24bBC ADDRESS BUS AND 8MB RAM DISK
By Robert Sprowson
THE limited expansion capabilities of an 8 bit addon on the 1MHz con-
nector on the BBC micro are easily overcome with some latches.
A fully decoded 24 bit address bus is presented here, giving up to 16
million unique locations! Half of this (8Mb) has been allocated as RAM
for a fast RAM disk.
It's up to the user's imagination to decide what input/output devices
are connected to the other 8 million locations - some suggestions are a
real time clock, your favourite ROM images, extra serial/parallel ports,
a TV card, etc...
Parts
THE slideshow of circuit diagrams in the Utilities Menu show how to
assemble the unit electrically. It requires the following parts:
3 x 74LS373 latches
3 x 74LS241 tristate buffers
4 x 74LS02
1 x 74LS00
1 x 4075BE
1 x 470uF capacitor
6 x 33nF capacitors
1 x 34 way IDC connector,and ribbon cable
2 x 3.3k resistor packs (8 resistors to a pack)
1 x stripboard,solder,and wires
In addition, the prototype RAM disk used 2 x 628128 SRAM chips (i.e.
256k in total), though any combination up to 8Mb can be added with a
little extra circuitry.
Benefits
* Single board decodes and cleans up all the 1MHz bus signals making
future projects easier to build
* Can be mounted internally to the case
* Use of a diode and 4.5v battery makes the RAM disk permanent
* No more grinding of precious floppy disks
* Fully featured RAM filing system already available
How To Build
1. Carefully consult the circuit diagram and manufacturers' data sheets
for the logic ICs, to arrive at a strip board layout.
2. Be sure to terminate the data bus with 3.3k resistors to 5v and 0v to
stop reflections over long cable lengths.
3. The decoupling capacitors (33nF) should be mounted as close to the
latch and tristate buffers as possible to stop noise on the power
lines.
4. It's arbitary which latches and tristate buffers you use for each of
the eight data lines from the BBC,but be consistent and label the
final board!
5. The RAM chips are best mounted on a small 'daughter' board as this
makes the wiring from the latches to the RAM address lines easier -
busses are very hard to implement on stripboard.
6. It's arbitary which order the RAM address lines are joined to the
main board since bytes will be read back from the same place they
were written, so it doesn't matter.
7. The board should be attached to a regulated supply capable of
supplying about 250mA.
Hints
* Below around 2.5v the contents of SRAM may become corrupted or lost.
* You can dramatically reduce the number of chips you need and (more
so) the wiring between the chips by use of 74ALS990 read/write
buffers.
* The board appears at &FC00, &FC01, &FC02 for the three address reg-
isters which is the 'test hardware' allocation in the 1MHz bus memory
map. Read/writes to the RAM occur at &FC03.
* The use of both latches and read back tristate buffers makes
?&FC00=?&FC00+1 in BASIC possible, or INC&FC00 in assembler which
have great speed increases over having to keep copies of the reg-
isters in the BBC's RAM
* Interrupt routines concerned with hardware on the 24bBC board must
preserve the current address by reading FC00/01/02,and restoring this
before exiting.
Happy soldering!
Robert Sprowson
IF you're not confident enough to build this piece of hardware yourself,
Robert Sprowson is offering a ready-made board service. Read his letter
from the Letters Menu for more details.
(The) Dave
