� Print Electron Memory Map
!� by R.A.Dimond February 1993
(!� ***************************
2�
<�6
F&�6,1)"Memory Map (Pages 4 to &C)"
P �'"Screen or Printer? (S/P)"
Z���-82 ��-56
d3�-82 �3:�14 ��3:�15,2,1,27,1,54,1,27,1,116,1,1
n�0);�201;�68,�205);�187
x/�printct("ELECTRON MEMORY MAP - Pages 4-7")
�"�printct("Language Workspace")
�'�199;�13,�196);�194;�54,�196);�182
��print("  Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�5�print(" &400-&46B","Integer Variables @% to Z%")
�@�print(" &46C-&47F","Temporary floating point storage area")
�8�print(" &480-&4EC","Start of variable linked list")
�4�print(" &4F6/&4F7","Start of PROC linked list")
�2�print(" &4F8/&4F9","Start of FN linked list")
�!�print(" &4FA-&4FF","Unused")
�E�print(" &500-&5A3","FOR/NEXT loop parameters - up to 10 blocks")
�!�print("","of 15 bytes each")
�D�print(" &5A4-&5B7","REPEAT/UNTIL loop start address low bytes")

�print("","up to 20")

E�print(" &5B8-&5CB","REPEAT/UNTIL loop start address high bytes")

D�print(" &5CC-&5E5","GOSUB return address low bytes - up to 20")

":�print(" &5E6-&5FF","GOSUB return address high bytes")

,@�print(" &600-&6FF","String buffer or CALL parameter block")

6'�print(" &700-&7FF","Input buffer")

@'�200;�13,�205);�207;�54,�205);�188

J�

T�201;�68,�205);�187

^4�printct("ELECTRON MEMORY MAP - Page 8 to &83E")

h �printct("Sound Processing")

r'�199;�13,�196);�194;�54,�196);�182

|�print("  Address","Use")

�'�199;�13,�196);�197;�54,�196);�182

�#�print(" &800-&803","Not used")

�5�print(" &804-&807","Sound queue occupancy flag")

�,�print(" &808-&80B","Current amplitude")

�?�print(" &80C-&80F","Number of amplitude phases processed")

�/�print(" &810-&813","Absolute pitch value")

�;�print(" &814-&817","Number of pitch phases processed")

�5�print(" &818-&81B","Number of steps to process")

�#�print(" &81C-&81F","Duration")

�.�print(" &820-&823","Interval multiplier")

�@�print(" &824-&827","Envelope number/auto repeat parameter")

�<�print(" &828-&82B","Length of remaining note interval")

�.�print(" &82C-&82F","Sync hold parameter")
;�print(" &830-&833","Sound chip current pitch setting")
*�print(" &834-&837","Pitch deviation")
:�print(" &838","Number of channels required for sync")
&,�print(" &839","Current amplitude step")
0.�print(" &83A","Current target amplitude")
:9�print(" &83B","Number of channels on hold for sync")
D@�print(" &83C-&83F","Sound parameter calculation workspace")
N>�print(" &83D","Low order frequency parameter as sent to")
X �print("","sound generator")
b?�print(" &83E","High order frequency parameter as sent to")
l �print("","sound generator")
v'�200;�13,�205);�207;�54,�205);�188
��'''''''
��201;�68,�205);�187
�9�printct("ELECTRON MEMORY MAP - Page 8 (contd) - &C")
�#�printct("Main System Buffers")
�'�199;�13,�196);�194;�54,�196);�182
��print("  Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�1�print(" &840-&84F","Sound buffer channel 0")
�1�print(" &850-&85F","Sound buffer channel 1")
�1�print(" &860-&86F","Sound buffer channel 2")
�1�print(" &870-&87F","Sound buffer channel 3")
�)�print(" &880-&8BF","Printer buffer")
�*�print(" &8C0-&8FF","Envelopes 1 - 4")
+�print(" &900-&9BF","Envelopes 5 - 16")
@�print(" &9C0-&9FF","Speech buffer (unused on the Electron")
D�print(" &900-&9FF","CFS output buffer (RS423 output buffer if")
 '�print("","interface is connected")
*B�print(" &A00-&AFF","CFS input buffer (RS423 input buffer if")
4'�print("","interface is connected")
>*�print(" &B00-&BFF","Soft key buffer")
H;�print(" &C00-&CFF","User defined characters 224 -255")
R'�200;�13,�205);�207;�54,�205);�188
\
�'''''
f�3
p:�''"PLEASE PRESS <F> FOR NEXT FILE, <M> FOR MAIN MENU"
z�:� �="F" � �="M"
�� �="F" � �"$.MM5"
�� �="M" � �"$.MENU"
��
�3��printct(t$):�186;�68/2-�t$/2);t$;�69);�186:�
�<��print(a$,b$):�186;�2)a$;�14);�179;�16);b$;�69);�186:�
�
