Filename: TOWER
Read OK: ✔
File size: 1561 bytes
Load address: FF2400
Exec address: FF8023
Duplicates

There is 1 duplicate copy of this file in the archive:

File contents
   10 REM INTERFACE DRIVER
   15 REM FISCHER COMPUTING <--> ACORN  BBC COMPUTER
   20 REM COPYRIGHT (C) ARTUR FISCHER FORSCHUNG 1984
   30 REM Use the following commands to control your FISCHERTECHNIK model with your Acorn Model B
   35 REM
   40 REM     * * COMMANDS * *
   45 REM
   50 REM - CALL M1,CW%
   55 REM   Rotates Motor #1 clockwise
   60 REM - CALL M1,CCW%
   65 REM   Rotates Motor #1 counter-clockwise
   70 REM - CALL M1,GO%
   75 REM   Switches device connected to M1 on
   80 REM - CALL M1,HALT%
   85 REM   Switches device connected to M1 off
   90 REM Instead of "M1" you may also use M2, M3 or M4
   95 REM - FNUSR (E1)
  100 REM   Returns a '0' or a '1' depending on the current state of the switch
  105 REM Instead of 'E1' you may also use any of the keys 'E2' to 'E8'
  110 REM - FNUSR (EX)
  115 REM   Returns a value depending on the current position of the potentiometer
  120 REM Instead of 'EX' you can also use 'EY' to obtain a value from potentiometer Y
  125 LET drr=&62
  130 LET up=&60
  135 LET til=&68
  140 LET tih=&69
  145 LET tic=&6B
  150 LET avar=&80
  155 LET mask=&81
  160 LET buff=&82
  165 LET asave=&84
  170 LET xsave=&85
  175 LET ysave=&86
  180 DIM M% 500
  185 FOR Z=0 TO 2 STEP 2
  190 P%=M%
  195[
  200 OPT Z
  205 \ * * OUTPUT DRIVER * *
  210 .init:lda #0:beq stvar:lda #3 :bne bout:lda #12:bne bout:lda #&30:bne bout:lda #&C0
  215 .bout :sta mask:lda avar:ora mask:sta avar:jsr check:jmp ok2
  220 .check :lda &0600:cmp #1:beq ok
  225 .err1:brk:]:PROCequb (&FF):PROCequs ("Use exactly one parameter"):PROCequb (0):[OPT Z
  230 .ok:lda&603: cmp #4:beq ok1
  235 .err2:brk:]:PROCequb(&FF):PROCequs("Use integer parameters only"):PROCequb(0):[OPT Z
  240 .ok1:lda &601:sta buff:lda &602:sta buff+1:ldy #0:lda (buff),Y
  245 .back:rts
  250 .ok2:and mask:sta mask: lda avar:eor mask
  255 .stvar:sta avar: tay
  260 .shout:jsr save:ldy #&3F:ldx #drr:jsr write:jsr load:ldx #8
  265 .loop: lda #&30:asl avar: bcc null:ora #4
  270 .null:jsr save:tay:ldx #up:jsr write:jsr load:ora #8:jsr save:tay:ldx #up
  275 jsr write:jsr load:dex:bne loop:jsr save:ldy #&31:ldx #up:jsr write:jsr load:sty avar:rts
  280 .E1:ldx #1:jmp test
  285 .E2:ldx #2:jmp test
  290 .E3:ldx #4:jmp test
  295 .E4:ldx #8:jmp test
  300 .E5:ldx #16:jmp test
  305 .E6:ldx #32:jmp test
  310 .E7:ldx #64:jmp test
  315 .E8:ldx #128
  320 .test:stx mask:lda #&32:jsr save:ldy asave:ldx #up:jsr write:jsr load:ora #8:jsr save:ldy asave:ldx #up:jsr write:jsr load:ldx #8
  325 .loop2:asl A:jsr save:ldx #up:jsr read:tya:and #&80:beq nul2:jsr load:ora #1:jmp nul3
  330 .nul2:jsr load
  335 .nul3:jsr save:ldy #&30:ldx #up:jsr write:jsr load:ldy #&38:ldx #up:jsr write:jsr load:dex:bne loop2:and mask:beq back1:lda #1
  340 .back1
  345 rts
  350 .EX:ldx #&A0:jmp poti
  355 .EY:ldx #&90
  360 .poti:sei:jsr save:ldy #&20:ldx #tic:jsr write:ldy #&FF:ldx #til:jsr write:ldy #&FF:ldx #tih:jsr write:ldy xsave
  365 ldx #up:jsr write:ldy #&38:ldx #up:jsr write:jsr load
  370 .tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:tya:ldx #200
  375 .delay:dex:bne delay:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:sbc ysave:bne tst:jsr save:ldx #til:jsr read:sty ysave:jsr load:sec:lda #&FF:sbc ysave:cli:rts
  380 .write:lda #&97:jsr &FFF4:clc:rts
  385 .read:lda #&96:jsr &FFF4:clc:rts
  390 .save:sta asave:stx xsave:sty ysave:rts
  395 .load:lda asave:ldx xsave:ldy ysave:rts
  400]
  405 NEXT Z
  410 LET M1=init+4
  415 LET M2=init+8
  420 LET M3=init+12
  425 LET M4=init+16
  430 LET INIT=init
  435 LET CW%=85
  440 LET CCW%=170
  445 LET GO%=85
  450 LET HALT%=255
  455 REM * * * END OF DRIVER * * *
  460 DEF FNUSR(A)=USR(A) AND &FF
  470 DEFPROCequb(num):?P%=num:P%=P%+1:ENDPROC
  480 DEFPROCequs(text$):$P%=text$:P%=P%+LEN text$:ENDPROC
  500 CALL INIT
  600 REM
  610 REM FISCHERTECHNIK COMPUTING
  620 REM
  630 REM TOWER OF HANOI
  640 REM
  650 REM COPYRIGHT (C) 1984
  660 REM BY ARTUR FISCHER FORSCHUNG
  670 REM
  690 REM ASSIGNMENTS FOR THE INTERFACE
  700 REM
  710 REM INPUT
  720 REM E1=BOTTOM
  730 REM E2=TOP
  740 REM EY=POSITION OF THE ANGLE
  750 REM
  760 REM OUTPUT
  770 REM M1=BODY
  780 REM M2=ARM
  790 REM M3=MAGNET
  800 REM
  810 REM FUNCTION DESCRIPTION :
  820 REM SORTING THE PILE OF DISCS
  830 REM FOLLOWING THE PUZZLE ORIGINATING FROM BUDDHIST TRADITION
  840 REM
  850 REM
 1000 DIM X(31),Y(31),Z(31),PILE(3)
 1010 REM POSITON OF PILES (ARBITRARY VALUES)
 1020 PROCsetpile
 1500 MODE6
 1510 PRINT "FISCHERTECHNIK"
 1520 PRINT "COMPUTING"
 1530 PRINT
 1540 PRINT "TOWER OF HANOI"
 1550 PRINT
 1600 INPUT "HOW MANY DISCS DOES THE TOWER HAVE ",N
 1610 IF N<1 THEN END
 1620 LET M=0
 1630 LET X(M)=N:LET Y(M)=1:LET Z(M)=3
 1640 GOSUB 1700
 1650 END
 1690 REM PSEUDORECURSIVE ROUTINE
 1700 IF X(M)=0 THEN RETURN
 1710 LET M=M+1
 1720 LET X(M)=X(M-1)-1
 1730 LET Y(M)=Y(M-1)
 1740 LET Z(M)=6-Y(M-1)-Z(M-1)
 1750 GOSUB 1700
 1760 LET M=M-1
 1770 PRINT "DISC ";X(M);"FROM PILE ";Y(M);" TO PILE ";Z(M)
 1780 GOSUB 2000:REM ROBOT ROUTINE
 1790 LET M=M+1
 1800 LET X(M)=X(M-1)-1
 1810 LET Y(M)=6-Y(M-1)-Z(M-1)
 1820 LET Z(M)=Z(M-1)
 1830 GOSUB 1700
 1840 LET M=M-1
 1850 RETURN
 2000 REM ROBOT ROUTINE
 2010 LET AIM=PILE(Y(M))
 2020 GOSUB 2200:REM TURN BODY
 2030 GOSUB 2310:REM LOWER ARM
 2040 CALL M1,GO%:REM SWITCH MAGNET ON
 2050 GOSUB 2350:REM LIFT ARM
 2060 LET AIM=PILE(Z(M))
 2070 GOSUB 2200:REM TURN BODY
 2080 GOSUB 2310:REM LOWER ARM
 2090 GOSUB 2120:REM MAGNET OFF
 2100 GOSUB 2350:REM LIFT ARM
 2110 RETURN
 2120 REM MAGNET-OFF ROUTINE
 2130 CALL M1,CCW%:REM REVERSE MAGNET CURRENT FOR DEMAGETIZATION
 2140 CALL M1,HALT%:REM MAGNET OFF
 2150 RETURN
 2200 REM POSITIONAL CONTROL ROUTINE
 2210 LET D=FNUSR(EY)-AIM
 2220 IF D>0 THEN CALL M3,CW%
 2230 IF D<0 THEN CALL M3,CCW%
 2240 IF D=0 THEN RETURN
 2250 LET D=ABS(D)
 2260 IF D>5 THEN GOTO 2210
 2270 FOR I=0 TO D
 2280 NEXT I
 2290 CALL M3,HALT%
 2300 GOTO 2210
 2310 CALL M2,CCW%:REM LOWER ARM
 2320 IF FNUSR(E1)=0 THEN GOTO 2310
 2330 CALL M2,HALT%
 2340 RETURN
 2350 CALL M2,CW%:REM LIFT ARM
 2360 IF FNUSR(E2)=0 THEN GOTO 2360
 2370 CALL M2,HALT%
 2380 RETURN
 2390 DEF PROCsetpile:OK=FALSE
 2395 FOR n=1 TO 3:OK=FALSE
 2400 REPEAT
 2410 IF FNUSR(E4)=1 THEN CALL M3,CW%:OK=TRUE
 2420 IF FNUSR(E5)=1 THEN CALL M3,CCW%:OK=TRUE
 2430 UNTIL OK
 2440 REPEAT:UNTIL FNUSR(E3)=1
 2450 CALL M3,HALT%
 2460 PILE(n)=FNUSR(EY)
 2470 NEXT n:ENDPROC
