10REM Advanced CAD - Main program
20REM (C) Dominic Ford 1998
30HIMEM=&4000:PROCinit:stop=FALSE:joy=(?&5210=1):mouse=(?&5211=1):REPEATIFmouse THENPROCmoucur ELSEPROCcursor
40PROCcompsel:IFFNfire THENPROCmenu
50UNTILstop:MODE7:OSCLI"FX15,1":END
60DEFFNfire:IFINKEY(-74)THEN=1ELSEIFjoy THENA%=&80:X%=0:IF(USR(&FFF4)AND(512+256))<>0THEN=1
70=0
80DEFPROCinit
90drawcomps=&5200:whatover=&5203:delete=&5206:getlink=&5209:pinbase=&520C:x=640:y=512:DIMmenu$(10),t%(15,1):!&47FC=0:?&4800=0:$&4801=" <Untitled> ":st$="":READc%:DIMcnam$(c%+1):FORc=1TOc%:READcnam$(c)
100cnam$(c)=cnam$(c)+STRING$(15-LEN(cnam$(c))," "):NEXT:cnam$(0)=STRING$(15," "):cnam$(c%+1)=STRING$(15," "):cp%=1:PROCdrawscr:ENDPROC
110DEFPROCdrawscr
120CLS:PRINT" Advanced CAD V1.0 by Dominic Ford 1998"
130GCOL0,1:MOVE0,992:DRAW1280,992:MOVE0,892:DRAW1280,892:MOVE0,884:DRAW1280,884
140GCOL0,1:CALLdrawcomps:PROCdraw(x,y):VDU23,1,0;0;0;0;
150PRINTTAB(0,1)cnam$(cp%-1):COLOUR129:COLOUR0:PRINTcnam$(cp%):COLOUR128:COLOUR1:PRINTcnam$(cp%+1);
160T=TIME:REPEATUNTIL(TIME>T+25)OR(NOT(INKEY(-58)ORINKEY(-42)))
170PRINTTAB(16,1)"Status: Ready ":PRINTTAB(16,3);:FORr=0TO14:PRINTCHR$?(&4801+r);:NEXT
180ENDPROC
190DEFPROCcompsel
200co%=cp%:IFINKEY(-58)ANDcp%<>1THENcp%=cp%-1
210IFINKEY(-42)ANDcp%<>c%THENcp%=cp%+1
220IFcp%<>co%THEN150
230ENDPROC
240DEFPROCput
250IF?&4800=160THENVDU7:ENDPROC
260?&4800=?&4800+1:c=&4800+16*?&4800:IFcp%=8THEN?(c+5)=FNpins
270?c=cp%-1:!(c+1)=x+65536*y:FORr=c+8TOc+15:?r=32:NEXT:PROCdraw(x,y)
280REPEATUNTILNOTINKEY(-74)
290ENDPROC
300DEFFNpins
310xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
320n%=10:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
330w%=3:menu$(0)="Pin":menu$(1)=" 6":menu$(2)=" 8":menu$(3)=" 14":menu$(4)=" 16":menu$(5)=" 18":menu$(6)=" 20":menu$(7)=" 24":menu$(8)=" 28":menu$(9)=" 32":menu$(10)=" 40":PROCdomenu
340=?(!pinbase+mo%)
350DEFPROCmenu
360PROCdraw(x,y):!&70=x:!&72=y:CALLwhatover
370n%=6:w%=6:IFx<1248-32*w%THENxm=(x AND &FFE0)ELSExm=1248-32*w%
380IFy>32*(n%+2)THENym=(y AND &FFE0)ELSEym=32*(n%+2)
390IF?&77=0THENPROCcadmenu:GOTO460
400menu$(0)="Object":menu$(1)="File "+CHR$255:menu$(2)="Move ":menu$(3)="Delete":menu$(4)="Label"+CHR$255:menu$(5)="Link "+CHR$255:menu$(6)="Cancel":PROCdomenu
410IFmo%=0THENPROCfile:GOTO460
420IFmo%=1THENPROCmove:GOTO460
430IFmo%=2THENIFFNsure("Delete Object")THENCALLdelete:GOTO460
440IFmo%=3THENPROClabel:GOTO460
450IFmo%=4THENPROClink
460PROCdrawscr
470ENDPROC
480DEFPROCcadmenu
490n%=3:menu$(0)="AdvCAD":menu$(1)="File "+CHR$255:menu$(2)="Add ":menu$(3)="Cancel":PROCdomenu
500IFmo%=0THENPROCfile:GOTO520
510IFmo%=1THENPROCput
520ENDPROC
530DEFPROCfile
540xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
550n%=9:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
560menu$(0)=" File ":menu$(1)="New ":menu$(2)="Open ":menu$(3)="Save ":menu$(4)="SaveAs":menu$(5)="Export":menu$(6)="Name "+CHR$255:menu$(7)="MOS(*)":menu$(8)="Exit ":menu$(9)="Cancel":PROCdomenu
570IFmo%=0THENIFFNsure("Clear Circuit")THEN!&47FC=0:?&4800=0:$&4801=" <Untitled> ":st$="":ENDPROC
580IFmo%=1THENPROCopen:ENDPROC
590IFmo%=2THENPROCsave(0):ENDPROC
600IFmo%=3THENPROCsave(1):ENDPROC
610IFmo%=4THENPROCexport:ENDPROC
620IFmo%=5THENPROCname:ENDPROC
630IFmo%=6THENPROCmos:ENDPROC
640IFmo%=7THENIFFNsure("Exit CAD")THENstop=TRUE:ENDPROC
650ENDPROC
660DEFPROCopen
670w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
680st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:OSCLI"LOAD "+st$
690ENDPROC
700DEFPROCsave(st)
710IFst=1ORst$=""THENw%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox:st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT
720min=&47FC-4*!&47FC:max=&4810+16*?&4800:OSCLI"SAVE "+st$+" "+STR$~min+" "+STR$~max
730ENDPROC
740DEFPROCexport
750w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
760st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:CLS:CALLdrawcomps:OSCLI"SAVE "+st$+" 5800 8000"
770ENDPROC
780DEFPROCdomenu
790xc=xm DIV32:yc=32-(ym DIV32):FORr=0TOn%:PRINTTAB(xc,yc+r)menu$(r);:NEXT
800GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4:MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
810MOVExm-4,ym-32:DRAWxm+32*w%+4,ym-32
820ad=&5800+&140*yc+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT
830GCOL3,1:mi%=0:REPEAT ad=&5940+&140*(yc+mi%)+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT:mo%=mi%
840REPEATUNTILNOT(INKEY(-58)ORINKEY(-42)ORINKEY(-73)ORINKEY(-105))
850IFjoy THENREPEATUNTILADVAL(2)<40000ANDADVAL(2)>24000
860REPEAT IFINKEY(-58)ORINKEY(-73)OR(joy ANDADVAL(2)>40000)THENmi%=mi%-1
870IFINKEY(-42)ORINKEY(-105)OR(joy ANDADVAL(2)<24000)THENmi%=mi%+1
880IFFNfire THENmi%=-5
890UNTILmi%<>mo%:IFmi%<>-5THENmi%=(mi%+n%)MODn%
900IFmi%<>-5THENFORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT
910UNTILmi%=-5
920ENDPROC
930DEFFNsure(s$)
940FORr=0TO3:PRINTTAB(14,14+r)SPC(13):NEXT:PRINTTAB(20-INT(0.5*LEN(s$)),14)s$;TAB(14,16)"Are you sure?";TAB(14,17)"(Y)es or (N)o":FORr=&69F0TO&6A57:?r=?r EOR255:NEXT
950GCOL0,1:MOVE448,448:DRAW864,448:DRAW864,576:DRAW448,576:DRAW448,448:MOVE440,440:DRAW872,440:DRAW872,584:DRAW440,584:DRAW440,440
960r=-5:REPEAT IFINKEY(-69)THENr=TRUE
970IFINKEY(-86)THENr=FALSE
980UNTILr<>-5:=r
990DEFPROCmos
1000CLS:PRINT"MOS Command Prompt"''"Enter blank line to return to CAD"'
1010OSCLI"FX15,1":REPEAT PRINT:INPUT"*"s$:OSCLIs$
1020UNTILs$=""
1030ENDPROC
1040DEFPROCname
1050w%=15:n%=0:ym=ym-256:xm=768:FORrx=0TO15:t%(rx,0)=?(&4801+rx):NEXT:PROCtextbox
1060FORrx=0TO15:?(&4801+rx)=t%(rx,0):NEXT
1070ENDPROC
1080DEFPROClabel
1090xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
1100n%=1:ym=ym-128:w%=4:FORrx=0TOw%-1:FORry=0TOn%:t%(rx,ry)=?(&4808+16*?&77+rx+4*ry):NEXT,:PROCtextbox
1110FORrx=0TO3:FORry=0TO1:?(&4808+16*?&77+rx+4*ry)=t%(rx,ry):NEXT,
1120ENDPROC
1130DEFPROCtextbox
1140xc=xm DIV32:yc=32-(ym DIV32):mx=0:my=0:GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4
1150MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
1160REPEAT FORry=0TOn%:PRINTTAB(xc,yc+ry);:FORrx=0TOw%-1:PRINTCHR$t%(rx,ry);:NEXT,:ad=&5800+8*(xc+mx)+&140*(yc+my):FORr=ad TOad+7:?r=?r EOR255:NEXT
1170st=0:REPEATUNTILINKEY(0)=-1:REPEAT IFINKEY(-58)ANDmy<>0THENmy=my-1:st=1
1180IFINKEY(-42)ANDmy<>n%THENmy=my+1:st=1
1190IFINKEY(-26)ANDmx<>0THENmx=mx-1:st=1
1200IFINKEY(-122)ANDmx<>(w%-1)THENmx=mx+1:st=1
1210IFINKEY(-74)THENst=2
1220IFst=0THENr=INKEY(0):IFr>31ANDr<127THENt%(mx,my)=r:st=1:IFmx<>(w%-1)THENmx=mx+1
1230UNTILst<>0:UNTILst=2
1240ENDPROC
1250DEFPROClink
1260co1%=?&77:xm=xm+32*(w%+1):ym=ym-160:PROCprelinks:IFmo%=n%-1THENENDPROC
1270cp1%=mo%:PROCdrawscr:PRINTTAB(16,1)"Status: Linking ":REPEATUNTILNOTFNfire
1280REPEAT PROCcursor:UNTILFNfire:!&70=x:!&72=y:CALLwhatover:IF?&77=0THENVDU7:REPEATUNTILNOTFNfire:GOTO1280
1290co2%=?&77:xm=(x AND &FFE0):ym=(y AND &FFE0):PROCprelinks
1300IFmo%=n%-1THENENDPROC
1310!&47FC=!&47FC+1:ad=&47FC-4*!&47FC:?ad=co1%:?(ad+1)=cp1%:?(ad+2)=co2%:?(ad+3)=mo%
1320ENDPROC
1330DEFPROCprelinks
1340?&70=?(&4800+16*?&77):CALLgetlink:n%=-1:w%=7:IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
1350IF?&73=10AND?&72=160THENPROCleads:GOTO1390
1360ad=?&72+256*?&73:REPEAT n%=n%+1:menu$(n%)="":FORr=ad TOad+6:menu$(n%)=menu$(n%)+CHR$?r:NEXT:ad=ad+8:UNTIL?(ad-1)=0:n%=n%+1:menu$(n%)="Cancel "
1370IFym<(n%+2)*32THENym=(n%+2)*32
1380PROCdomenu
1390ENDPROC
1400DEFPROCleads
1410ml%=?(&4805+16*?&77)*2:n%=(ml%DIV5)+2:menu$(0)="Lead No":menu$(1)="1 - 4 ":FORr=2TOn%-1
1420IF(5*(r-1))=ml%THENmenu$(r)=STR$(5*(r-1)):GOTO1440
1430IF(5*(r-1)+4)>=ml%THENmenu$(r)=STR$(5*(r-1))+" - "+STR$(ml%)ELSEmenu$(r)=STR$(5*(r-1))+" - "+STR$(5*r-1)
1440IFLEN(menu$(r))<7THENmenu$(r)=menu$(r)+STRING$(7-LEN(menu$(r))," ")
1450NEXT:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
1460PROCdomenu:IFmo%=n%-1THENENDPROC
1470IF(mo%=n%-1)AND(ml%MOD5)=0THENmo%=ml%-1:n%=999:ENDPROC
1480min=VAL(menu$(mo%+1)):max=VAL(MID$(menu$(mo%+1),5,3)):FORr=min TOmax:menu$(1+r-min)=STRING$(7-LEN(STR$r)," ")+STR$r:NEXT:n%=max-min+2:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
1490xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-96*(w%+1)
1500PROCdomenu:IFmo%=n%-1THENENDPROC
1510mo%=mo%+min:n%=999:ENDPROC
1520ENDPROC
1530DEFPROCmove
1540PROCdrawscr:PROCdraw(x,y):PRINTTAB(16,1)"Status: Moving ":REPEATUNTILNOTFNfire
1550!&70=x:!&72=y:CALLwhatover:ad=&4801+16*?&77:x=?ad+256*?(ad+1):y=?(ad+2)+256*?(ad+3):PROCbox(x,y)
1560REPEAT xold=x:yold=y:PROCmovecur:PROCbox(xold,yold):PROCbox(x,y):UNTILFNfire
1570!ad=x+65536*y
1580ENDPROC
1590DEFPROCbox(x,y)
1600GCOL3,1:MOVEx,y:DRAWx,y-64:DRAWx+64,y-64:DRAWx+64,y:DRAWx,y
1610ENDPROC
1620DEFPROCcursor
1630xold=x:yold=y:PROCmovecur
1640IF(x=xold)AND(y=yold)THENENDPROC
1650PROCdraw(xold,yold)
1660PROCdraw(x,y)
1670ENDPROC
1680DEFPROCmoucur
1690xold=x:yold=y:PROCmovemou
1700GOTO1640
1710DEFPROCmovemou
1720ENDPROC
1730DEFPROCdraw(x,y)
1740GCOL3,1:MOVEx,y-20:DRAWx,y+20:MOVEx-20,y:DRAWx+20,y
1750ENDPROC
1760DEFPROCmovecur
1770PROCcheckmove:IFx<0THENx=0 ELSEIFx>1280THENx=1280
1780IFy<0THENy=0 ELSEIFy>884THENy=884
1790ENDPROC
1800DEFPROCcheckmove
1810step=4:IFINKEY(-1)THENstep=40
1820IFINKEY(-98)OR(joy ANDADVAL(1)>40000)THENx=x-step
1830IFINKEY(-67)OR(joy ANDADVAL(1)<24000)THENx=x+step
1840IFINKEY(-73)OR(joy ANDADVAL(2)>40000)THENy=y+step
1850IFINKEY(-105)OR(joy ANDADVAL(2)<24000)THENy=y-step
1860IFNOTjoy THENENDPROC
1870IFADVAL(1)>55000THENx=x-step*9
1880IFADVAL(1)<10000THENx=x+step*9
1890IFADVAL(2)<10000THENy=y-step*9
1900IFADVAL(2)>55000THENy=y+step*9
1910ENDPROC
1920:
1930DATA20,"Capacitor","Capacitor(E)","Cell","Battery","Diode","Diode(Zener)","Ground","IC","Inductor","Logic AND","Logic NOT","Logic OR","Node","OpAmp","Resistor","Resistor(Var)"
1940DATA"Switch","Transistor(NPN)","Transistor(PNP)","Transistor(FET)"
