File contents
The Utility Label program will ask you various questions that you should
answer as below:
Use select file (N,Y)? (type N if this applies to the whole
database or Y is to select file)
Screen or Printer (S,P)? P (RETURN)
Label height (lines)? 6
Lines between each label? 3
Width of label? 25
Characters between each label? 6
Number of labels across the page? 3
Line 1? )
Line 2? ) enter the field name or names from which information
Line 3? ) has to be extracted. Where there is more than one field
Line 4? ) name required this must be separated by commas
Line 5? ) eg Name, Address
Line 6? )
(press RETURN)
26 Using Viewstore convert
1. 'Convert' converts an existing database, or a SELECTED subset into a new
file. To add a space to an existing file use:
Use Select file (N,Y)? N
Field 1? *
:
Filename? (a new name)
Record size: +100
Then use LOAD (new name) (old name) to use the new database, with the old
format file, or rename the (new name) to (old name) (backing up the old file
first!).
2 Printing out some fields or a file is done with the REPORT Utility - see
the manual for details.
3 Furthermore, if you want to pass an alphabetically sorted database to
View it is done by SELECTing the fields you want, sorting on the appropriate
field, then using CONVERT, this time with a select file, to produce a new
database in sorted order, which can be passed to View.
27 This applies to View and Viewstore (PDG)
Although View has only two highlight codes these can be redefined using HT
code in "Edit command" (Shift F8) to make use of other features available on
the printer. The actual values associated with the highlight codes can vary
from 128 to 148.
If you want to access extended characters you use HT 2 130. This is entered
in your View document using Shift F8 (Edit command). However, you should
enter the appropriate codes in response to the printer initialisation
question in the PDG.
For example: In View to change font you would enter *-- (means Highlight
2,1,1). View then sends to the Printer Driver 130 128 128 codes to switch
to the new font.
With Viewstore you would need to put these codes in REPORT FORMAT file 3 1
1. Viewstore sends to the Printer Driver 127 + number (130 128 128).
28 Viewstore import procedure - Viewstore to Viewstore
CHAIN "IMPORT"
Question Input
Source file D.(filename)
Destination file :(drive number).D.(new filename)
Position in file where data starts 0>RETURN<
Record Separator 13 (carriage return in Viewstore)
Appears before first record N
Appears before last record Y
Field Separator 9 (tab character in Viewstore)
Before first character N
After last character N
End of file marker 0
Is data reserved N (it is in database)
Trailing character to skip N
Record size <RETURN>
-----------------------------------------------------------------------------
Printing Labels from a View Macro File
-----------------------------------------------------------------------------
The following BASIC listing can be used to print labels from a View file in
macro format. The program allows the user to select which fields from the
macro shoul be printed, the order in which they are to be printed and the
number of lines between each label.
Before running this program critical points that should be noted are:
1 The printer should be set up and connected to the computer following the
instructions in the relevant user guides.
2 The starting position on the printer should be checked and adjusted on a
short run first to avoid wastage of labels.
3 The View file should be carefully checked to ensure that all addresses
have the same number of fields, adding commas where necessary.
10 REM label print utility
20 REM Acorn Computers Ltd (c) 1989
30 ON ERROR VDU3 : CLOSE# 0 : REPORT : PRINT "At line " ERL:END
40 INPUT"Fields in MACRO "fields%
50 INPUT"Lines to print out "lines%
60 INPUT"Lines of gap between labels "gap%
70 DIM out% (lines%)
80 PRINT "enter the position of the entries in the MACRO" :"PRINT "in the order you
want them printed"
90 FOR z% =1 TO lines%:PRINT "Lines "z%"is entry? ";
100 INPUT" "out% (z%) :NEXT
110 DIM a$ (fields%)
120 INPUT"Enter name of file to be printed"mg$
130 INPUT "Output of Printer Y/N" q$
140 IF INSTR ("Yy",q$) :print=TRUE ELSE print=FALSE
150 a%=OPENIN (mg$)
160 IF print:VDU2
170 PROCnext
180 FOR z% = 1 TO fields%
190 as (z%) = FNstring
200 NEXT
210 FOR z% = 1 TO lines%
220 PRINT STRING(gap%, CHR$13)
230 UNTIL EOF#a%
240 DEF PROCnext
250 REPEAT d%=BGET#a%:UNTILd%=&80:PTR#a%=PTR#a%+2
260 ENDPROC
270 DEF FNstring
280 LOCAL c%
290 r$=" ":REPEAT
300 c%=BGET#a%
310 IF c%=ASC" , " OR c%=13:UNTIL1: =r$
320 r$=r$+CHR$ (c%) :UNTIL0
