  300 .E5:ldx #16:jmp test
  305 .E6:ldx #32:jmp test
  310 .E7:ldx #64:jmp test
  315 .E8:ldx #128
  320 .test:stx mask:lda #&32:jsr save:ldy asave:ldx #up:jsr write:jsr load:ora #8:jsr save:ldy asave:ldx #up:jsr write:jsr load:ldx #8
  325 .loop2:asl A:jsr save:ldx #up:jsr read:tya:and #&80:beq nul2:jsr load:ora #1:jmp nul3
  330 .nul2:jsr load
  335 .nul3:jsr save:ldy #&30:ldx #up:jsr write:jsr load:ldy #&38:ldx #up:jsr write:jsr load:dex:bne loop2:and mask:beq back1:lda #1
  340 .back1
  345 rts
  350 .EX:ldx #&A0:jmp poti
  355 .EY:ldx #&90
  360 .poti:sei:jsr save:ldy #&20:ldx #tic:jsr write:ldy #&FF:ldx #til:jsr write:ldy #&FF:ldx #tih:jsr write:ldy xsave
  365 ldx #up:jsr write:ldy #&38:ldx #up:jsr write:jsr load
  370 .tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:tya:ldx #200
  375 .delay:dex:bne delay:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:sbc ysave:bne tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:lda #&FF:sbc ysave:cli:rts
  380 .write:lda #&97:jsr &FFF4:clc:rts
  385 .read:lda #&96:jsr &FFF4:clc:rts
  390 .save:sta asave:stx xsave:sty ysave:rts
  395 .load:lda asave:ldx xsave:ldy ysave:rts
  400]
  405 NEXT Z
  410 LET M1=init+4
  415 LET M2=init+8
  420 LET M3=init+12
  425 LET M4=init+16
  430 LET INIT=init
  435 LET CW%=85
  440 LET CCW%=170
  445 LET GO%=85
  450 LET HALT%=255
  455 REM * * * END OF DRIVER * * *
  460 DEF FNUSR(A)=USR(A) AND &FF
  470 DEFPROCequb(num):?P%=num:P%=P%+1:ENDPROC
  480 DEFPROCequs(text$):$P%=text$:P%=P%+LEN text$:ENDPROC
  500 CALL INIT
  510 REM FISCHERTECHNIK COMPUTING
  520 REM
  530 REM DIAGNOSTIC PROGRAM
  540 REM
  541 REM COPYRIGHT (C) 1984
  542 REM BY ARTUR FISCHER FORSCHUNG
  545 REM
  550 @%=4:REM PRINTOUT FORMAT
  560 DIM STA$(4),STA%(4):REM MOTOR STATUS
  570 FOR I=1TO4
  580 STA%(I)=255
  590 NEXT I
  600 M=0
  610 MODE 6
  620 VDU 23,1,0;0;0;0;:REM CURSOR OFF
  630 PRINT "FISCHERTECHNIK"
  640 PRINT "COMPUTING"
  650 PRINT "DIAGNOSTIC PROGRAM"
  660 PRINT TAB(5,6);
  670 INPUT "DO YOU USE POTENTIOMETER X",X$
  680 PRINT TAB(5,7);
  690 INPUT "DO YOU USE POTENTIOMETER Y",Y$
  700 LET X=LEFT$(X$,1)="Y"
  710 LET Y=LEFT$(Y$,1)="Y"
  720 PRINT TAB(5,6);
  730 PRINT "E1  E2  E3  E4  E5  E6  E7  E8"
  740 PRINT TAB(15,4);"KEY STATUS"
  750 PRINT TAB(9,9);"POTENTIOMETER STATUS"
  760 PRINT TAB(14,13);"MOTOR STATUS"
  770 PRINT TAB(10,15);"M1    M2    M3    M4"
  780 PRINT TAB(2,19);"<C>  ALL MOTORS OFF  "
  790 PRINT "  <O>  CURRENT MOTOR OFF"
  800 PRINT "  <L>  CURRENT MOTOR LEFT"
  810 PRINT "  <R>  CURRENT MOTOR RIGHT"
  820 PRINT " <1-4> SELECT CURRENT MOTOR   <X> EXIT"
  830 GOSUB 970
  840 K=INKEY (1)
  860 IF K=ASC("C") THEN FOR I=1TO4:STA%(I)=HALT%:NEXT I:M=0:GOTO 920
  870 IF K=ASC("O") THEN LET STA%(M)=HALT%:GOTO 920
  880 IF K=ASC("L") THEN LET STA%(M)=CCW%:GOTO 920
  890 IF K=ASC("R") THEN LET STA%(M)=CW%:GOTO 920
  900 IF K=ASC("X") THEN GOTO 1170
  910 IF K>48 AND K<53 THEN LET M=K-48
  920 CALL M1,STA%(1)
  930 CALL M2,STA%(2)
  940 CALL M3,STA%(3)
  950 CALL M4,STA%(4)
  960 GOTO 830
  970 PRINT TAB(2,7);
  980 PRINT FNUSR(E1);
  990 PRINT FNUSR(E2);
 1000 PRINT FNUSR(E3);
 1010 PRINT FNUSR(E4);
 1020 PRINT FNUSR(E5);
 1030 PRINT FNUSR(E6);
 1040 PRINT FNUSR(E7);
 1050 PRINT FNUSR(E8);
 1060 FOR I=1TO4
 1070 IF STA%(I)=255 THEN LET STA$(I)="OFF   "
 1080 IF STA%(I)=85 THEN LET STA$(I)="CW    "
 1090 IF STA%(I)=170 THEN LET STA$(I)="CCW   "
 1100 NEXT I
 1110 PRINT TAB(10,17);STA$(1);STA$(2);STA$(3);STA$(4)
 1120 IF X THEN PRINT TAB(9,11);"EX : ";FNUSR(EX);" "
 1130 IF Y THEN PRINT TAB(21,11);"EY : ";FNUSR(EY);" "
 1140 PRINT TAB(25,20);"CURRENT MOTOR "
 1150 PRINT TAB(30,21);">";M;"<"
 1160 RETURN
 1170 REM QUIT TEST ROUTINE
 1180 REM SWITCH ON CURSOR
 1190 VDU 23,1,1;0;0;0;
 1200 REM STOP ALL MOTORS
 1210 CALL INIT
 1220 MODE 6
 1230 END
