THE BIG SQUEEZE (2)
In the last article, we discussed how text could be compressed by con-
verting it into four-bit nibbles of commonly-used characters, or codes
giving information about the following nibble:
Nibble value Meaning
------------ -------
0 Next nibble is a less commonly used character.
1 Next nibble is a token.
2 End of text.
3-15 The 13 most commonly used characters.
Here we'll be discussing 'tokens'. A 'token' is a representation of a
commonly used word, a bit like BASIC keywords, which are stored in
memory as one-byte tokens.
In our case, tokens occupy one nibble (four bits), meaning we can
include 16 commonly-used words like "this", "and", "that", and so on. If
"this" was token number zero, "and" token number one, and "that" token
two, then a sentence like "this and that" would be compacted as so:
byte 1 2 3
value &10 11 13
Program COMPRE2 is identical to COMPRES, but with the addition of the
machine code to 'tokenise' any commonly-used words found in the input
text, and expand them when the text is decompressed.
The tokens are contained in the table 'toktab'. Each token starts
with a number specifying the length of the token (e.g. 3 for "and")
followed by the token word itself. The words are READ in from line
1990, and their length is worked out automatically by EQUB (LEN word$)
in line 1210.
Matching words in the input string to the token words is handled by
'chktok'. It starts at the beginning of 'toktab' and compares the
current input character with the first character of the current word in
'toktab'. If it is the same, the next character from the input string
is checked with the next character in the table and so on. The token
length is put into the X register, and decremented each time a match is
found. So if X=0, all characters have been matched, and the word in the
input string has been successfully matched with the word in 'toktab'.
If, on the other hand, the first letter was matched but not the
next, the routine branches to 'notfnd'. The position of the next word in
'toktab' is calculated by adding the length of the current token,
'toklen', to the address in 'from' (which began as pointing to the start
of the token table). The token number, 'tokno', is incremented by one so
if a match is ever found, 'tokno' is written out to the the output
string, preceeded by a one nibble which signifies that the next nibble
is a token.
&FF marks the end of the token table, so if the end of 'toktab' is
reached with no match having been made, 'chktok' exits with the negative
flag set. The 'compress' routine then gets on with individually matching
common or less-common characters as before.
If you want, you can devise your own set of token words and put them
in line 1990. Note that there's no point in including two-letter words
comprising common letters - "of", "is", and so forth - because a token
flag followed by a token number takes up the same amount of memory as
two commonly-used letters, i.e. two nibbles.
The token expansion routine, 'outtok', works out the correct position
in 'toktab' from which to begin printing. The lengths of any tokens
preceeding the token in question are added to the address in 'from'.
Again, the token length is loading into X and used as a counter for how
many characters from the table should be sent to OSWRCH.
To see what effect this has on the compression factor, type in "she
sells sea shells on the sea shore", and compare the result with last
time: 54% is quite impressive. Having said that, the entire compression
program suffers from a limited token table, and only lower-case letters
are accepted. You could improve on this by assuming that the character
after a full stop and space is a capital letter. A few more spaces could
be squeezed out by assuming that all punctuation marks are followed by a
space. You also could assign a nibble value of 3 to mean that the
following two nibbles index into a 256-word token table.
Christopher Dewhurst, EUG #53
