FURTHER NOTES ON ROMBOX+ PROBLEMS ~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~ Manythanks for your suggestions regarding my problems. The original Rombox had 8 ROM sockets but no cartidge slots and this is the one which you repaired. My Rombox is a later type with 4 ROM sockets and 2 cartridge slots. Since I wrote my appeal for help, I have had another attempt and it would seem that I have now cured the fault. This seems to have been due to the contacts of the edge connector on the Rombox. I had tried to make them make better contact by poking them together with the point of a scriber but this was not very satisfactory and did not completely cure the fault. I have now used a pair of pointed tweezers so that each pair of contacts could be squeezed together and so make better contact. I suppose that it would be better to replace the edge connector but as you say the plastic case is stuck together and I am reluctant to open it up. Regarding the cleaning of the edge connector on the Elk. I have got the Cleaning Pad (Maplin FM81C) for cleaning edge connectors. This is an impregnated tissue in a sachet. I found that this easier to use than a pencil eraser as you can fold it round a piece of stiff card for cleaning the top side without having to dismantle the Elk. As I had already used a pencil eraser, I cannot say whether this made any further improvement at present. Richard Dimond, 5 Briary Court, SIDCUP, Kent, DA14 6HZ. Tel 0181 302 2395 ************************************************************************** ONE FURTHER POINT ON THE PROBLEM OF EDGE CONNECTORS. I HAD A PLUS 2 AND AN ORIGINAL JAFA MODE 7 BOARD AS WELL AS MY PLUS 1 AND 3. I HAD A LOT OF EDGE CONNECTOR PROBLEMS. I REMOVED THE CONNECTOR FROM THE PLUS 2 AND USING SHORT LENGTHS OF WIRE SOLDIERED THE PLUS 2 AND THE MODE 7 BOARD TOGETHER. I DON'T ADVISE THIS. IT DID WORK AFTER A WHILE, I NEEDED TO DO A LOT OF RESOLDERING AND THE FINISHED RESULT IS NEVER GOING TO BE AS GOOD. ALSO IT IS EXTREEMLY DIFFICULT TO REMOVE THE SOLDER FROM THE GOLD CONTACTS OF THE PLUS 2.
00000000 0d 46 55 52 54 48 45 52 20 4e 4f 54 45 53 20 4f |.FURTHER NOTES O| 00000010 4e 20 52 4f 4d 42 4f 58 2b 20 50 52 4f 42 4c 45 |N ROMBOX+ PROBLE| 00000020 4d 53 0d 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e |MS.~~~~~~~~~~~~~| 00000030 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e 7e |~~~~~~~~~~~~~~~~| 00000040 7e 7e 7e 7e 0d 0d 4d 61 6e 79 1a 74 68 61 6e 6b |~~~~..Many.thank| 00000050 73 1a 20 66 6f 72 1a 20 79 6f 75 72 20 73 75 67 |s. for. your sug| 00000060 67 65 73 74 69 6f 6e 73 20 72 65 67 61 72 64 69 |gestions regardi| 00000070 6e 67 20 6d 79 20 70 72 6f 62 6c 65 6d 73 2e 1a |ng my problems..| 00000080 20 20 54 68 65 1a 20 6f 72 69 67 69 6e 61 6c 0d | The. original.| 00000090 52 6f 6d 62 6f 78 20 68 61 64 20 38 20 52 4f 4d |Rombox had 8 ROM| 000000a0 20 73 6f 63 6b 65 74 73 1a 20 62 75 74 1a 20 6e | sockets. but. n| 000000b0 6f 20 63 61 72 74 69 64 67 65 20 73 6c 6f 74 73 |o cartidge slots| 000000c0 20 61 6e 64 20 74 68 69 73 20 69 73 20 74 68 65 | and this is the| 000000d0 20 6f 6e 65 20 77 68 69 63 68 0d 79 6f 75 1a 20 | one which.you. | 000000e0 72 65 70 61 69 72 65 64 2e 1a 20 20 4d 79 20 52 |repaired.. My R| 000000f0 6f 6d 62 6f 78 20 69 73 20 61 20 6c 61 74 65 72 |ombox is a later| 00000100 1a 20 74 79 70 65 1a 20 77 69 74 68 1a 20 34 1a |. type. with. 4.| 00000110 20 52 4f 4d 1a 20 73 6f 63 6b 65 74 73 1a 20 61 | ROM. sockets. a| 00000120 6e 64 1a 20 32 0d 63 61 72 74 72 69 64 67 65 20 |nd. 2.cartridge | 00000130 73 6c 6f 74 73 2e 0d 0d 53 69 6e 63 65 20 49 20 |slots...Since I | 00000140 77 72 6f 74 65 20 6d 79 20 61 70 70 65 61 6c 20 |wrote my appeal | 00000150 66 6f 72 20 68 65 6c 70 2c 20 49 1a 20 68 61 76 |for help, I. hav| 00000160 65 20 68 61 64 20 61 6e 6f 74 68 65 72 20 61 74 |e had another at| 00000170 74 65 6d 70 74 20 61 6e 64 20 69 74 20 77 6f 75 |tempt and it wou| 00000180 6c 64 0d 73 65 65 6d 20 74 68 61 74 20 49 20 68 |ld.seem that I h| 00000190 61 76 65 20 6e 6f 77 20 63 75 72 65 64 20 74 68 |ave now cured th| 000001a0 65 20 66 61 75 6c 74 2e 20 20 54 68 69 73 1a 20 |e fault. This. | 000001b0 73 65 65 6d 73 20 74 6f 20 68 61 76 65 20 62 65 |seems to have be| 000001c0 65 6e 20 64 75 65 20 74 6f 20 74 68 65 0d 63 6f |en due to the.co| 000001d0 6e 74 61 63 74 73 20 6f 66 20 74 68 65 20 65 64 |ntacts of the ed| 000001e0 67 65 20 63 6f 6e 6e 65 63 74 6f 72 20 6f 6e 20 |ge connector on | 000001f0 74 68 65 20 52 6f 6d 62 6f 78 2e 20 20 49 20 68 |the Rombox. I h| 00000200 61 64 1a 20 74 72 69 65 64 1a 20 74 6f 1a 20 6d |ad. tried. to. m| 00000210 61 6b 65 20 74 68 65 6d 0d 6d 61 6b 65 1a 20 62 |ake them.make. b| 00000220 65 74 74 65 72 1a 20 63 6f 6e 74 61 63 74 1a 20 |etter. contact. | 00000230 62 79 20 70 6f 6b 69 6e 67 20 74 68 65 6d 20 74 |by poking them t| 00000240 6f 67 65 74 68 65 72 20 77 69 74 68 20 74 68 65 |ogether with the| 00000250 20 70 6f 69 6e 74 20 6f 66 20 61 20 73 63 72 69 | point of a scri| 00000260 62 65 72 0d 62 75 74 20 74 68 69 73 20 77 61 73 |ber.but this was| 00000270 20 6e 6f 74 1a 20 76 65 72 79 20 73 61 74 69 73 | not. very satis| 00000280 66 61 63 74 6f 72 79 20 61 6e 64 20 64 69 64 20 |factory and did | 00000290 6e 6f 74 20 63 6f 6d 70 6c 65 74 65 6c 79 20 63 |not completely c| 000002a0 75 72 65 20 74 68 65 20 66 61 75 6c 74 2e 20 0d |ure the fault. .| 000002b0 49 20 68 61 76 65 20 6e 6f 77 20 75 73 65 64 20 |I have now used | 000002c0 61 1a 20 70 61 69 72 1a 20 6f 66 20 70 6f 69 6e |a. pair. of poin| 000002d0 74 65 64 20 74 77 65 65 7a 65 72 73 20 73 6f 20 |ted tweezers so | 000002e0 74 68 61 74 20 65 61 63 68 20 70 61 69 72 20 6f |that each pair o| 000002f0 66 20 63 6f 6e 74 61 63 74 73 0d 63 6f 75 6c 64 |f contacts.could| 00000300 20 62 65 20 73 71 75 65 65 7a 65 64 20 74 6f 67 | be squeezed tog| 00000310 65 74 68 65 72 20 61 6e 64 20 73 6f 20 6d 61 6b |ether and so mak| 00000320 65 20 62 65 74 74 65 72 20 63 6f 6e 74 61 63 74 |e better contact| 00000330 2e 0d 0d 49 20 73 75 70 70 6f 73 65 20 74 68 61 |...I suppose tha| 00000340 74 20 69 74 20 77 6f 75 6c 64 20 62 65 20 62 65 |t it would be be| 00000350 74 74 65 72 20 74 6f 20 72 65 70 6c 61 63 65 20 |tter to replace | 00000360 74 68 65 20 65 64 67 65 20 63 6f 6e 6e 65 63 74 |the edge connect| 00000370 6f 72 20 62 75 74 20 61 73 20 79 6f 75 0d 73 61 |or but as you.sa| 00000380 79 20 74 68 65 20 70 6c 61 73 74 69 63 20 63 61 |y the plastic ca| 00000390 73 65 20 69 73 20 73 74 75 63 6b 20 74 6f 67 65 |se is stuck toge| 000003a0 74 68 65 72 20 61 6e 64 20 49 20 61 6d 20 72 65 |ther and I am re| 000003b0 6c 75 63 74 61 6e 74 20 74 6f 20 6f 70 65 6e 20 |luctant to open | 000003c0 69 74 20 75 70 2e 0d 0d 52 65 67 61 72 64 69 6e |it up...Regardin| 000003d0 67 20 74 68 65 20 63 6c 65 61 6e 69 6e 67 20 6f |g the cleaning o| 000003e0 66 20 74 68 65 20 65 64 67 65 20 63 6f 6e 6e 65 |f the edge conne| 000003f0 63 74 6f 72 1a 20 6f 6e 1a 20 74 68 65 20 45 6c |ctor. on. the El| 00000400 6b 2e 20 20 49 20 68 61 76 65 20 67 6f 74 20 74 |k. I have got t| 00000410 68 65 0d 43 6c 65 61 6e 69 6e 67 1a 20 50 61 64 |he.Cleaning. Pad| 00000420 1a 20 28 4d 61 70 6c 69 6e 1a 20 46 4d 38 31 43 |. (Maplin. FM81C| 00000430 29 20 66 6f 72 20 63 6c 65 61 6e 69 6e 67 20 65 |) for cleaning e| 00000440 64 67 65 20 63 6f 6e 6e 65 63 74 6f 72 73 2e 20 |dge connectors. | 00000450 20 54 68 69 73 1a 20 69 73 1a 20 61 6e 0d 69 6d | This. is. an.im| 00000460 70 72 65 67 6e 61 74 65 64 20 74 69 73 73 75 65 |pregnated tissue| 00000470 20 69 6e 20 61 1a 20 73 61 63 68 65 74 2e 1a 20 | in a. sachet.. | 00000480 20 49 1a 20 66 6f 75 6e 64 20 74 68 61 74 20 74 | I. found that t| 00000490 68 69 73 20 65 61 73 69 65 72 20 74 6f 20 75 73 |his easier to us| 000004a0 65 20 74 68 61 6e 20 61 0d 70 65 6e 63 69 6c 20 |e than a.pencil | 000004b0 65 72 61 73 65 72 20 61 73 20 79 6f 75 20 63 61 |eraser as you ca| 000004c0 6e 1a 20 66 6f 6c 64 20 69 74 20 72 6f 75 6e 64 |n. fold it round| 000004d0 20 61 20 70 69 65 63 65 20 6f 66 20 73 74 69 66 | a piece of stif| 000004e0 66 20 63 61 72 64 20 66 6f 72 20 63 6c 65 61 6e |f card for clean| 000004f0 69 6e 67 0d 74 68 65 20 74 6f 70 20 73 69 64 65 |ing.the top side| 00000500 20 77 69 74 68 6f 75 74 20 68 61 76 69 6e 67 20 | without having | 00000510 74 6f 20 64 69 73 6d 61 6e 74 6c 65 20 74 68 65 |to dismantle the| 00000520 20 45 6c 6b 2e 20 20 41 73 20 49 20 68 61 64 20 | Elk. As I had | 00000530 61 6c 72 65 61 64 79 20 75 73 65 64 20 61 0d 70 |already used a.p| 00000540 65 6e 63 69 6c 20 65 72 61 73 65 72 2c 20 49 20 |encil eraser, I | 00000550 63 61 6e 6e 6f 74 20 73 61 79 20 77 68 65 74 68 |cannot say wheth| 00000560 65 72 1a 20 74 68 69 73 1a 20 6d 61 64 65 20 61 |er. this. made a| 00000570 6e 79 20 66 75 72 74 68 65 72 20 69 6d 70 72 6f |ny further impro| 00000580 76 65 6d 65 6e 74 20 61 74 0d 70 72 65 73 65 6e |vement at.presen| 00000590 74 2e 0d 0d 52 69 63 68 61 72 64 20 44 69 6d 6f |t...Richard Dimo| 000005a0 6e 64 2c 20 35 20 42 72 69 61 72 79 20 43 6f 75 |nd, 5 Briary Cou| 000005b0 72 74 2c 20 53 49 44 43 55 50 2c 20 4b 65 6e 74 |rt, SIDCUP, Kent| 000005c0 2c 20 44 41 31 34 20 36 48 5a 2e 20 54 65 6c 20 |, DA14 6HZ. Tel | 000005d0 30 31 38 31 20 33 30 32 20 32 33 39 35 0d 2a 2a |0181 302 2395.**| 000005e0 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a |****************| * 00000620 2a 2a 2a 2a 2a 2a 2a 2a 0d 0d 4f 4e 45 20 46 55 |********..ONE FU| 00000630 52 54 48 45 52 20 50 4f 49 4e 54 20 4f 4e 20 54 |RTHER POINT ON T| 00000640 48 45 20 50 52 4f 42 4c 45 4d 20 4f 46 20 45 44 |HE PROBLEM OF ED| 00000650 47 45 20 43 4f 4e 4e 45 43 54 4f 52 53 2e 20 49 |GE CONNECTORS. I| 00000660 20 48 41 44 20 41 20 50 4c 55 53 20 32 20 41 4e | HAD A PLUS 2 AN| 00000670 44 20 41 4e 0d 4f 52 49 47 49 4e 41 4c 20 4a 41 |D AN.ORIGINAL JA| 00000680 46 41 20 4d 4f 44 45 20 37 20 42 4f 41 52 44 20 |FA MODE 7 BOARD | 00000690 41 53 20 57 45 4c 4c 20 41 53 20 4d 59 20 50 4c |AS WELL AS MY PL| 000006a0 55 53 20 31 20 41 4e 44 20 33 2e 20 49 20 48 41 |US 1 AND 3. I HA| 000006b0 44 20 41 20 4c 4f 54 20 4f 46 20 45 44 47 45 0d |D A LOT OF EDGE.| 000006c0 43 4f 4e 4e 45 43 54 4f 52 20 50 52 4f 42 4c 45 |CONNECTOR PROBLE| 000006d0 4d 53 2e 20 49 20 52 45 4d 4f 56 45 44 20 54 48 |MS. I REMOVED TH| 000006e0 45 20 43 4f 4e 4e 45 43 54 4f 52 20 46 52 4f 4d |E CONNECTOR FROM| 000006f0 20 54 48 45 20 50 4c 55 53 20 32 20 41 4e 44 20 | THE PLUS 2 AND | 00000700 55 53 49 4e 47 0d 53 48 4f 52 54 20 4c 45 4e 47 |USING.SHORT LENG| 00000710 54 48 53 20 4f 46 20 57 49 52 45 20 53 4f 4c 44 |THS OF WIRE SOLD| 00000720 49 45 52 45 44 20 54 48 45 20 50 4c 55 53 20 32 |IERED THE PLUS 2| 00000730 20 41 4e 44 20 54 48 45 20 4d 4f 44 45 20 37 20 | AND THE MODE 7 | 00000740 42 4f 41 52 44 20 54 4f 47 45 54 48 45 52 2e 20 |BOARD TOGETHER. | 00000750 0d 49 20 44 4f 4e 27 54 20 41 44 56 49 53 45 20 |.I DON'T ADVISE | 00000760 54 48 49 53 2e 20 49 54 20 44 49 44 20 57 4f 52 |THIS. IT DID WOR| 00000770 4b 20 41 46 54 45 52 20 41 20 57 48 49 4c 45 2c |K AFTER A WHILE,| 00000780 20 49 20 4e 45 45 44 45 44 20 54 4f 20 44 4f 20 | I NEEDED TO DO | 00000790 41 20 4c 4f 54 20 4f 46 0d 52 45 53 4f 4c 44 45 |A LOT OF.RESOLDE| 000007a0 52 49 4e 47 20 41 4e 44 20 54 48 45 20 46 49 4e |RING AND THE FIN| 000007b0 49 53 48 45 44 20 52 45 53 55 4c 54 20 49 53 20 |ISHED RESULT IS | 000007c0 4e 45 56 45 52 20 47 4f 49 4e 47 20 54 4f 20 42 |NEVER GOING TO B| 000007d0 45 20 41 53 20 47 4f 4f 44 2e 20 41 4c 53 4f 20 |E AS GOOD. ALSO | 000007e0 49 54 0d 49 53 20 45 58 54 52 45 45 4d 4c 59 20 |IT.IS EXTREEMLY | 000007f0 44 49 46 46 49 43 55 4c 54 20 54 4f 20 52 45 4d |DIFFICULT TO REM| 00000800 4f 56 45 20 54 48 45 20 53 4f 4c 44 45 52 20 46 |OVE THE SOLDER F| 00000810 52 4f 4d 20 54 48 45 20 47 4f 4c 44 20 43 4f 4e |ROM THE GOLD CON| 00000820 54 41 43 54 53 20 4f 46 20 54 48 45 0d 50 4c 55 |TACTS OF THE.PLU| 00000830 53 20 32 2e 0d |S 2..| 00000835
L/LETT1.m0
L/LETT1.m1
