LIBRARY/Basic/FindBadSec
This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.
Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.
| Tape/disk: | Home » Personal collection » Acorn ADFS disks » Electron » Utilities_1.ADF |
| Filename: | LIBRARY/Basic/FindBadSec |
| Read OK: | ✔ |
| File size: | 0E82 bytes |
| Load address: | FFFF1D00 |
| Exec address: | FFFF8023 |
Duplicates
There are 7 duplicate copies of this file in the archive:
- AEW website » acp_pres » acp_pres_3_5_discs_Electron-Adfs-E00_A-E00.adf » Library/BASIC/FindBadSec
- AEW website » database » database_3_5_discs_Classic-Card-And-Board-Games-2_A-CCB2.adf » LIBRARY/BASIC/FindBadSec
- Personal collection » Acorn ADFS disks » Electron » PRES_E00.ADF » Library/BASIC/FindBadSec
- Personal collection » Acorn ADFS disks » Electron » PRES_E00_backup.ADF » Library/Basic/FindBadSec
- Personal collection » Acorn ADFS disks » Electron » Utilities_1.ADF » LIBRARY/Basic/FindBadSec
- Personal collection » Acorn ADFS disks » Electron » Utilities_2.ADF » LIBRARY/Basic/FindBadSec
- Personal collection » Acorn ADFS disks » Greaseweazled » adfs_E00.adf » Library/BASIC/FindBadSec
- Personal collection » Acorn ADFS disks » Greaseweazled » dfs_box04_disk01b_adfs_welcome_disk_interleaved.adf » Library/BASIC/FindBadSec
File contents
10REM Program "FindBadSec". Finds the bad sectors on a floppy or Winnie.
20REM Looks for faulty sectors by reading the sectors via OSWORD &72.
30REM Asks for drive number, first & last sectors for search window.
40REM Searches a track at a time.
50
55ON ERROR GOTO 960
60MODE6
65or% = ?&1000: ?&1000 = 2
70SectorsPerTrack% = 16: Read = 8: OSWORD = &FFF1
80DIM FCB 16, Buffer &1005
90
100PRINT '' "F I N D B A D S E C T O R - V1.00"'
110
120REPEAT
130INPUT "Drive 0, 1, 4 or 5? " Drive$
140IF Drive$ = "" Drive$ = "0"
150UNTIL Drive$="0" OR Drive$ = "1" OR Drive$ = "4" OR Drive$ = "5"
160PRINT"Reading drive "Drive$
170Drive% = EVAL(Drive$)
180
190REPEAT
200
210 REPEAT
220
230 INPUT '"Which sector should I start at? Type a decimal number or a Hex number preceded by & " FirstSector$
240 IF FirstSector$ = "" THEN FirstSector$ = "0"
250 FirstSector% = EVAL(FirstSector$)
260 PRINT "Starting at sector "; FirstSector% " = &"; ~FirstSector%
270 INPUT '"Which sector should I stop after? " LastSector$
280 IF LastSector$ = "" THEN LastSector$ = "&4FF"
290 LastSector% = EVAL(LastSector$)
300 IF LastSector% < FirstSector% THEN PRINT "Last sector < First sector" ELSE PRINT "Stopping after sector "; LastSector%" = &"; ~LastSector%
310
320 UNTIL LastSector% >= FirstSector%
330
340PRINT '"Insert disc and press a key to start" : Junk% = GET
350OSCLI ("DIR:" + Drive$)
360 REM Reset drive else couldn't do an OSWORD &72 to drive 0 if drive 1 were selected
370REM Now check disc size. First set up FCB for OSWORD call.
380
390!(FCB + 1) = Buffer: ?(FCB + 10) = 0
400REM FCB is set up to read sector 0 in PROC ReadSector0
410PROC_ReadSector0
420TotalSectors% = ?(Buffer + 252) + (?(Buffer + 253))*&100 + (?(Buffer + 254))*&10000
430IF TotalSectors% <= LastSector% THEN PRINT'"This disc only contains &"; ~TotalSectors% " sectors"
440
450UNTIL TotalSectors% > LastSector%
460
480ThisSector% = FirstSector%
490NoOfBadSectors% = 0
500CLS
510PRINT ''''SPC(10) "BAD SECTORS" '" Sector Error code"'" (Dec) (Hex)"'
520VDU28,2,20,39,6
525VDU 23,1,0;0;0;0;
530
540REM Now the real work - read the sectors
550REPEAT
560 SectorsLeftOnTrack% = SectorsPerTrack% - (ThisSector% MOD SectorsPerTrack%)
570Temp% = LastSector% - ThisSector%
580IF Temp% < SectorsLeftOnTrack% THEN SectorsLeftOnTrack% = Temp% + 1
590?(FCB + 6) = (ThisSector% DIV &10000) AND &FF
600?(FCB + 7) = (ThisSector% DIV &100) AND &FF
610?(FCB + 8) = (ThisSector% ) AND &FF
620?(FCB + 9) = SectorsLeftOnTrack%
630
640vpos%=VPOS
650VDU26
660PRINTTAB(4,2)"READING TRACK" ThisSector% DIV 16
670VDU28,2,24,39,8
680PRINTTAB(0,vpos%);
690
700PROC_ReadSectors
710ThisSector% = ((ThisSector% + SectorsPerTrack%) DIV SectorsPerTrack%) * SectorsPerTrack%
720
730
740IF ?FCB = 0 THEN GOTO 900
750
760REM Error has occurred
770NoOfBadSectors% = NoOfBadSectors% + 1
780A% = &73: X% = Buffer AND &FF: Y% = (Buffer DIV &100) AND &FF
790CALL OSWORD
800ThisSector% = ?Buffer + (?(Buffer + 1))*&100 + ((?(Buffer + 2)) AND &1F)*&10000
810Error% = (?(Buffer + 3)) AND &7F
820PROC_ReadSector0
830
840PRINT ; ThisSector%;TAB(8) ~ ThisSector%;TAB(21) ~Error%
850IFNoOfBadSectors% MOD 15 = 0THEN PRINT"Continue?(Y/N) ";: go$ = GET$ :PRINTgo$ :ELSE go$ = "y"
860 ThisSector% = ThisSector% + 1: REM Start on next sector
870IF go$ <> "Y" AND go$ <> "y" THEN GOTO 950
880REM End of error part
890
900
910UNTIL ThisSector% > LastSector%
920
930IF NoOfBadSectors% = 0 PRINT''"Search done, no bad sectors found"
940IF NoOfBadSectors% = 1 PRINT''"Search done, 1 bad sector found"
950IF NoOfBadSectors% > 1 PRINT''"Search done, "; NoOfBadSectors% " bad sectors found"
960?&1000 = or%
970VDU26
975VDU 23,1,1;0;0;0;
980PRINTTAB(0,23)
990END
1000
1010
1020DEFPROC_ReadSector0
1030?FCB=0
1040!(FCB + 5) = Read
1050?(FCB + 9) = 1: REM Read 1 sector
1060PROC_ReadSectors
1070ENDPROC
1080
1090DEFPROC_ReadSectors
1100A% = &72
1110X% = FCB AND &FF: Y% = (FCB DIV &100) AND &FF
1120CALL OSWORD
1130ENDPROC
