CIRCUIT DESIGN
~~~~~~~~~~~~~~
by Richard Dimond
Gus sent me a simple CAD program written for the BBC DFS by a friend of
his some time ago and asked me if I could make it work with ADFS at &1D00.
This needed several modifications to save memory and, altough my first
versions worked well, I felt that it was rather limited as there were only
eight preset components. While it was fairly easy to re-define these it
was not possible the add further ones because of the limited memory.
I then thought of using overlays to enable the data for the components to
be changed. This now works well and you can change the data without
losing the drawing that you have already done.
I have made up two DATA files (CD and CD2) which give you a choice of
thirteen components plus three items to modify components. These are all
shown by loading a circuit file named COMPS. This shows the filename and
the key to press for each one.
Should you BREAK out of the program, you must CHAIN it again from the
disc. This is because, after the DATA file is loaded, the value of top$
is altered with the added file and another file is added on top of this
and a BAD MODE error is given.
Thr function keys are used for the following -
f0: Toggle between Text and Graphics modes
f1: Shows the direction in which the component is drawn
f2: Turns the Erase facility ON/OFF
f3: Turns the Link facility ON/OFF
f4: Turns the Node facility ON/OFF
Shift-f5: Clears the screen
f6: LOADs a Circuit file
f7: SAVEs a Circuit file
f8: Dumps to printer
f9: LOADs the DATA files
When the program is first loaded, you will be asked to enter a DATA
filename. The main display screen will then be shown. This shows two
windows. The top window shows the f0 - f4 function key flags and other
messages. The lower is the drawing area.
The flags should show -
Text/Graphics : G
Erase : 0
Link : 0
Node : 0
The compoments represented in each file are shown below together with the
key to press.
File CD File CD2
A Diode Zener Diode
B Op. Amplifier Logic gate
C Transistor Arrow )
D FE Transistor Arrow ) see note below
E Resistor Arrow )
F Condenser Electrolytic Condenser
G Inductor Iron Cored Inductor
H Transformer Iron Cored Transformer
The arrow options C, D & E in file CD2 together with the components can
enable the distinction between NPN and PNP transistors also to set up
variable and preset codensers, resistors and potentiometers by drawing
them over the component.
To link components together, press f3. The link flag will turn to 1. The
link is drawn by the rubber-band drawing procedure. Move the cursor to
the start position and pres COPY. Then move to the end position and press
COPY again. When the linking is finished, press f3 again to turn the
facility off.
To insert a node, press f4. The node flag will turn to 1. Move to the
position required and press COPY and when completed, press f4 again to
return to the drawing mode.
Mistakes can be corrected by pressing F2 to turn on the erase facility and
re-draw the component, line or node at the same position.
The DATA files can be changed using f9 and entering the file name. The
drawing will remain so the all components can be drawn.
Drawings can be SAVEd using f7 and re-LOADed with f6.
New DATA files may be written in similar manner to those included. The
eight components must be allocated to lines 1110 to 1190 in steps 10 and
the first data is Z%, the number of commands, followed by the groups of
three values. The total length the file must be less than &500. This is
the length of the memory reserved between TOP and LOMEM.
WAY BACK IN THE GOOD OLD DAYS BEFORE I GOT INTO COMPUTERS I WAS AN
ELECTRONICS BUFF. LIKE MANY ELECTRONICS BUFFS I SAW COMPUTERS AS A MEANS
OF CONTROLLING MY ELECTRONICS PROJECTS AND DIDN'T REALLY BOTHER TO BUY ONE
SINCE I COULD GET ENOUGH CONTROL WITHOUT ONE.
I GOT MY FIRST COMPUTER, A JUPITER ACE BECAUSE I WANTED TO COMPILE A
DATABASE OF ELECTRONIC CIRCUITS WHICH I HAD A PLENTY BUT COULD NEVER FIND
WHEN I NEEDED ONE. OF COURSE I NEVER DID FIND THE RIGHT SOFTWARE, EVEN
WHEN IT WAS AVAILABLE IT WAS EXPENSIVE OR NOT SUITABLE FOR MY MACHINE.
WHEN I WAS GIVEN THIS PROGRAM RECENTLY MY HEART LITTERLY JUMPED. MY ELK
CAN USE DFS SO THAT WASN'T REALLY A PROBLEM BUT I PASSED IT TO RICHARD SO
THAT EVERYONE CAN USE IT.
NOW I MUST SAY THAT RICHARD HAS DONE US ALL PROUD, YET AGAIN. THE PROGRAM
I SENT HIM COULDN'T PRINTOUT AND HAD ONLY A FEW SYMBOLS. HIS VERSION IS
FIRST CLASS.
