ECGsim3

This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk:	Home » Personal collection » Acorn tapes » Electron_User » Electron_User_tape38b_acorn_eu_1992_september.wav
Filename:	ECGsim3
Read OK:	✔
File size:	2221 bytes
Load address:	FFFF1A00
Exec address:	FFFF8023

Duplicates

There are 5 duplicate copies of this file in the archive:

AEW website » bbc_pd » bbc_pd_5_25_discs_d-bbc140_D-BBC140.dsd » E.ECGSim3
AEW website » headfirst » headfirst_5_25_discs_HeadFirst-PD-Disk-011_D-HD011.ssd » ECGSim3
AEW website » mu » mu_5_25_discs_Micro_User_10_07_D-MU10_07.ssd » ECGSim3
AEW website » mu » mu_Micro_User_10_07_MU10-7_B.uef » ECGsim3
Personal collection » Acorn tapes » Electron_User » Electron_User_tape38a_acorn_eu_1992_september.wav » ECGsim3
Personal collection » Acorn tapes » Electron_User » Electron_User_tape38b_acorn_eu_1992_september.wav » ECGsim3

File contents

    0REM Wed,13 May 1992.21:22:34
   10DEFFNS:$(PAGE+6)=TIME$:="ECGSIM3"
   20A%=0:X%=255:T%=USR&FFF4:T%=(T%DIV&100)AND7:IF T%<3 PROCa:A$="*T.|MFORL%=0TOTOP-PAGE STEP4:L%!&E00=L%!PAGE:N.|MPAGE=&E00|M" ELSE A$="240V.23,7,0,1,0,0,0,0,0,0|M":PRINT"MASTER VERSION RUNNING ENSURE PAGE=&E00"
   30OSCLI"K.0DEL.0,30|MDEL.730,790|M"+A$+"O.|MV.6:RUN|M":OSCLI"FX138 0 128":END :REM Z%=DATA START B% IS NSR Q% IS NUMBER OF RHYTHMS
   40MODE0:VDU23;8202;0;0;0;0;:E%=0:F%=0:G%=0:H%=0:D%=0:R%=0:Z%=800:Q%=38:B%=860
   50ONERROR:MODE0:REPORT:PRINTERL:END
   60VDU19,1,2,0,0,0:FORL%=0TO1278STEP235:MOVEL%,370:DRAWL%,625:NEXT:VDU24,0;382;1278;608;:CLG:MOVE0,608:DRAW1278,608:MOVE0,382:DRAW1278,382
   70PROCc("ECG Simulation by C.J.Richardson.",1):PROCc("D - Dump.  ",4):PROCc("W - Window.",5):PROCc("P - Prompt.",6):PROCc("G - Grid   ",7)
   80REPEAT:PROCc("R - To run through rhythms.",15):PROCc("I - To interpret rhythms.  ",16):b$=GET$:IFb$="R":PROCt
   90UNTILb$="I"
  100I%=1:b$="1":PRINTTAB(0,9)SPC160
  110PROCc("SPACE - interpret rhythm.",3)
  120REPEATPROCc("Attempts :"+STR$F%,9):PROCc("Correct  :"+STR$G%,10):PRINTTAB(33,11);"Points   :";E%;" ":PROCe:PROCd:VDU28,0,31,79,0:UNTILFALSE
  130DEFPROCe
  140IFI%>0:U%=0:C%=Z%+(RND(Q%)-1)*30:RESTOREC%:READ A$,A2$:C%=C%+10:R%=0:D%=0:IFA$="N"A$="COARSE VF":A2$="VF":R%=1 ELSE IFA$="O"PROCb
  150RESTOREC%
  160VDU28,0,19,79,13
  170Y%=0
  180REPEAT:IFD%IFRND(50)=1PROCb
  190MOVE1264,Y%+500
  200READY%:IFY%=-1:RESTOREC%:READY%
  210IFY%>-5ANDY%<0PROCf
  220DRAW1271,Y%+500:READY%:IFY%>-5ANDY%<0PROCf
  230DRAW1278,Y%+500
  240CALLA%
  250K%=INKEY0
  260IFR%=1IFD%=0IFRND(50)=1C%=B%+(RND(Q%-2)-1)*30:RESTOREC%:READA$,A2$:C%=C%+10
  270IFK%=71PROCg
  280IFK%=68:VDU2,1,27,1,69,32,32:FORL%=1TOLENA$:VDU1,ASCMID$(A$,L%,1)EORVALb$:NEXT:VDU3:PROCg:OSCLI"GDUMP"
  290IFK%=87:OSCLI"WIN."
  300IFK%=80:T%=Z%+60:VDU28,0,30,79,21,14:REPEAT:RESTORET%:READW$,X$:PRINTW$;" OR ";X$:T%=T%+30:UNTILT%>Z%+Q%*30-30:PRINT"Press a key":L%=GET:VDU12,28,0,19,79,13,15:RESTOREC%
  310UNTILK%=32
  320ENDPROC
  330DEFPROCc(c$,N%):PRINTTAB(39-(LENc$/2),N%);c$:ENDPROC
  340DEFPROCd:VDU28,0,30,79,21:F%=F%+1:I%=0
  350INPUT"What is this rhythm? "a$:FORL%=1TOLENa$
  360IFASCMID$(a$,L%,1)>90a$=MID$(a$,1,L%-1)+CHR$(ASCMID$(a$,L%,1)-32)+MID$(a$,L%+1,LENa$)
  370NEXT
  380IFLENa$>LENA$/2IFINSTR(A$,a$):I%=1
  390IFA2$=a$:I%=2
  400IFA$=a$:I%=2
  410IFI%=0PROCc("WRONG!",3):U%=U%+1
  420IFI%>0G%=G%+1
  430IFI%=1PROCc("Partially correct. 1 point",4)
  440IFI%=2PROCc("Fully correct. 2 points",4)
  450E%=E%+I%
  460IFU%=4:IF I%=0PROCc("THATS ENOUGH! score reduced by 1!",4):E%=E%-1:I%=1:PROCc("It was "+A$+"/"+A2$,5)
  470PROCc("Press any key to continue",6):L%=GET:VDU12
  480ENDPROC
  490DEFPROCf
  500IFY%=-2:READO%,V%:Y%=RND(O%)+V%:RESTOREC%:ENDPROC
  510IFY%=-3:READO%,V%:Y%=RND(O%)+V%:ENDPROC
  520IFY%=-4:READW%:IFRND(W%)<>1 RESTOREC%:READY%:ENDPROC ELSE IFY%=-4 READY%:ENDPROC
  530ENDPROC
  540DEFPROCt:PROCc("SPACE - next rhythm.",3)
  550I%=0:C%=Z%+60:FORM%=3TOQ%:VDU28,0,31,79,0:RESTOREC%:READA$,A2$:PRINTTAB(0,9)SPC160:PROCc(A$,9):PROCc(A2$,10):C%=C%+10:PROCe:C%=C%+20:NEXT:VDU28,0,31,79,0
  560ENDPROC
  570DEFPROCg:IF K%=71 H%=H%EOR1:VDU28,0,31,79,0:PRINTTAB(42,7);:IFH%=0:PRINT"off." ELSE IFK%=71PRINT"on. "
  580VDU28,0,19,79,13:IFH%=0:ENDPROC
  590FORL%=0TO1278STEP47:MOVEL%,384:DRAWL%,606:NEXT:FORL%=2TO1280STEP235:MOVEL%,370:DRAWL%,625:NEXT:FORL%=412TO588STEP28:FORX%=0TO1278STEP10:MOVEX%+5,L%:DRAWX%+5,L%:NEXT,:ENDPROC
  600DEFPROCb:D%=D%+1
  610IFD%=1:C%=0
  620IFD%=2:C%=30
  630IFD%=3:C%=60
  640IFD%=4:C%=720
  650IFD%=5:C%=750
  660IFD%=6:C%=780
  670IFD%=7:C%=120
  680IFD%=8:C%=150
  690IFD%>8:C%=180
  700C%=C%+B%
  710RESTOREC%:READA$,A2$:C%=C%+10
  720ENDPROC
  730DEFPROCa:VDU21:FORL%=0TO2STEP2:P%=&C00:[:OPTL%
  740.A%
  750LDA#0:LDX#0:.m1:STA&5080,X:INX:CPX#8:BNEm1:LDX#0:.m2:STA&5300,X:INX:CPX#8:BNEm2:LDX#0:.m3:STA&5580,X:INX:CPX#8:BNEm3:LDX#0:.m4:STA&5800,X:INX:CPX#8:BNEm4:LDX#0:.m5:STA&5A80,X:INX:CPX#8:BNEm5:LDX#0:.m6:STA&5D00,X:INX:CPX#8:BNEm6
  760LDX#0:.m7:STA&5F80,X:INX:CPX#8:BNEm7
  770.S%:LDA&5088:STA&5080:INCS%+1:BNEnup:INCS%+2:.nup:INCS%+4:BNEnup2:INCS%+5:.nup2
  780LDAS%+2:CMP#&62:BNES%:LDA#&50:STAS%+2:STAS%+5:LDA#&88:STAS%+1:LDA#&80:STAS%+4:LDX#0:LDA#0:.m8:STA&61F8,X:INX:CPX#8:BNEm8
  790RTS:]:NEXT:ENDPROC
  800DATAN,N
  810DATA-2,130,-60
  820DATA-1
  830DATAO,O
  840DATA-1,-1
  850DATA-1
  860DATANORMAL SINUS RHYTHM,NSR
  870DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10
  880DATA-1
  890DATASINUS TACHYCARDIA,ST
  900DATA0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10
  910DATA-1
  920DATARAPID SINUS TACHYCARDIA,RAPID ST
  930DATA10,5,0,-10,50,-30,0,10,20,25
  940DATA-1
  950DATASINUS BRADYCARDIA,SINUS BRADY
  960DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
  970DATA-1
  980DATACOARSE VENTRICULAR FIBRILLATION,COARSE VF
  990DATA-2,130,-60
 1000DATA-1
 1010DATAFINE VENTRICULAR FIBRILLATION,FINE VF
 1020DATA-2,20,-10
 1030DATA-1
 1040DATAASYSTOLE,ASYSTOLE
 1050DATA0,0
 1060DATA-1
 1070DATANORMAL SINUS RHYTHM ATRIAL EXTRASYSTOLE,NSR+PACS
 1080DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,-4,5,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,0,0
 1090DATA-1
 1100DATANORMAL SINUS RHYTHM VENTRICULAR EXTRASYSTOLE,NSR+PVCS
 1110DATA0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,-4,5,40,-50,-60,-80,-75,0,10,15,10,0,-5,0,0,0,0,0,0,0,0,0
 1120DATA-1
 1130DATASUPRAVENTRICULAR TACHYCARDIA,SVT
 1140DATA10,-10,50,-30,0,10,20,25
 1150DATA-1
 1160DATAATRIAL FIBRILLATION,AF
 1170DATA-3,5,0,-3,5,0,-4,3,-5,0,-10,50,-30,0,0,10,20,25,20,10
 1180DATA-1
 1190DATAATRIAL FLUTTER 3:1,AFLUTT
 1200DATA12,10,0,12,10,0,12,10,0,-10,50,-30,0,0,10,20,25,20,10,0
 1210DATA-1
 1220DATAATRIAL FLUTTER 2:1,AFLUTT
 1230DATA12,10,0,12,10,0,-10,50,-30,0,0,10,20,25,20,0
 1240DATA-1
 1250DATAATRIAL FLUTTER 1:1,AFLUTT
 1260DATA12,10,0,-10,50,-30,0,0,10,20,25,20,10,0
 1270DATA-1
 1280DATAHIGH JUNCTIONAL,HIGH NODAL
 1290DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,-5,-10,-5,50,-30,0,0,10,20,25,20,10
 1300DATA-1
 1310DATAMID JUNCTIONAL,MID NODAL
 1320DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,-5,50,-30,0,0,10,20,25,20,10
 1330DATA-1
 1340DATALOW JUNCTIONAL,LOW NODAL
 1350DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,-5,50,-20,0,-10,5,10,15,10,0
 1360DATA-1
 1370DATA1ST DEGREE ATRIO VENTRICULAR BLOCK,1ST DEGREE
 1380DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,-10,50,-30,0,0,10,20,25,20,10
 1390DATA-1
 1400DATA2ND DEGREE TYPE 1 BLOCK WENKEBACH,2ND DEGREE TYPE 1
 1410DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,-10,50,-30,0,0,10,20,25,20,10
 1420DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,-1
 1430DATA2ND DEGREE TYPE 2 BLOCK,2ND DEGREE TYPE 2
 1440DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,-4,5,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5
 1450DATA-1
 1460DATABUNDLE BRANCH BLOCK,BBB
 1470DATA0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,40,-30,0,0,10,20,25,20,10,0
 1480DATA-1
 1490DATAMULTIFOCAL PREMATURE VENTRICULAR CONTRACTIONS,MULTIFOCAL PVCS
 1500DATA0,0,0,0,0,0,-4,2,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,-4,3
 1510DATA0,0,0,0,0,0,-3,50,0,-3,50,0,-3,50,-100,-50,-3,50,-50,-3,0,20,0,0,0,0,0,0,0,0,-1
 1520DATAR ON T ECTOPICS,R ON T
 1530DATA0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,-4,4,0,0,0,0,0,0,-10,50,-30,0,0,10,20,25,20,10,40,-50,-60,-80,-75,0,10,15,10,0,-5,0,0,0,0,0
 1540DATA-1
 1550DATAVENTRICULAR BIGEMINY,BIGEMINY
 1560DATA0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,40,-50,-60,-80,-75,0,10,15,10,0,-5,0,0,0,0,0,0,0,0,0
 1570DATA-1
 1580DATASLOW VENTRICULAR TACHYCARDIA,SLOW VT
 1590DATA40,-50,-60,-80,-75,0,10,15,10,0,-5,0,0,0,0,0
 1600DATA-1
 1610DATAFAST VENTRICULAR TACHYCARDIA,FAST VT
 1620DATA40,-50,-60,-80,-75,0,10,15,10,-5
 1630DATA-1
 1640DATARAPID VENTRICULAR TACHYCARDIA,RAPID VT
 1650DATA40,-50,-60,-80,-75,15,10,-5
 1660DATA-1
 1670DATAAGONAL,AGONAL
 1680DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,10,15,20,22,20,15,10,0
 1690DATA-10,-15,-20,-15,-10,0,10,12,10,0,-1
 1700DATAVENTRICULAR STANDSTILL,VENTRICULAR STANDSTILL
 1710DATA0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0
 1720DATA-1
 1730DATAIDIO VENTRICULAR,IDIOVENTRICULAR
 1740DATA0,0,0,0,-4,10,25,35,45,0,-50,-60,-80,-75,0,10,15,10,0,-5
 1750DATA-1
 1760DATANORMAL SINUS RHYTHM ST ELEVATION,NSR+ST ELEVATION
 1770DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,20,15,15,15,20,25,20,10
 1780DATA-1
 1790DATANORMAL SINUS RHYTHM ST DEPRESSION,NSR+ST DEPRESSION
 1800DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,-10,50,-25,-23,-21,-19,-5,10,20,25,20,10
 1810DATA-1
 1820DATASINUS ARRHYTHMIA,NSR
 1830DATA0,0,-4,2,0,0,0,0,0,0,0,0,5,10,5,0,-10,50,-30,0,0,10,20,25,20,10
 1840DATA-1
 1850DATANSR+SINUS ARREST,NSR+SINUS ARREST
 1860DATA0,0,5,10,5,0,-10,50,-30,0,0,10,20,25,20,10,0,0,0,0,0,0,0,0,0,0,-4,20,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0
 1870DATA-1
 1880DATAWANDERING ATRIAL PACEMAKER,WAP
 1890DATA0,0,0,0,0,0,0,0,0,0,0,0,0,5,-3,5,10,5,0,0,-10,50,-30,0,0,10,20,25,20,10
 1900DATA-1
 1910DATA3RD DEGREE ATRIO VENTRICULAR BLOCK,3RD DEGREE
 1920DATA0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,50,-30,0,0,10,20,25,20,10
 1930DATA0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,50,-30,0,0,10,20,25,20,10
 1940DATA0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,50,-30,0,0,10,20,25,20,10
 1950DATA10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,0,0,5,10,5,50,-30,0,0,10,20,25,20,10
 1960DATA5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,50,-30,0,0,10,20,25,20,10
 1970DATA0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,50,-30,0,0,10,20,25,20,10
 1980DATA0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,0,5,50,-30,0,0,10,20,25,20,10
 1990DATA0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,50,-30,5,0,10,20,25,20,10
 2000DATA0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,0,5,10,5,0,0,0,0,0,0,0,0,0,0,50,-30,0,5,10,20,25,20,10
 2010DATA0,-1
