9 �3:�23,1,0;0;0;0;:�14:�''"PRESS <SHIFT> TO SCROLL"''
�"PROLIFIC PROGRAMMER"
�"*******************"
(F�"You will find on this disc a few machine code utilities for the"
2P�"manipulation of basic programs that I have written over the years. Please"
<=�"publish them at your discretion. They are as follows:-"
F�
PN�"PROCLST - a basic procedure lister which I have only just finnished, it"
ZP�"started off life as a basic procedure it self. Save the machine code file"
dN�"as PROC. ie *SAVE PROC 7000 +250 on a 64k Elk or where ever you wish to"
nI�"run the program. If  assembling at page 900 it will over write the"
xO�"character definitions and the function keys. Type *PROC if saved to disc"
�I�"or *RUN if on tape.  The program replies with LISTPROC type in the"
�J�"procedure name, if it is a FUNCTION precede the name with 'FN'. The"
�Q�"program steps through the basic program in memory after first finding PAGE"
�K�"until it encounters the appropriate DEFPROC, it then stores the line"
�K�"number. It then looks for the next DEFPROC, DATA statement or end of"
�M�"program flag, and stores the preceding line number or the last one. It"
�Q�"then decodes the line numbers and puts LIST <first number>,<second number>"
�O�"into the keyboard buffer and then exits the program. The elk should then"
�>�"list the procedure or tell you if it could not find it."
��
�J�"KEYLIST - Function key lister that lists all sixteen keys ready for"
�P�"editing and takes less than one page of memory. If only function keys 0 -"
�M�"9 are required delete lines 150 & 160 and delete from line 170 CLC:LDA"

O�"&75, and finally change CMP #16 in line 240 to CMP #10. Save the machine"

O�"code file as *SAVE K 900 +100. The utility can be used as a star command"

&�"from disc *K or *RUN from tape."

"�

,N�"LIST - variable and procedure name lister, like KEYLIST takes less than"

6N�"one page of memory. The machine code picks out the procedure names from"

@Q�"the basic program in memory and declared variables from the linked list at"

JM�"PAGE 4. Dimensioned arrays are shown with a pair of brackets. Save the"

TD�"code as *LOOK 7000 +100 or where ever you wish to save it to."

^�

hL�"A few queries for the letters page. Has anybody got a spare Viewsheet"

rO�"cartridge they wish to sell for a paltry sum. The application I am using"

|Q�"at present has run out of memory using the 'Microl' disc based spreadsheet"

��"that I normally use."

��

�O�"I recently brought a complete Elk system from another chap, mainly for a"

�P�"second disc drive, with it is a Project Expansion User Port and a Slogger"

�P�"32k sideways Ram cartridge both of which crash all three of my Elk's. Has"

�P�"anybody got any ideas on that one because they both puzzle me and I would"

� �"like to use both of them."

��

�N�"On printer drivers I see nobody has mentioned Dabs Press 'Hyperdriver',"

�I�"its a rom based printer driver for the Elk, BBC B/B+/Master series"

�K�"computers which uses nemonics and is very versatile and I thoroughly"

�;�"recommend it as I have used it for the past 2 years."

��
Q�"The problem of a 64k Elk crashing every now and again I pinned down to dry"
O�"joints on the chip holders that the 'Master Ram Board' plugs into on the"
L�"main circuit board, apart from the ULA being dislodged. The course of"
&J�"action was to re-solder all the joints. Can anybody offer help on a"
0M�"Ferguson monitor whose screen some times flicks to a bright horizontal"
:;�"line across the centre of the screen and back again."
D�
N#�"Mick Comley, Faversham, Kent"
XO�"************************************************************************"
b�"THE WINNER!"
l�"***********"
vN�"As winner of the PRINTER SWITCH competition I should like to express my"
�O�"thanks to all involved. To Derek for donating, and to Will (or I suspect"
�P�"Alison) for checking the entries. I can assure you that to me this switch"
�Q�"will be most useful, and hopfully I can say goodbye to all the fiddling of"
�M�"changing plugs and cables etc. But, also I had a lovely time doing the"
�N�"actual competition, which gave me several hours enjoyment. Good luck to"
�O�"E.U.G. and all ELK users, long may you prosper. I enjoy the Magazine and"
�O�"am sorry to hear that it is no longer feasable to print it . But nice to"
�P�"know it will continue in the form of a disc. ( a bit difficult to read in"
�<�"bed though) Keep smiling everyone the summers coming."
��
�$�"David Randall, Exeter, Devon."
�Q�"**************************************************************************"
��
�"ALTERNATIVE ALTERATIVE"
�"**********************"
P�"With reference to the Alternative Printer Driver discussed by Christopher"
 %�"Chadwick in Issue 4 of E.U.G."
*�
4P�"First of all let me say how good I thought the programme was, but for one"
>I�"thing, I could never get my G.L.P. printer to go into N.L.Q. mode."
H�
RO�"On looking at the Driver  programme I checked the line which should send"
\L�"my printer to work.  Although I had copied it correctly it still only"
f�"printed in draft print."
p�
z"�"810 EQUB &00004645FF/HT 132"
��
�P�"On consulting the Printer manual I came up with an alternative code which"
�
�"was :-"
��
� �"810 EQUB &3031FF78/HT 132"
��
�P�"It may be that there's something different about my G.L.P. but if anybody"
�I�"else has had the same problem they might like to try the new code."
��
�%�"Alec Miles, Billericay, Essex."
�Q�"**************************************************************************"
��
��"UNLOCKING SWRAM"
�"***************"
O�"In E.U.G. 6, S. Treasurer of Birmingham asks about an old Commodore disc"
N�"drive.  I have a C64C and 1541 MkII disc drive which isn't very helpful"
$K�"but a friend of mine used to own a PET which did use the 8050 drive."
.Q�"According to him, the 8050 works through a GPIB (general purpose interface"
8O�"bus) which operates according to the IEEE488 standard and I believe this"
BP�"is used in a lot of industrial applications. A local Commodore user group"
L �"may be able to help more."
V�
`Q�"I recently fitted Slogger's Electron expansion 2.0 (actually 2.02) into my"
jQ�"Plus 1 and puzzled for a while as to why *RLOAD would not work with PRES's"
tQ�"Advanced Sideways Ram. The sideways RAM worked perfectly when I loaded ROM"
~O�"images with *ASR. I found that with *RLOAD it is necessary to unlock the"
�C�"RAM and then relock it. Once I had done this it worked well."
��
�E�"Can anyone let me have a copy of the instructions for Cyklone?"
��
�=�"I do agree with J.D. - Assembler or Assembly language."
��
�Q�"On caring for one's data recorder may I add that it is good sense to clean"
�P�"the pinch wheel and capstan whenever the head is cleaned (or more often)."
�O�"Iron oxide can build up on the pinch wheel and it is possible for a spot"
�N�"to be deposited onto the tape. this explains why a tape that works well"
�P�"one time will not load the next time. Quite frustrating but checking with"
�I�"a magnifying glass may enable one to find and remove the offending"
3�"particle and render the tape readable again."

�
P�"I do hope we are going to get listings on disc as well as the magazine. I"
P�"was intrigued by the article on printing at full speed until I found that"
()�"my printer only prints at 100 cps!"
2�
<P�"Finally, I'd like to know whether there has ever been accounting software"
FQ�"and genealogical software written for the Elk and if so, can I get hold of"
PK�"the programmes? And finally finally, is there an expert out there on"
Z,�"coulour printing with the Okimate 20?"
d�
nJ�"I think the newsletter is super, and much better value than the big"
x0�"glossies that don't support the Electron."
��
�.�"Alan Richardson, Auckland, New Zealand."
�Q�"**************************************************************************"
��3
�:�''"PLEASE PRESS <P> TO PRINT TEXT, <M> FOR MAIN MENU"
��:A$=�:� A$="P" �  A$="M"
�� A$="P" � �2:�
�� A$="M" � �"MENU"
�
