Sound Tracker Player v4.13 (24 Jan 1992)
============================================================================
Credits => Hugo Finnes (The original SoundTracker playroutine)
Fabrice Mercier (The Serial Port's Tracker player)
Matthew Farrow (Put the above together, and added SWIs)
William Delves (The DeskTop front end)
============================================================================
Introduction
------------
The visible part of this program is an interface to a relocatable
module written by the people named above. It provides many ways of
controlling the way in which the SoundTracker modules are played. Such
modules can be obtained from most PD libraries or BBSs. There follows a
description of how to use the program - further information on the
SoundTracker module can be found in the file Mod_Help.
Loading
-------
The program can be loaded from any filer window by double-clicking on
it's icon, or on any STracker tune icon. The icon will then appear on the
icon bar, ready for a tune to be loaded. Tunes may be loaded by double
clicking on them (filetype CB6). The icon on the icon bar changes to
reflect the type of tune loaded - STracker or Tracker. The tune will
then start to play. Loading further tunes will stop the previous tune,
and load the new tune, memory permitting. Any spare memory in the RMA
will be released at this point. Double clicking on a tune when the program
is not loaded will result in the program being loaded, and the tune file
loaded as well. The tune will then start to play.
The Menu
--------
Clicking on the middle mouse button over the icon on the icon bar
reveals a menu. A description of the given options follows :-
+---------------+
| STracker |
|---------------|
| Info | - Selecting (or moving right over the arrow) brings up a
| | window showing details about the program (version,
| | authors etc). It will disappear as soon as you perform
| | any other operation.
| |
| Windows ->| - Leads to a submenu that gives a selection of windows
| | that may be opened. Explained later.
| |
| Click Open ->| - Leads to a submenu that gives a list of all the
| | available windows. The entrys may be toggled on/off,
| | those with a tick by them being 'on'. Those that are
| | 'on' will be opened when the icon bar icon is clicked
| | on. Those that are not 'on' will not be opened.
| |
| Delay ->| - This option leads to a writable sub-menu. This
| | specifies the delay (in centi-seconds) between each
| | refresh of the 'Control', 'Sound Info' and 'Keyboard'
| | windows. If this value is set to 0, then the windows
| | will be updated every null event. The lower this
| | number, the greater the processing time taken by the
| | program. The default value of 2 seems to give a good
| | balance between processing time and the appearance of
| | the program.
| |
| Sample Rate ->| - Leads to a submenu that gives 4 sample rate options.
| | These are:
| | Normal - The normal (default) sample rate
| | Half - Sample pitch as normal, but the sample rate
| | is halved. This results in less processor
| | time being used by the module. Some samples
| | sound clearly different at this rate.
| | Enhanced VIDC Normal
| | - For people with VIDC enhancers. The tune
| | will now sound at normal pitch, or a
| | perfect fifth lower for those without a
| | VIDC enhancer.
| | Enhanced VIDC Half
| | - Again for people with VIDC enhancers. The
| | tune will be at normal pitch for those with
| | a VIDC enhancer, and dire for those without
| | a VIDC enhancer.
| |
| |
| Quit | - This option removes the program from the computer's
| | memory. It will ask if you wish to stop the music.
| | If the answer to this is yes, then the music will be
| | stopped, the TrackerModule removed, and as much
| | memory as possible will be released.
+---------------+
+---------------+
| Open Window |
+---------------+
| |
| Control | - This window will stay on the screen until it is
| | explicitly closed. It allows control over most of the
| | modules functions. The top row of icons are the control
| | icons, the lower icons giving information. The control
| | icons are (from left to right):
| | REVERSE - Moves to the beginning of the previous pattern
| | STOP - Stops the current tune & releases the memory
| | PAUSE - Pauses the current tune retaining position
| | PLAY - Restarts the tune after PAUSE
| | FORWARD - Moves to the beginning of the next pattern
| | SPEAKER - Toggles the internal speaker on/off
| | The next icon down gives the overall status of the
| | program - STOPPED, PAUSED or PLAYING. Below this are
| | the position and speed icons. Pattern is the current
| | position in the Pattern table, and Position is the
| | position within this Pattern. Speed shows how quickly
| | it moves onto a new position. 1 is fast, with higher
| | numbers being slower.
| |
| Keyboard | - This window will stay on the screen until it is
| | explicitly closed. This window shows graphically the
| | pitch of the notes currently playing. Channel 1 uses
| | colour 8, channel 8 uses colour 15, with the other
| | channels using colour (channel no. + 8).
| | If a note is clicked on, then the Pitch field in 'Play
| | Sample' will be set accordingly, and if the tune is
| | paused, then the sample will be played.
| |
| General Info | - This window will stay on the screen until it is
| | explicitly closed. It shows information about the
| | current tune. Author is only filled in if the tune is
| | a Tracker tune. Patterns relates to the 'Patterns'
| | field in Control.
| |
| Stereo Setting| - This window will stay on the screen until it is
| | explicitly closed. This window allows adjustment of
| | the stereo positioning of the 8 sound channels.
| | To adjust the positions, click anywhere in the icon
| | that has a red area for the relevant channel. The
| | red block will move to the nearest possible position,
| | and the stereo position of the channel will be set
| | accordingly. The icon saying 'ON' can be toggled
| | simply by clicking on it. The icon will change
| | accordingly, and the status of the channel will as
| | well: ON - channel sounds
| | OFF - channel is muted.
| | The presets section in the lower half of the window
| | allows for quick changing of the stereo positioning.
| | By clicking on the icon, the position and status
| | of the channel will be altered according to the
| | icon clicked on.
| | The bottom row are user definable. Set the position
| | and status of the channels, and click on the red 'REC'
| | icon. The position and status of all 8 channels will
| | be recorded, and can be recalled just like the other
| | presets. The best way to understand this is by
| | experimentation.
| | The slider bar along the bottom of the window is the
| | overall volume control. Clicking on the bar will
| | cause the volume to change smoothly, the red bar
| | indicating the volume at all times. The two icons,
| | max and min, take the volume (and slider) to the
| | maximum and the minimum. It also indicates which ends
| | of the slider are maximum and minimum.
| |
| Sound Data | - This window will stay on the screen until it is
| | explicitly closed. It shows information about what
| | notes are currently sounding. Sample shows which
| | sample is currently being used on the channel (see
| | 'Sample Info' for an explanation of the numbers).
| | Volume (in the range 0(silent) -255(loud)) is fairly
| | self explanatory. Note shows the pitch of the note
| | currently being played. The pitch is shown more
| | graphically in 'Keyboard'.
| |
| Sample Info | - This window will stay on the screen until it is
| | explicitly closed. It shows information about the
| | samples used by the tune. The first column is the
| | sample number, the second is the sample name. The
| | third column is the sample length (in bytes). The
| | final column is the default volume of the sample.
| | By clicking in the name column, the sample clicked on
| | will become the current sample for 'Play Sample'.
| | Clicking menu on this window will pop up a menu
| | allowing raw sample data to be saved. The first entry
| | leads off to a submenu in which the number of the
| | sample to be saved is entered. The second entry
| | leads off to a save dialogue box. The sample data
| | can be save in the normal manner. The save sample
| | dialogue box will not show if no tune is loaded.
| |
| Play Sample ->| - To open the window, click on the Play Sample entry.
| | To use the submenu options, move the mouse across.
| | This window will stay on the screen until it is
| | explicitly closed. This window allows the playing of
| | the samples used by the tune. They can only be played
| | while the tune is paused (the grey box at the bottom of
| | the window will change to reveal a 'Play Sample' icon).
| | All of the fields are self explanatory - click on the
| | arrows to change the value, and 'Play Sample' to play
| | the sample.
| | A couple of items have been added to to ease the
| | playing of samples:
| | 1) By clicking on the notes on the keyboard, the
| | Pitch field in the window will be set to to value
| | of the note clicked on. Additionally, if the the
| | Keyboard entry on the submenu is ticked, the
| | sample will also be played.
| | 2) By clicking on the sample name (not number) in the
| | sample info window, the sample field in the window
| | will be set to the value of the sample clicked on.
| | Additionally, if the Samples entry on the submenu
| | is ticked, then the sample will be played as well.
+---------------+
============================================================================
This program was written in Acorn's C (release 3) and compiled on a
2meg A3000.
If anyone wishes to contact me (for donations, ideas for modifications/
extensions, reporting of bugs, requests for source code, modifications etc),
I can be contacted at the following places:
Snail Mail - William Delves
Pound House,
Pound Lane,
Hadleigh,
Suffolk,
IP7 5EQ.
Via Modem - Arcade BBS - 081 654 2212 - UserName: Deleves
UserNo. : #102
This program is public domain, and therefore may be freely copied. A
charge may be made, but only to cover costs of media, advertising and
postage. This application must be distributed in its entirety, with no
alterations to any of the files. Any modifications must be sent to me
at the address above.
Changes.
========
Version Date Change
v4.01 01-09-91 Opening of windows now put onto a submenu.
v4.02 05-10-91 Changed to accommodate TrackerModule v4.04
- Channel 1 of playsample now works
- Channel mute now uses Tracker SWIs
- New menu option - sample rate. Allows people
with VIDC enhancers to hear the tune at the proper
pitch. Half sample rate also available. Default
is normal with no VIDC enhancer.
v4.03 08-10-91 Control, Playsample and Stereo setting windows now
changed to 3D.
Channel 0 on PlaySample means that the sample is played
on all channels simultaneousty.
v4.10 18-11-91 Complete re-write.
All windows now '3D'.
Tunes will load properly when program not loaded.
Will no longer crash with certain tunes.
Stereo setting now much better (presets added).
User choice of windows opened on icon bar click.
Channel 0 playsample option now works.
User choice of playing sample or not when clicking
on keyboard and sample windows.
v4.11 24-11-91 Added overall volume control (using the new Tracker_
Volume SWI) to stereo window.
Sample list should no longer have strange characters
in empty slots (was bug in module).
Now requires v4.05 of TrackerModule.
v4.12 30-11-91 Various minor bugs fixed (including overall volume)
v4.13 24-11-92 Window structures now created only when requested
- should allow for more programs to run with STracker
Save raw sample data menu added.
Now requires v4.06 of TrackerModule.
00000000 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| * 00000040 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 0a 53 6f 75 |============.Sou| 00000050 6e 64 20 54 72 61 63 6b 65 72 20 50 6c 61 79 65 |nd Tracker Playe| 00000060 72 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 |r | 00000070 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00000080 20 20 20 20 20 20 76 34 2e 31 33 20 28 32 34 20 | v4.13 (24 | 00000090 4a 61 6e 20 31 39 39 32 29 0a 3d 3d 3d 3d 3d 3d |Jan 1992).======| 000000a0 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| * 000000e0 3d 3d 3d 3d 3d 3d 0a 0a 43 72 65 64 69 74 73 20 |======..Credits | 000000f0 3d 3e 20 48 75 67 6f 20 46 69 6e 6e 65 73 20 20 |=> Hugo Finnes | 00000100 20 20 20 20 20 20 28 54 68 65 20 6f 72 69 67 69 | (The origi| 00000110 6e 61 6c 20 53 6f 75 6e 64 54 72 61 63 6b 65 72 |nal SoundTracker| 00000120 20 70 6c 61 79 72 6f 75 74 69 6e 65 29 0a 20 20 | playroutine). | 00000130 20 20 20 20 20 20 20 20 20 46 61 62 72 69 63 65 | Fabrice| 00000140 20 4d 65 72 63 69 65 72 20 20 20 20 28 54 68 65 | Mercier (The| 00000150 20 53 65 72 69 61 6c 20 50 6f 72 74 27 73 20 54 | Serial Port's T| 00000160 72 61 63 6b 65 72 20 70 6c 61 79 65 72 29 0a 20 |racker player). | 00000170 20 20 20 20 20 20 20 20 20 20 4d 61 74 74 68 65 | Matthe| 00000180 77 20 46 61 72 72 6f 77 20 20 20 20 20 28 50 75 |w Farrow (Pu| 00000190 74 20 74 68 65 20 61 62 6f 76 65 20 74 6f 67 65 |t the above toge| 000001a0 74 68 65 72 2c 20 61 6e 64 20 61 64 64 65 64 20 |ther, and added | 000001b0 53 57 49 73 29 0a 0a 20 20 20 20 20 20 20 20 20 |SWIs).. | 000001c0 20 20 57 69 6c 6c 69 61 6d 20 44 65 6c 76 65 73 | William Delves| 000001d0 20 20 20 20 20 28 54 68 65 20 44 65 73 6b 54 6f | (The DeskTo| 000001e0 70 20 66 72 6f 6e 74 20 65 6e 64 29 0a 0a 3d 3d |p front end)..==| 000001f0 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| * 00000230 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 0a 0a 49 6e 74 72 |==========..Intr| 00000240 6f 64 75 63 74 69 6f 6e 0a 2d 2d 2d 2d 2d 2d 2d |oduction.-------| 00000250 2d 2d 2d 2d 2d 0a 20 20 20 20 54 68 65 20 76 69 |-----. The vi| 00000260 73 69 62 6c 65 20 70 61 72 74 20 6f 66 20 74 68 |sible part of th| 00000270 69 73 20 70 72 6f 67 72 61 6d 20 69 73 20 61 6e |is program is an| 00000280 20 69 6e 74 65 72 66 61 63 65 20 74 6f 20 61 20 | interface to a | 00000290 72 65 6c 6f 63 61 74 61 62 6c 65 20 0a 6d 6f 64 |relocatable .mod| 000002a0 75 6c 65 20 77 72 69 74 74 65 6e 20 62 79 20 74 |ule written by t| 000002b0 68 65 20 70 65 6f 70 6c 65 20 6e 61 6d 65 64 20 |he people named | 000002c0 61 62 6f 76 65 2e 20 20 49 74 20 70 72 6f 76 69 |above. It provi| 000002d0 64 65 73 20 6d 61 6e 79 20 77 61 79 73 20 6f 66 |des many ways of| 000002e0 20 0a 63 6f 6e 74 72 6f 6c 6c 69 6e 67 20 74 68 | .controlling th| 000002f0 65 20 77 61 79 20 69 6e 20 77 68 69 63 68 20 74 |e way in which t| 00000300 68 65 20 53 6f 75 6e 64 54 72 61 63 6b 65 72 20 |he SoundTracker | 00000310 6d 6f 64 75 6c 65 73 20 61 72 65 20 70 6c 61 79 |modules are play| 00000320 65 64 2e 20 20 53 75 63 68 20 0a 6d 6f 64 75 6c |ed. Such .modul| 00000330 65 73 20 63 61 6e 20 62 65 20 6f 62 74 61 69 6e |es can be obtain| 00000340 65 64 20 66 72 6f 6d 20 6d 6f 73 74 20 50 44 20 |ed from most PD | 00000350 6c 69 62 72 61 72 69 65 73 20 6f 72 20 42 42 53 |libraries or BBS| 00000360 73 2e 20 20 54 68 65 72 65 20 66 6f 6c 6c 6f 77 |s. There follow| 00000370 73 20 61 20 0a 64 65 73 63 72 69 70 74 69 6f 6e |s a .description| 00000380 20 6f 66 20 68 6f 77 20 74 6f 20 75 73 65 20 74 | of how to use t| 00000390 68 65 20 70 72 6f 67 72 61 6d 20 2d 20 66 75 72 |he program - fur| 000003a0 74 68 65 72 20 69 6e 66 6f 72 6d 61 74 69 6f 6e |ther information| 000003b0 20 6f 6e 20 74 68 65 20 0a 53 6f 75 6e 64 54 72 | on the .SoundTr| 000003c0 61 63 6b 65 72 20 6d 6f 64 75 6c 65 20 63 61 6e |acker module can| 000003d0 20 62 65 20 66 6f 75 6e 64 20 69 6e 20 74 68 65 | be found in the| 000003e0 20 66 69 6c 65 20 4d 6f 64 5f 48 65 6c 70 2e 0a | file Mod_Help..| 000003f0 0a 4c 6f 61 64 69 6e 67 0a 2d 2d 2d 2d 2d 2d 2d |.Loading.-------| 00000400 0a 20 20 20 20 54 68 65 20 70 72 6f 67 72 61 6d |. The program| 00000410 20 63 61 6e 20 62 65 20 6c 6f 61 64 65 64 20 66 | can be loaded f| 00000420 72 6f 6d 20 61 6e 79 20 66 69 6c 65 72 20 77 69 |rom any filer wi| 00000430 6e 64 6f 77 20 62 79 20 64 6f 75 62 6c 65 2d 63 |ndow by double-c| 00000440 6c 69 63 6b 69 6e 67 20 6f 6e 0a 69 74 27 73 20 |licking on.it's | 00000450 69 63 6f 6e 2c 20 6f 72 20 6f 6e 20 61 6e 79 20 |icon, or on any | 00000460 53 54 72 61 63 6b 65 72 20 74 75 6e 65 20 69 63 |STracker tune ic| 00000470 6f 6e 2e 20 20 54 68 65 20 69 63 6f 6e 20 77 69 |on. The icon wi| 00000480 6c 6c 20 74 68 65 6e 20 61 70 70 65 61 72 20 6f |ll then appear o| 00000490 6e 20 74 68 65 0a 69 63 6f 6e 20 62 61 72 2c 20 |n the.icon bar, | 000004a0 72 65 61 64 79 20 66 6f 72 20 61 20 74 75 6e 65 |ready for a tune| 000004b0 20 74 6f 20 20 62 65 20 6c 6f 61 64 65 64 2e 20 | to be loaded. | 000004c0 20 54 75 6e 65 73 20 6d 61 79 20 62 65 20 6c 6f | Tunes may be lo| 000004d0 61 64 65 64 20 62 79 20 64 6f 75 62 6c 65 0a 63 |aded by double.c| 000004e0 6c 69 63 6b 69 6e 67 20 6f 6e 20 74 68 65 6d 20 |licking on them | 000004f0 28 66 69 6c 65 74 79 70 65 20 43 42 36 29 2e 20 |(filetype CB6). | 00000500 20 20 54 68 65 20 69 63 6f 6e 20 6f 6e 20 74 68 | The icon on th| 00000510 65 20 69 63 6f 6e 20 62 61 72 20 63 68 61 6e 67 |e icon bar chang| 00000520 65 73 20 74 6f 0a 72 65 66 6c 65 63 74 20 74 68 |es to.reflect th| 00000530 65 20 74 79 70 65 20 6f 66 20 74 75 6e 65 20 6c |e type of tune l| 00000540 6f 61 64 65 64 20 2d 20 20 53 54 72 61 63 6b 65 |oaded - STracke| 00000550 72 20 6f 72 20 54 72 61 63 6b 65 72 2e 20 20 54 |r or Tracker. T| 00000560 68 65 20 74 75 6e 65 20 77 69 6c 6c 0a 74 68 65 |he tune will.the| 00000570 6e 20 73 74 61 72 74 20 74 6f 20 70 6c 61 79 2e |n start to play.| 00000580 20 20 4c 6f 61 64 69 6e 67 20 66 75 72 74 68 65 | Loading furthe| 00000590 72 20 20 74 75 6e 65 73 20 77 69 6c 6c 20 73 74 |r tunes will st| 000005a0 6f 70 20 74 68 65 20 70 72 65 76 69 6f 75 73 20 |op the previous | 000005b0 74 75 6e 65 2c 0a 61 6e 64 20 6c 6f 61 64 20 74 |tune,.and load t| 000005c0 68 65 20 6e 65 77 20 74 75 6e 65 2c 20 6d 65 6d |he new tune, mem| 000005d0 6f 72 79 20 20 70 65 72 6d 69 74 74 69 6e 67 2e |ory permitting.| 000005e0 20 20 41 6e 79 20 73 70 61 72 65 20 6d 65 6d 6f | Any spare memo| 000005f0 72 79 20 69 6e 20 74 68 65 20 52 4d 41 0a 77 69 |ry in the RMA.wi| 00000600 6c 6c 20 62 65 20 72 65 6c 65 61 73 65 64 20 61 |ll be released a| 00000610 74 20 74 68 69 73 20 70 6f 69 6e 74 2e 20 44 6f |t this point. Do| 00000620 75 62 6c 65 20 63 6c 69 63 6b 69 6e 67 20 6f 6e |uble clicking on| 00000630 20 61 20 74 75 6e 65 20 77 68 65 6e 20 74 68 65 | a tune when the| 00000640 20 70 72 6f 67 72 61 6d 0a 69 73 20 6e 6f 74 20 | program.is not | 00000650 6c 6f 61 64 65 64 20 77 69 6c 6c 20 72 65 73 75 |loaded will resu| 00000660 6c 74 20 69 6e 20 74 68 65 20 70 72 6f 67 72 61 |lt in the progra| 00000670 6d 20 62 65 69 6e 67 20 6c 6f 61 64 65 64 2c 20 |m being loaded, | 00000680 61 6e 64 20 74 68 65 20 74 75 6e 65 20 66 69 6c |and the tune fil| 00000690 65 0a 6c 6f 61 64 65 64 20 61 73 20 77 65 6c 6c |e.loaded as well| 000006a0 2e 20 20 54 68 65 20 74 75 6e 65 20 77 69 6c 6c |. The tune will| 000006b0 20 74 68 65 6e 20 73 74 61 72 74 20 74 6f 20 70 | then start to p| 000006c0 6c 61 79 2e 0a 0a 54 68 65 20 4d 65 6e 75 0a 2d |lay...The Menu.-| 000006d0 2d 2d 2d 2d 2d 2d 2d 0a 20 20 20 20 43 6c 69 63 |-------. Clic| 000006e0 6b 69 6e 67 20 6f 6e 20 74 68 65 20 6d 69 64 64 |king on the midd| 000006f0 6c 65 20 6d 6f 75 73 65 20 62 75 74 74 6f 6e 20 |le mouse button | 00000700 6f 76 65 72 20 74 68 65 20 69 63 6f 6e 20 6f 6e |over the icon on| 00000710 20 74 68 65 20 69 63 6f 6e 20 62 61 72 20 0a 72 | the icon bar .r| 00000720 65 76 65 61 6c 73 20 61 20 6d 65 6e 75 2e 20 20 |eveals a menu. | 00000730 41 20 64 65 73 63 72 69 70 74 69 6f 6e 20 6f 66 |A description of| 00000740 20 74 68 65 20 67 69 76 65 6e 20 6f 70 74 69 6f | the given optio| 00000750 6e 73 20 66 6f 6c 6c 6f 77 73 20 3a 2d 0a 0a 20 |ns follows :-.. | 00000760 2b 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |+---------------| 00000770 2b 0a 20 7c 20 20 20 53 54 72 61 63 6b 65 72 20 |+. | STracker | 00000780 20 20 20 7c 0a 20 7c 2d 2d 2d 2d 2d 2d 2d 2d 2d | |. |---------| 00000790 2d 2d 2d 2d 2d 2d 7c 20 0a 20 7c 20 49 6e 66 6f |------| . | Info| 000007a0 20 20 20 20 20 20 20 20 20 20 7c 20 2d 20 53 65 | | - Se| 000007b0 6c 65 63 74 69 6e 67 20 28 6f 72 20 6d 6f 76 69 |lecting (or movi| 000007c0 6e 67 20 72 69 67 68 74 20 6f 76 65 72 20 74 68 |ng right over th| 000007d0 65 20 61 72 72 6f 77 29 20 62 72 69 6e 67 73 20 |e arrow) brings | 000007e0 75 70 20 61 0a 20 7c 20 20 20 20 20 20 20 20 20 |up a. | | 000007f0 20 20 20 20 20 20 7c 20 20 20 77 69 6e 64 6f 77 | | window| 00000800 20 73 68 6f 77 69 6e 67 20 64 65 74 61 69 6c 73 | showing details| 00000810 20 61 62 6f 75 74 20 74 68 65 20 70 72 6f 67 72 | about the progr| 00000820 61 6d 20 28 76 65 72 73 69 6f 6e 2c 20 0a 20 7c |am (version, . || 00000830 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00000840 20 20 20 61 75 74 68 6f 72 73 20 65 74 63 29 2e | authors etc).| 00000850 20 20 49 74 20 77 69 6c 6c 20 64 69 73 61 70 70 | It will disapp| 00000860 65 61 72 20 61 73 20 73 6f 6f 6e 20 61 73 20 79 |ear as soon as y| 00000870 6f 75 20 70 65 72 66 6f 72 6d 0a 20 7c 20 20 20 |ou perform. | | 00000880 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00000890 61 6e 79 20 6f 74 68 65 72 20 6f 70 65 72 61 74 |any other operat| 000008a0 69 6f 6e 2e 20 0a 20 7c 20 20 20 20 20 20 20 20 |ion. . | | 000008b0 20 20 20 20 20 20 20 7c 0a 20 7c 20 57 69 6e 64 | |. | Wind| 000008c0 6f 77 73 20 20 20 20 20 2d 3e 7c 20 2d 20 4c 65 |ows ->| - Le| 000008d0 61 64 73 20 74 6f 20 61 20 73 75 62 6d 65 6e 75 |ads to a submenu| 000008e0 20 74 68 61 74 20 67 69 76 65 73 20 61 20 73 65 | that gives a se| 000008f0 6c 65 63 74 69 6f 6e 20 6f 66 20 77 69 6e 64 6f |lection of windo| 00000900 77 73 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |ws. | | 00000910 20 20 20 20 7c 20 20 20 74 68 61 74 20 6d 61 79 | | that may| 00000920 20 62 65 20 6f 70 65 6e 65 64 2e 20 20 45 78 70 | be opened. Exp| 00000930 6c 61 69 6e 65 64 20 6c 61 74 65 72 2e 0a 20 7c |lained later.. || 00000940 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00000950 0a 20 7c 20 43 6c 69 63 6b 20 4f 70 65 6e 20 20 |. | Click Open | 00000960 2d 3e 7c 20 2d 20 4c 65 61 64 73 20 74 6f 20 61 |->| - Leads to a| 00000970 20 73 75 62 6d 65 6e 75 20 74 68 61 74 20 67 69 | submenu that gi| 00000980 76 65 73 20 61 20 6c 69 73 74 20 6f 66 20 61 6c |ves a list of al| 00000990 6c 20 74 68 65 20 0a 20 7c 20 20 20 20 20 20 20 |l the . | | 000009a0 20 20 20 20 20 20 20 20 7c 20 20 20 61 76 61 69 | | avai| 000009b0 6c 61 62 6c 65 20 77 69 6e 64 6f 77 73 2e 20 20 |lable windows. | 000009c0 54 68 65 20 65 6e 74 72 79 73 20 6d 61 79 20 62 |The entrys may b| 000009d0 65 20 74 6f 67 67 6c 65 64 20 6f 6e 2f 6f 66 66 |e toggled on/off| 000009e0 2c 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |,. | | 000009f0 20 20 20 7c 20 20 20 74 68 6f 73 65 20 77 69 74 | | those wit| 00000a00 68 20 61 20 74 69 63 6b 20 62 79 20 74 68 65 6d |h a tick by them| 00000a10 20 62 65 69 6e 67 20 27 6f 6e 27 2e 20 20 54 68 | being 'on'. Th| 00000a20 6f 73 65 20 74 68 61 74 20 61 72 65 0a 20 7c 20 |ose that are. | | 00000a30 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 | | | 00000a40 20 20 27 6f 6e 27 20 77 69 6c 6c 20 62 65 20 6f | 'on' will be o| 00000a50 70 65 6e 65 64 20 77 68 65 6e 20 74 68 65 20 69 |pened when the i| 00000a60 63 6f 6e 20 62 61 72 20 69 63 6f 6e 20 69 73 20 |con bar icon is | 00000a70 63 6c 69 63 6b 65 64 0a 20 7c 20 20 20 20 20 20 |clicked. | | 00000a80 20 20 20 20 20 20 20 20 20 7c 20 20 20 6f 6e 2e | | on.| 00000a90 20 20 54 68 6f 73 65 20 74 68 61 74 20 61 72 65 | Those that are| 00000aa0 20 6e 6f 74 20 27 6f 6e 27 20 77 69 6c 6c 20 6e | not 'on' will n| 00000ab0 6f 74 20 62 65 20 6f 70 65 6e 65 64 2e 0a 20 7c |ot be opened.. || 00000ac0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00000ad0 0a 20 7c 20 44 65 6c 61 79 20 20 20 20 20 20 20 |. | Delay | 00000ae0 2d 3e 7c 20 2d 20 54 68 69 73 20 6f 70 74 69 6f |->| - This optio| 00000af0 6e 20 6c 65 61 64 73 20 74 6f 20 61 20 77 72 69 |n leads to a wri| 00000b00 74 61 62 6c 65 20 73 75 62 2d 6d 65 6e 75 2e 20 |table sub-menu. | 00000b10 20 54 68 69 73 0a 20 7c 20 20 20 20 20 20 20 20 | This. | | 00000b20 20 20 20 20 20 20 20 7c 20 20 20 73 70 65 63 69 | | speci| 00000b30 66 69 65 73 20 74 68 65 20 64 65 6c 61 79 20 28 |fies the delay (| 00000b40 69 6e 20 63 65 6e 74 69 2d 73 65 63 6f 6e 64 73 |in centi-seconds| 00000b50 29 20 62 65 74 77 65 65 6e 20 65 61 63 68 0a 20 |) between each. | 00000b60 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00000b70 7c 20 20 20 72 65 66 72 65 73 68 20 6f 66 20 74 || refresh of t| 00000b80 68 65 20 27 43 6f 6e 74 72 6f 6c 27 2c 20 27 53 |he 'Control', 'S| 00000b90 6f 75 6e 64 20 49 6e 66 6f 27 20 61 6e 64 20 27 |ound Info' and '| 00000ba0 4b 65 79 62 6f 61 72 64 27 0a 20 7c 20 20 20 20 |Keyboard'. | | 00000bb0 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 77 | | w| 00000bc0 69 6e 64 6f 77 73 2e 20 20 49 66 20 74 68 69 73 |indows. If this| 00000bd0 20 76 61 6c 75 65 20 69 73 20 73 65 74 20 74 6f | value is set to| 00000be0 20 30 2c 20 74 68 65 6e 20 74 68 65 20 77 69 6e | 0, then the win| 00000bf0 64 6f 77 73 0a 20 7c 20 20 20 20 20 20 20 20 20 |dows. | | 00000c00 20 20 20 20 20 20 7c 20 20 20 77 69 6c 6c 20 62 | | will b| 00000c10 65 20 75 70 64 61 74 65 64 20 65 76 65 72 79 20 |e updated every | 00000c20 6e 75 6c 6c 20 65 76 65 6e 74 2e 20 20 54 68 65 |null event. The| 00000c30 20 6c 6f 77 65 72 20 74 68 69 73 0a 20 7c 20 20 | lower this. | | 00000c40 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 | | | 00000c50 20 6e 75 6d 62 65 72 2c 20 74 68 65 20 67 72 65 | number, the gre| 00000c60 61 74 65 72 20 74 68 65 20 70 72 6f 63 65 73 73 |ater the process| 00000c70 69 6e 67 20 74 69 6d 65 20 74 61 6b 65 6e 20 62 |ing time taken b| 00000c80 79 20 74 68 65 0a 20 7c 20 20 20 20 20 20 20 20 |y the. | | 00000c90 20 20 20 20 20 20 20 7c 20 20 20 70 72 6f 67 72 | | progr| 00000ca0 61 6d 2e 20 20 54 68 65 20 64 65 66 61 75 6c 74 |am. The default| 00000cb0 20 76 61 6c 75 65 20 6f 66 20 32 20 73 65 65 6d | value of 2 seem| 00000cc0 73 20 74 6f 20 67 69 76 65 20 61 20 67 6f 6f 64 |s to give a good| 00000cd0 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00000ce0 20 20 7c 20 20 20 62 61 6c 61 6e 63 65 20 62 65 | | balance be| 00000cf0 74 77 65 65 6e 20 70 72 6f 63 65 73 73 69 6e 67 |tween processing| 00000d00 20 74 69 6d 65 20 61 6e 64 20 74 68 65 20 61 70 | time and the ap| 00000d10 70 65 61 72 61 6e 63 65 20 6f 66 0a 20 7c 20 20 |pearance of. | | 00000d20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 | | | 00000d30 20 74 68 65 20 70 72 6f 67 72 61 6d 2e 0a 20 7c | the program.. || 00000d40 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00000d50 0a 20 7c 20 53 61 6d 70 6c 65 20 52 61 74 65 20 |. | Sample Rate | 00000d60 2d 3e 7c 20 2d 20 4c 65 61 64 73 20 74 6f 20 61 |->| - Leads to a| 00000d70 20 73 75 62 6d 65 6e 75 20 74 68 61 74 20 67 69 | submenu that gi| 00000d80 76 65 73 20 34 20 73 61 6d 70 6c 65 20 72 61 74 |ves 4 sample rat| 00000d90 65 20 6f 70 74 69 6f 6e 73 2e 0a 20 7c 20 20 20 |e options.. | | 00000da0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00000db0 54 68 65 73 65 20 61 72 65 3a 0a 20 7c 20 20 20 |These are:. | | 00000dc0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00000dd0 20 4e 6f 72 6d 61 6c 20 2d 20 54 68 65 20 6e 6f | Normal - The no| 00000de0 72 6d 61 6c 20 28 64 65 66 61 75 6c 74 29 20 73 |rmal (default) s| 00000df0 61 6d 70 6c 65 20 72 61 74 65 0a 20 7c 20 20 20 |ample rate. | | 00000e00 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00000e10 20 48 61 6c 66 20 20 20 2d 20 53 61 6d 70 6c 65 | Half - Sample| 00000e20 20 70 69 74 63 68 20 61 73 20 6e 6f 72 6d 61 6c | pitch as normal| 00000e30 2c 20 62 75 74 20 74 68 65 20 73 61 6d 70 6c 65 |, but the sample| 00000e40 20 72 61 74 65 0a 20 7c 20 20 20 20 20 20 20 20 | rate. | | 00000e50 20 20 20 20 20 20 20 7c 20 20 20 20 20 20 20 20 | | | 00000e60 20 20 20 20 20 20 69 73 20 68 61 6c 76 65 64 2e | is halved.| 00000e70 20 20 54 68 69 73 20 72 65 73 75 6c 74 73 20 69 | This results i| 00000e80 6e 20 6c 65 73 73 20 70 72 6f 63 65 73 73 6f 72 |n less processor| 00000e90 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00000ea0 20 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00000eb0 20 74 69 6d 65 20 62 65 69 6e 67 20 75 73 65 64 | time being used| 00000ec0 20 62 79 20 74 68 65 20 6d 6f 64 75 6c 65 2e 20 | by the module. | 00000ed0 20 53 6f 6d 65 20 73 61 6d 70 6c 65 73 20 0a 20 | Some samples . | 00000ee0 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00000ef0 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 73 || s| 00000f00 6f 75 6e 64 20 63 6c 65 61 72 6c 79 20 64 69 66 |ound clearly dif| 00000f10 66 65 72 65 6e 74 20 61 74 20 74 68 69 73 20 72 |ferent at this r| 00000f20 61 74 65 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 |ate.. | | 00000f30 20 20 20 20 20 20 7c 20 20 20 20 45 6e 68 61 6e | | Enhan| 00000f40 63 65 64 20 56 49 44 43 20 4e 6f 72 6d 61 6c 0a |ced VIDC Normal.| 00000f50 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00000f60 20 7c 20 20 20 20 20 20 20 20 20 20 20 2d 20 46 | | - F| 00000f70 6f 72 20 70 65 6f 70 6c 65 20 77 69 74 68 20 56 |or people with V| 00000f80 49 44 43 20 65 6e 68 61 6e 63 65 72 73 2e 20 20 |IDC enhancers. | 00000f90 54 68 65 20 74 75 6e 65 0a 20 7c 20 20 20 20 20 |The tune. | | 00000fa0 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 20 20 | | | 00000fb0 20 20 20 20 20 20 20 20 20 77 69 6c 6c 20 6e 6f | will no| 00000fc0 77 20 73 6f 75 6e 64 20 61 74 20 6e 6f 72 6d 61 |w sound at norma| 00000fd0 6c 20 70 69 74 63 68 2c 20 6f 72 20 61 20 0a 20 |l pitch, or a . | 00000fe0 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00000ff0 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 70 || p| 00001000 65 72 66 65 63 74 20 66 69 66 74 68 20 6c 6f 77 |erfect fifth low| 00001010 65 72 20 66 6f 72 20 74 68 6f 73 65 20 77 69 74 |er for those wit| 00001020 68 6f 75 74 20 61 0a 20 7c 20 20 20 20 20 20 20 |hout a. | | 00001030 20 20 20 20 20 20 20 20 7c 20 20 20 20 20 20 20 | | | 00001040 20 20 20 20 20 20 20 56 49 44 43 20 65 6e 68 61 | VIDC enha| 00001050 6e 63 65 72 2e 0a 20 7c 20 20 20 20 20 20 20 20 |ncer.. | | 00001060 20 20 20 20 20 20 20 7c 20 20 20 20 45 6e 68 61 | | Enha| 00001070 6e 63 65 64 20 56 49 44 43 20 48 61 6c 66 0a 20 |nced VIDC Half. | 00001080 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00001090 7c 20 20 20 20 20 20 20 20 20 20 20 2d 20 41 67 || - Ag| 000010a0 61 69 6e 20 66 6f 72 20 70 65 6f 70 6c 65 20 77 |ain for people w| 000010b0 69 74 68 20 56 49 44 43 20 65 6e 68 61 6e 63 65 |ith VIDC enhance| 000010c0 72 73 2e 20 20 54 68 65 20 0a 20 7c 20 20 20 20 |rs. The . | | 000010d0 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 20 | | | 000010e0 20 20 20 20 20 20 20 20 20 20 74 75 6e 65 20 77 | tune w| 000010f0 69 6c 6c 20 62 65 20 61 74 20 6e 6f 72 6d 61 6c |ill be at normal| 00001100 20 70 69 74 63 68 20 66 6f 72 20 74 68 6f 73 65 | pitch for those| 00001110 20 77 69 74 68 0a 20 7c 20 20 20 20 20 20 20 20 | with. | | 00001120 20 20 20 20 20 20 20 7c 20 20 20 20 20 20 20 20 | | | 00001130 20 20 20 20 20 20 61 20 56 49 44 43 20 65 6e 68 | a VIDC enh| 00001140 61 6e 63 65 72 2c 20 61 6e 64 20 64 69 72 65 20 |ancer, and dire | 00001150 66 6f 72 20 74 68 6f 73 65 20 77 69 74 68 6f 75 |for those withou| 00001160 74 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |t. | | 00001170 20 20 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00001180 20 20 61 20 56 49 44 43 20 65 6e 68 61 6e 63 65 | a VIDC enhance| 00001190 72 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |r.. | | 000011a0 20 20 20 20 7c 0a 20 7c 20 20 20 20 20 20 20 20 | |. | | 000011b0 20 20 20 20 20 20 20 7c 0a 20 7c 20 51 75 69 74 | |. | Quit| 000011c0 20 20 20 20 20 20 20 20 20 20 7c 20 2d 20 54 68 | | - Th| 000011d0 69 73 20 6f 70 74 69 6f 6e 20 72 65 6d 6f 76 65 |is option remove| 000011e0 73 20 74 68 65 20 70 72 6f 67 72 61 6d 20 66 72 |s the program fr| 000011f0 6f 6d 20 74 68 65 20 63 6f 6d 70 75 74 65 72 27 |om the computer'| 00001200 73 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |s. | | 00001210 20 20 20 7c 20 20 20 6d 65 6d 6f 72 79 2e 20 20 | | memory. | 00001220 49 74 20 77 69 6c 6c 20 61 73 6b 20 69 66 20 79 |It will ask if y| 00001230 6f 75 20 77 69 73 68 20 74 6f 20 73 74 6f 70 20 |ou wish to stop | 00001240 74 68 65 20 6d 75 73 69 63 2e 0a 20 7c 20 20 20 |the music.. | | 00001250 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00001260 49 66 20 74 68 65 20 61 6e 73 77 65 72 20 74 6f |If the answer to| 00001270 20 74 68 69 73 20 69 73 20 79 65 73 2c 20 74 68 | this is yes, th| 00001280 65 6e 20 74 68 65 20 6d 75 73 69 63 20 77 69 6c |en the music wil| 00001290 6c 20 62 65 0a 20 7c 20 20 20 20 20 20 20 20 20 |l be. | | 000012a0 20 20 20 20 20 20 7c 20 20 20 73 74 6f 70 70 65 | | stoppe| 000012b0 64 2c 20 74 68 65 20 54 72 61 63 6b 65 72 4d 6f |d, the TrackerMo| 000012c0 64 75 6c 65 20 72 65 6d 6f 76 65 64 2c 20 61 6e |dule removed, an| 000012d0 64 20 61 73 20 6d 75 63 68 20 0a 20 7c 20 20 20 |d as much . | | 000012e0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 000012f0 6d 65 6d 6f 72 79 20 61 73 20 70 6f 73 73 69 62 |memory as possib| 00001300 6c 65 20 77 69 6c 6c 20 62 65 20 72 65 6c 65 61 |le will be relea| 00001310 73 65 64 2e 0a 20 2b 2d 2d 2d 2d 2d 2d 2d 2d 2d |sed.. +---------| 00001320 2d 2d 2d 2d 2d 2d 2b 0a 0a 20 2b 2d 2d 2d 2d 2d |------+.. +-----| 00001330 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2b 0a 20 7c 20 4f |----------+. | O| 00001340 70 65 6e 20 57 69 6e 64 6f 77 20 20 20 7c 0a 20 |pen Window |. | 00001350 2b 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d |+---------------| 00001360 2b 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |+. | | 00001370 20 20 20 7c 0a 20 7c 20 43 6f 6e 74 72 6f 6c 20 | |. | Control | 00001380 20 20 20 20 20 20 7c 20 2d 20 54 68 69 73 20 77 | | - This w| 00001390 69 6e 64 6f 77 20 77 69 6c 6c 20 73 74 61 79 20 |indow will stay | 000013a0 6f 6e 20 74 68 65 20 73 63 72 65 65 6e 20 75 6e |on the screen un| 000013b0 74 69 6c 20 69 74 20 69 73 20 0a 20 7c 20 20 20 |til it is . | | 000013c0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 000013d0 65 78 70 6c 69 63 69 74 6c 79 20 63 6c 6f 73 65 |explicitly close| 000013e0 64 2e 20 20 49 74 20 61 6c 6c 6f 77 73 20 63 6f |d. It allows co| 000013f0 6e 74 72 6f 6c 20 6f 76 65 72 20 6d 6f 73 74 20 |ntrol over most | 00001400 6f 66 20 74 68 65 0a 20 7c 20 20 20 20 20 20 20 |of the. | | 00001410 20 20 20 20 20 20 20 20 7c 20 20 20 6d 6f 64 75 | | modu| 00001420 6c 65 73 20 66 75 6e 63 74 69 6f 6e 73 2e 20 20 |les functions. | 00001430 54 68 65 20 74 6f 70 20 72 6f 77 20 6f 66 20 69 |The top row of i| 00001440 63 6f 6e 73 20 61 72 65 20 74 68 65 20 63 6f 6e |cons are the con| 00001450 74 72 6f 6c 0a 20 7c 20 20 20 20 20 20 20 20 20 |trol. | | 00001460 20 20 20 20 20 20 7c 20 20 20 69 63 6f 6e 73 2c | | icons,| 00001470 20 74 68 65 20 6c 6f 77 65 72 20 69 63 6f 6e 73 | the lower icons| 00001480 20 67 69 76 69 6e 67 20 69 6e 66 6f 72 6d 61 74 | giving informat| 00001490 69 6f 6e 2e 20 20 54 68 65 20 63 6f 6e 74 72 6f |ion. The contro| 000014a0 6c 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |l. | | 000014b0 20 20 20 7c 20 20 20 69 63 6f 6e 73 20 61 72 65 | | icons are| 000014c0 20 28 66 72 6f 6d 20 6c 65 66 74 20 74 6f 20 72 | (from left to r| 000014d0 69 67 68 74 29 3a 0a 20 7c 20 20 20 20 20 20 20 |ight):. | | 000014e0 20 20 20 20 20 20 20 20 7c 20 20 20 52 45 56 45 | | REVE| 000014f0 52 53 45 20 2d 20 4d 6f 76 65 73 20 74 6f 20 74 |RSE - Moves to t| 00001500 68 65 20 62 65 67 69 6e 6e 69 6e 67 20 6f 66 20 |he beginning of | 00001510 74 68 65 20 70 72 65 76 69 6f 75 73 20 70 61 74 |the previous pat| 00001520 74 65 72 6e 0a 20 7c 20 20 20 20 20 20 20 20 20 |tern. | | 00001530 20 20 20 20 20 20 7c 20 20 20 53 54 4f 50 20 20 | | STOP | 00001540 20 20 2d 20 53 74 6f 70 73 20 74 68 65 20 63 75 | - Stops the cu| 00001550 72 72 65 6e 74 20 74 75 6e 65 20 26 20 72 65 6c |rrent tune & rel| 00001560 65 61 73 65 73 20 74 68 65 20 6d 65 6d 6f 72 79 |eases the memory| 00001570 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00001580 20 20 7c 20 20 20 50 41 55 53 45 20 20 20 2d 20 | | PAUSE - | 00001590 50 61 75 73 65 73 20 74 68 65 20 63 75 72 72 65 |Pauses the curre| 000015a0 6e 74 20 74 75 6e 65 20 72 65 74 61 69 6e 69 6e |nt tune retainin| 000015b0 67 20 70 6f 73 69 74 69 6f 6e 0a 20 7c 20 20 20 |g position. | | 000015c0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 000015d0 50 4c 41 59 20 20 20 20 2d 20 52 65 73 74 61 72 |PLAY - Restar| 000015e0 74 73 20 74 68 65 20 74 75 6e 65 20 61 66 74 65 |ts the tune afte| 000015f0 72 20 50 41 55 53 45 0a 20 7c 20 20 20 20 20 20 |r PAUSE. | | 00001600 20 20 20 20 20 20 20 20 20 7c 20 20 20 46 4f 52 | | FOR| 00001610 57 41 52 44 20 2d 20 4d 6f 76 65 73 20 74 6f 20 |WARD - Moves to | 00001620 74 68 65 20 62 65 67 69 6e 6e 69 6e 67 20 6f 66 |the beginning of| 00001630 20 74 68 65 20 6e 65 78 74 20 70 61 74 74 65 72 | the next patter| 00001640 6e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |n. | | 00001650 20 20 20 7c 20 20 20 53 50 45 41 4b 45 52 20 2d | | SPEAKER -| 00001660 20 54 6f 67 67 6c 65 73 20 74 68 65 20 69 6e 74 | Toggles the int| 00001670 65 72 6e 61 6c 20 73 70 65 61 6b 65 72 20 6f 6e |ernal speaker on| 00001680 2f 6f 66 66 0a 20 7c 20 20 20 20 20 20 20 20 20 |/off. | | 00001690 20 20 20 20 20 20 7c 20 20 20 54 68 65 20 6e 65 | | The ne| 000016a0 78 74 20 69 63 6f 6e 20 64 6f 77 6e 20 67 69 76 |xt icon down giv| 000016b0 65 73 20 74 68 65 20 6f 76 65 72 61 6c 6c 20 73 |es the overall s| 000016c0 74 61 74 75 73 20 6f 66 20 74 68 65 20 0a 20 7c |tatus of the . || 000016d0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 000016e0 20 20 20 70 72 6f 67 72 61 6d 20 2d 20 53 54 4f | program - STO| 000016f0 50 50 45 44 2c 20 50 41 55 53 45 44 20 6f 72 20 |PPED, PAUSED or | 00001700 50 4c 41 59 49 4e 47 2e 20 20 42 65 6c 6f 77 20 |PLAYING. Below | 00001710 74 68 69 73 20 61 72 65 0a 20 7c 20 20 20 20 20 |this are. | | 00001720 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 74 68 | | th| 00001730 65 20 70 6f 73 69 74 69 6f 6e 20 61 6e 64 20 73 |e position and s| 00001740 70 65 65 64 20 69 63 6f 6e 73 2e 20 20 50 61 74 |peed icons. Pat| 00001750 74 65 72 6e 20 69 73 20 74 68 65 20 63 75 72 72 |tern is the curr| 00001760 65 6e 74 0a 20 7c 20 20 20 20 20 20 20 20 20 20 |ent. | | 00001770 20 20 20 20 20 7c 20 20 20 70 6f 73 69 74 69 6f | | positio| 00001780 6e 20 69 6e 20 74 68 65 20 50 61 74 74 65 72 6e |n in the Pattern| 00001790 20 74 61 62 6c 65 2c 20 61 6e 64 20 50 6f 73 69 | table, and Posi| 000017a0 74 69 6f 6e 20 69 73 20 74 68 65 0a 20 7c 20 20 |tion is the. | | 000017b0 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 | | | 000017c0 20 70 6f 73 69 74 69 6f 6e 20 77 69 74 68 69 6e | position within| 000017d0 20 74 68 69 73 20 50 61 74 74 65 72 6e 2e 20 20 | this Pattern. | 000017e0 53 70 65 65 64 20 73 68 6f 77 73 20 68 6f 77 20 |Speed shows how | 000017f0 71 75 69 63 6b 6c 79 0a 20 7c 20 20 20 20 20 20 |quickly. | | 00001800 20 20 20 20 20 20 20 20 20 7c 20 20 20 69 74 20 | | it | 00001810 6d 6f 76 65 73 20 6f 6e 74 6f 20 61 20 6e 65 77 |moves onto a new| 00001820 20 70 6f 73 69 74 69 6f 6e 2e 20 20 31 20 69 73 | position. 1 is| 00001830 20 66 61 73 74 2c 20 77 69 74 68 20 68 69 67 68 | fast, with high| 00001840 65 72 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |er. | | 00001850 20 20 20 20 7c 20 20 20 6e 75 6d 62 65 72 73 20 | | numbers | 00001860 62 65 69 6e 67 20 73 6c 6f 77 65 72 2e 0a 20 7c |being slower.. || 00001870 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00001880 0a 20 7c 20 4b 65 79 62 6f 61 72 64 20 20 20 20 |. | Keyboard | 00001890 20 20 7c 20 2d 20 54 68 69 73 20 77 69 6e 64 6f | | - This windo| 000018a0 77 20 77 69 6c 6c 20 73 74 61 79 20 6f 6e 20 74 |w will stay on t| 000018b0 68 65 20 73 63 72 65 65 6e 20 75 6e 74 69 6c 20 |he screen until | 000018c0 69 74 20 69 73 20 0a 20 7c 20 20 20 20 20 20 20 |it is . | | 000018d0 20 20 20 20 20 20 20 20 7c 20 20 20 65 78 70 6c | | expl| 000018e0 69 63 69 74 6c 79 20 63 6c 6f 73 65 64 2e 20 20 |icitly closed. | 000018f0 54 68 69 73 20 77 69 6e 64 6f 77 20 73 68 6f 77 |This window show| 00001900 73 20 67 72 61 70 68 69 63 61 6c 6c 79 20 74 68 |s graphically th| 00001910 65 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |e. | | 00001920 20 20 20 7c 20 20 20 70 69 74 63 68 20 6f 66 20 | | pitch of | 00001930 74 68 65 20 6e 6f 74 65 73 20 63 75 72 72 65 6e |the notes curren| 00001940 74 6c 79 20 70 6c 61 79 69 6e 67 2e 20 20 43 68 |tly playing. Ch| 00001950 61 6e 6e 65 6c 20 31 20 75 73 65 73 0a 20 7c 20 |annel 1 uses. | | 00001960 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 | | | 00001970 20 20 63 6f 6c 6f 75 72 20 38 2c 20 63 68 61 6e | colour 8, chan| 00001980 6e 65 6c 20 38 20 75 73 65 73 20 63 6f 6c 6f 75 |nel 8 uses colou| 00001990 72 20 31 35 2c 20 77 69 74 68 20 74 68 65 20 6f |r 15, with the o| 000019a0 74 68 65 72 0a 20 7c 20 20 20 20 20 20 20 20 20 |ther. | | 000019b0 20 20 20 20 20 20 7c 20 20 20 63 68 61 6e 6e 65 | | channe| 000019c0 6c 73 20 75 73 69 6e 67 20 63 6f 6c 6f 75 72 20 |ls using colour | 000019d0 28 63 68 61 6e 6e 65 6c 20 6e 6f 2e 20 2b 20 38 |(channel no. + 8| 000019e0 29 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |).. | | 000019f0 20 20 20 20 7c 20 20 20 49 66 20 61 20 6e 6f 74 | | If a not| 00001a00 65 20 69 73 20 63 6c 69 63 6b 65 64 20 6f 6e 2c |e is clicked on,| 00001a10 20 74 68 65 6e 20 74 68 65 20 50 69 74 63 68 20 | then the Pitch | 00001a20 66 69 65 6c 64 20 69 6e 20 27 50 6c 61 79 0a 20 |field in 'Play. | 00001a30 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00001a40 7c 20 20 20 53 61 6d 70 6c 65 27 20 77 69 6c 6c || Sample' will| 00001a50 20 62 65 20 73 65 74 20 61 63 63 6f 72 64 69 6e | be set accordin| 00001a60 67 6c 79 2c 20 61 6e 64 20 69 66 20 74 68 65 20 |gly, and if the | 00001a70 74 75 6e 65 20 69 73 0a 20 7c 20 20 20 20 20 20 |tune is. | | 00001a80 20 20 20 20 20 20 20 20 20 7c 20 20 20 70 61 75 | | pau| 00001a90 73 65 64 2c 20 74 68 65 6e 20 74 68 65 20 73 61 |sed, then the sa| 00001aa0 6d 70 6c 65 20 77 69 6c 6c 20 62 65 20 70 6c 61 |mple will be pla| 00001ab0 79 65 64 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 |yed.. | | 00001ac0 20 20 20 20 20 20 7c 0a 20 7c 20 47 65 6e 65 72 | |. | Gener| 00001ad0 61 6c 20 49 6e 66 6f 20 20 7c 20 2d 20 54 68 69 |al Info | - Thi| 00001ae0 73 20 77 69 6e 64 6f 77 20 77 69 6c 6c 20 73 74 |s window will st| 00001af0 61 79 20 6f 6e 20 74 68 65 20 73 63 72 65 65 6e |ay on the screen| 00001b00 20 75 6e 74 69 6c 20 69 74 20 69 73 20 0a 20 7c | until it is . || 00001b10 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00001b20 20 20 20 65 78 70 6c 69 63 69 74 6c 79 20 63 6c | explicitly cl| 00001b30 6f 73 65 64 2e 20 20 49 74 20 73 68 6f 77 73 20 |osed. It shows | 00001b40 69 6e 66 6f 72 6d 61 74 69 6f 6e 20 61 62 6f 75 |information abou| 00001b50 74 20 74 68 65 0a 20 7c 20 20 20 20 20 20 20 20 |t the. | | 00001b60 20 20 20 20 20 20 20 7c 20 20 20 63 75 72 72 65 | | curre| 00001b70 6e 74 20 74 75 6e 65 2e 20 20 41 75 74 68 6f 72 |nt tune. Author| 00001b80 20 69 73 20 6f 6e 6c 79 20 66 69 6c 6c 65 64 20 | is only filled | 00001b90 69 6e 20 69 66 20 74 68 65 20 74 75 6e 65 20 69 |in if the tune i| 00001ba0 73 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |s. | | 00001bb0 20 20 20 7c 20 20 20 61 20 54 72 61 63 6b 65 72 | | a Tracker| 00001bc0 20 74 75 6e 65 2e 20 20 50 61 74 74 65 72 6e 73 | tune. Patterns| 00001bd0 20 72 65 6c 61 74 65 73 20 74 6f 20 74 68 65 20 | relates to the | 00001be0 27 50 61 74 74 65 72 6e 73 27 0a 20 7c 20 20 20 |'Patterns'. | | 00001bf0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00001c00 66 69 65 6c 64 20 69 6e 20 43 6f 6e 74 72 6f 6c |field in Control| 00001c10 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |.. | | 00001c20 20 20 20 7c 0a 20 7c 20 53 74 65 72 65 6f 20 53 | |. | Stereo S| 00001c30 65 74 74 69 6e 67 7c 20 2d 20 54 68 69 73 20 77 |etting| - This w| 00001c40 69 6e 64 6f 77 20 77 69 6c 6c 20 73 74 61 79 20 |indow will stay | 00001c50 6f 6e 20 74 68 65 20 73 63 72 65 65 6e 20 75 6e |on the screen un| 00001c60 74 69 6c 20 69 74 20 69 73 20 0a 20 7c 20 20 20 |til it is . | | 00001c70 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00001c80 65 78 70 6c 69 63 69 74 6c 79 20 63 6c 6f 73 65 |explicitly close| 00001c90 64 2e 20 20 54 68 69 73 20 77 69 6e 64 6f 77 20 |d. This window | 00001ca0 61 6c 6c 6f 77 73 20 61 64 6a 75 73 74 6d 65 6e |allows adjustmen| 00001cb0 74 20 6f 66 0a 20 7c 20 20 20 20 20 20 20 20 20 |t of. | | 00001cc0 20 20 20 20 20 20 7c 20 20 20 74 68 65 20 73 74 | | the st| 00001cd0 65 72 65 6f 20 70 6f 73 69 74 69 6f 6e 69 6e 67 |ereo positioning| 00001ce0 20 6f 66 20 74 68 65 20 38 20 73 6f 75 6e 64 20 | of the 8 sound | 00001cf0 63 68 61 6e 6e 65 6c 73 2e 0a 20 7c 20 20 20 20 |channels.. | | 00001d00 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 54 | | T| 00001d10 6f 20 61 64 6a 75 73 74 20 74 68 65 20 70 6f 73 |o adjust the pos| 00001d20 69 74 69 6f 6e 73 2c 20 63 6c 69 63 6b 20 61 6e |itions, click an| 00001d30 79 77 68 65 72 65 20 69 6e 20 74 68 65 20 69 63 |ywhere in the ic| 00001d40 6f 6e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |on. | | 00001d50 20 20 20 20 7c 20 20 20 74 68 61 74 20 68 61 73 | | that has| 00001d60 20 61 20 72 65 64 20 61 72 65 61 20 66 6f 72 20 | a red area for | 00001d70 74 68 65 20 72 65 6c 65 76 61 6e 74 20 63 68 61 |the relevant cha| 00001d80 6e 6e 65 6c 2e 20 20 54 68 65 0a 20 7c 20 20 20 |nnel. The. | | 00001d90 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00001da0 72 65 64 20 62 6c 6f 63 6b 20 77 69 6c 6c 20 6d |red block will m| 00001db0 6f 76 65 20 74 6f 20 74 68 65 20 6e 65 61 72 65 |ove to the neare| 00001dc0 73 74 20 70 6f 73 73 69 62 6c 65 20 70 6f 73 69 |st possible posi| 00001dd0 74 69 6f 6e 2c 0a 20 7c 20 20 20 20 20 20 20 20 |tion,. | | 00001de0 20 20 20 20 20 20 20 7c 20 20 20 61 6e 64 20 74 | | and t| 00001df0 68 65 20 73 74 65 72 65 6f 20 70 6f 73 69 74 69 |he stereo positi| 00001e00 6f 6e 20 6f 66 20 74 68 65 20 63 68 61 6e 6e 65 |on of the channe| 00001e10 6c 20 77 69 6c 6c 20 62 65 20 73 65 74 0a 20 7c |l will be set. || 00001e20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00001e30 20 20 20 61 63 63 6f 72 64 69 6e 67 6c 79 2e 20 | accordingly. | 00001e40 20 54 68 65 20 69 63 6f 6e 20 73 61 79 69 6e 67 | The icon saying| 00001e50 20 27 4f 4e 27 20 63 61 6e 20 62 65 20 74 6f 67 | 'ON' can be tog| 00001e60 67 6c 65 64 0a 20 7c 20 20 20 20 20 20 20 20 20 |gled. | | 00001e70 20 20 20 20 20 20 7c 20 20 20 73 69 6d 70 6c 79 | | simply| 00001e80 20 62 79 20 63 6c 69 63 6b 69 6e 67 20 6f 6e 20 | by clicking on | 00001e90 69 74 2e 20 20 54 68 65 20 69 63 6f 6e 20 77 69 |it. The icon wi| 00001ea0 6c 6c 20 63 68 61 6e 67 65 0a 20 7c 20 20 20 20 |ll change. | | 00001eb0 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 61 | | a| 00001ec0 63 63 6f 72 64 69 6e 67 6c 79 2c 20 61 6e 64 20 |ccordingly, and | 00001ed0 74 68 65 20 73 74 61 74 75 73 20 6f 66 20 74 68 |the status of th| 00001ee0 65 20 63 68 61 6e 6e 65 6c 20 77 69 6c 6c 20 61 |e channel will a| 00001ef0 73 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |s. | | 00001f00 20 20 20 7c 20 20 20 77 65 6c 6c 3a 20 4f 4e 20 | | well: ON | 00001f10 20 2d 20 63 68 61 6e 6e 65 6c 20 73 6f 75 6e 64 | - channel sound| 00001f20 73 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |s. | | 00001f30 20 20 20 7c 20 20 20 20 20 20 20 20 20 4f 46 46 | | OFF| 00001f40 20 2d 20 63 68 61 6e 6e 65 6c 20 69 73 20 6d 75 | - channel is mu| 00001f50 74 65 64 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 |ted.. | | 00001f60 20 20 20 20 20 20 7c 20 20 20 54 68 65 20 70 72 | | The pr| 00001f70 65 73 65 74 73 20 73 65 63 74 69 6f 6e 20 69 6e |esets section in| 00001f80 20 74 68 65 20 6c 6f 77 65 72 20 68 61 6c 66 20 | the lower half | 00001f90 6f 66 20 74 68 65 20 77 69 6e 64 6f 77 0a 20 7c |of the window. || 00001fa0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00001fb0 20 20 20 61 6c 6c 6f 77 73 20 66 6f 72 20 71 75 | allows for qu| 00001fc0 69 63 6b 20 63 68 61 6e 67 69 6e 67 20 6f 66 20 |ick changing of | 00001fd0 74 68 65 20 73 74 65 72 65 6f 20 70 6f 73 69 74 |the stereo posit| 00001fe0 69 6f 6e 69 6e 67 2e 0a 20 7c 20 20 20 20 20 20 |ioning.. | | 00001ff0 20 20 20 20 20 20 20 20 20 7c 20 20 20 42 79 20 | | By | 00002000 63 6c 69 63 6b 69 6e 67 20 6f 6e 20 74 68 65 20 |clicking on the | 00002010 69 63 6f 6e 2c 20 74 68 65 20 70 6f 73 69 74 69 |icon, the positi| 00002020 6f 6e 20 61 6e 64 20 73 74 61 74 75 73 0a 20 7c |on and status. || 00002030 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00002040 20 20 20 6f 66 20 74 68 65 20 63 68 61 6e 6e 65 | of the channe| 00002050 6c 20 77 69 6c 6c 20 62 65 20 61 6c 74 65 72 65 |l will be altere| 00002060 64 20 61 63 63 6f 72 64 69 6e 67 20 74 6f 20 74 |d according to t| 00002070 68 65 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |he. | | 00002080 20 20 20 20 7c 20 20 20 69 63 6f 6e 20 63 6c 69 | | icon cli| 00002090 63 6b 65 64 20 6f 6e 2e 0a 20 7c 20 20 20 20 20 |cked on.. | | 000020a0 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 54 68 | | Th| 000020b0 65 20 62 6f 74 74 6f 6d 20 72 6f 77 20 61 72 65 |e bottom row are| 000020c0 20 75 73 65 72 20 64 65 66 69 6e 61 62 6c 65 2e | user definable.| 000020d0 20 20 53 65 74 20 74 68 65 20 70 6f 73 69 74 69 | Set the positi| 000020e0 6f 6e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |on. | | 000020f0 20 20 20 20 7c 20 20 20 61 6e 64 20 73 74 61 74 | | and stat| 00002100 75 73 20 6f 66 20 74 68 65 20 63 68 61 6e 6e 65 |us of the channe| 00002110 6c 73 2c 20 61 6e 64 20 63 6c 69 63 6b 20 6f 6e |ls, and click on| 00002120 20 74 68 65 20 72 65 64 20 27 52 45 43 27 0a 20 | the red 'REC'. | 00002130 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00002140 7c 20 20 20 69 63 6f 6e 2e 20 20 54 68 65 20 70 || icon. The p| 00002150 6f 73 69 74 69 6f 6e 20 61 6e 64 20 73 74 61 74 |osition and stat| 00002160 75 73 20 6f 66 20 61 6c 6c 20 38 20 63 68 61 6e |us of all 8 chan| 00002170 6e 65 6c 73 20 77 69 6c 6c 0a 20 7c 20 20 20 20 |nels will. | | 00002180 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 62 | | b| 00002190 65 20 72 65 63 6f 72 64 65 64 2c 20 61 6e 64 20 |e recorded, and | 000021a0 63 61 6e 20 62 65 20 72 65 63 61 6c 6c 65 64 20 |can be recalled | 000021b0 6a 75 73 74 20 6c 69 6b 65 20 74 68 65 20 6f 74 |just like the ot| 000021c0 68 65 72 0a 20 7c 20 20 20 20 20 20 20 20 20 20 |her. | | 000021d0 20 20 20 20 20 7c 20 20 20 70 72 65 73 65 74 73 | | presets| 000021e0 2e 20 20 54 68 65 20 62 65 73 74 20 77 61 79 20 |. The best way | 000021f0 74 6f 20 75 6e 64 65 72 73 74 61 6e 64 20 74 68 |to understand th| 00002200 69 73 20 69 73 20 62 79 0a 20 7c 20 20 20 20 20 |is is by. | | 00002210 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 65 78 | | ex| 00002220 70 65 72 69 6d 65 6e 74 61 74 69 6f 6e 2e 0a 20 |perimentation.. | 00002230 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00002240 7c 20 20 20 54 68 65 20 73 6c 69 64 65 72 20 62 || The slider b| 00002250 61 72 20 61 6c 6f 6e 67 20 74 68 65 20 62 6f 74 |ar along the bot| 00002260 74 6f 6d 20 6f 66 20 74 68 65 20 77 69 6e 64 6f |tom of the windo| 00002270 77 20 69 73 20 74 68 65 0a 20 7c 20 20 20 20 20 |w is the. | | 00002280 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 6f 76 | | ov| 00002290 65 72 61 6c 6c 20 76 6f 6c 75 6d 65 20 63 6f 6e |erall volume con| 000022a0 74 72 6f 6c 2e 20 20 43 6c 69 63 6b 69 6e 67 20 |trol. Clicking | 000022b0 6f 6e 20 74 68 65 20 62 61 72 20 77 69 6c 6c 0a |on the bar will.| 000022c0 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 000022d0 20 7c 20 20 20 63 61 75 73 65 20 74 68 65 20 76 | | cause the v| 000022e0 6f 6c 75 6d 65 20 74 6f 20 63 68 61 6e 67 65 20 |olume to change | 000022f0 73 6d 6f 6f 74 68 6c 79 2c 20 74 68 65 20 72 65 |smoothly, the re| 00002300 64 20 62 61 72 0a 20 7c 20 20 20 20 20 20 20 20 |d bar. | | 00002310 20 20 20 20 20 20 20 7c 20 20 20 69 6e 64 69 63 | | indic| 00002320 61 74 69 6e 67 20 74 68 65 20 76 6f 6c 75 6d 65 |ating the volume| 00002330 20 61 74 20 61 6c 6c 20 74 69 6d 65 73 2e 20 20 | at all times. | 00002340 54 68 65 20 74 77 6f 20 69 63 6f 6e 73 2c 0a 20 |The two icons,. | 00002350 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00002360 7c 20 20 20 6d 61 78 20 61 6e 64 20 6d 69 6e 2c || max and min,| 00002370 20 74 61 6b 65 20 74 68 65 20 76 6f 6c 75 6d 65 | take the volume| 00002380 20 28 61 6e 64 20 73 6c 69 64 65 72 29 20 74 6f | (and slider) to| 00002390 20 74 68 65 20 0a 20 7c 20 20 20 20 20 20 20 20 | the . | | 000023a0 20 20 20 20 20 20 20 7c 20 20 20 6d 61 78 69 6d | | maxim| 000023b0 75 6d 20 61 6e 64 20 74 68 65 20 6d 69 6e 69 6d |um and the minim| 000023c0 75 6d 2e 20 20 49 74 20 61 6c 73 6f 20 69 6e 64 |um. It also ind| 000023d0 69 63 61 74 65 73 20 77 68 69 63 68 20 65 6e 64 |icates which end| 000023e0 73 20 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |s . | | 000023f0 20 20 20 20 7c 20 20 20 6f 66 20 74 68 65 20 73 | | of the s| 00002400 6c 69 64 65 72 20 61 72 65 20 6d 61 78 69 6d 75 |lider are maximu| 00002410 6d 20 61 6e 64 20 6d 69 6e 69 6d 75 6d 2e 0a 20 |m and minimum.. | 00002420 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 || | 00002430 7c 0a 20 7c 20 53 6f 75 6e 64 20 44 61 74 61 20 ||. | Sound Data | 00002440 20 20 20 7c 20 2d 20 54 68 69 73 20 77 69 6e 64 | | - This wind| 00002450 6f 77 20 77 69 6c 6c 20 73 74 61 79 20 6f 6e 20 |ow will stay on | 00002460 74 68 65 20 73 63 72 65 65 6e 20 75 6e 74 69 6c |the screen until| 00002470 20 69 74 20 69 73 20 0a 20 7c 20 20 20 20 20 20 | it is . | | 00002480 20 20 20 20 20 20 20 20 20 7c 20 20 20 65 78 70 | | exp| 00002490 6c 69 63 69 74 6c 79 20 63 6c 6f 73 65 64 2e 20 |licitly closed. | 000024a0 20 49 74 20 73 68 6f 77 73 20 69 6e 66 6f 72 6d | It shows inform| 000024b0 61 74 69 6f 6e 20 61 62 6f 75 74 20 77 68 61 74 |ation about what| 000024c0 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 000024d0 20 20 7c 20 20 20 6e 6f 74 65 73 20 61 72 65 20 | | notes are | 000024e0 63 75 72 72 65 6e 74 6c 79 20 73 6f 75 6e 64 69 |currently soundi| 000024f0 6e 67 2e 20 20 53 61 6d 70 6c 65 20 73 68 6f 77 |ng. Sample show| 00002500 73 20 77 68 69 63 68 0a 20 7c 20 20 20 20 20 20 |s which. | | 00002510 20 20 20 20 20 20 20 20 20 7c 20 20 20 73 61 6d | | sam| 00002520 70 6c 65 20 69 73 20 63 75 72 72 65 6e 74 6c 79 |ple is currently| 00002530 20 62 65 69 6e 67 20 75 73 65 64 20 6f 6e 20 74 | being used on t| 00002540 68 65 20 63 68 61 6e 6e 65 6c 20 28 73 65 65 0a |he channel (see.| 00002550 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00002560 20 7c 20 20 20 27 53 61 6d 70 6c 65 20 49 6e 66 | | 'Sample Inf| 00002570 6f 27 20 66 6f 72 20 61 6e 20 65 78 70 6c 61 6e |o' for an explan| 00002580 61 74 69 6f 6e 20 6f 66 20 74 68 65 20 6e 75 6d |ation of the num| 00002590 62 65 72 73 29 2e 0a 20 7c 20 20 20 20 20 20 20 |bers).. | | 000025a0 20 20 20 20 20 20 20 20 7c 20 20 20 56 6f 6c 75 | | Volu| 000025b0 6d 65 20 28 69 6e 20 74 68 65 20 72 61 6e 67 65 |me (in the range| 000025c0 20 30 28 73 69 6c 65 6e 74 29 20 2d 32 35 35 28 | 0(silent) -255(| 000025d0 6c 6f 75 64 29 29 20 69 73 20 66 61 69 72 6c 79 |loud)) is fairly| 000025e0 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 000025f0 20 20 7c 20 20 20 73 65 6c 66 20 65 78 70 6c 61 | | self expla| 00002600 6e 61 74 6f 72 79 2e 20 20 4e 6f 74 65 20 73 68 |natory. Note sh| 00002610 6f 77 73 20 74 68 65 20 70 69 74 63 68 20 6f 66 |ows the pitch of| 00002620 20 74 68 65 20 6e 6f 74 65 0a 20 7c 20 20 20 20 | the note. | | 00002630 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 63 | | c| 00002640 75 72 72 65 6e 74 6c 79 20 62 65 69 6e 67 20 70 |urrently being p| 00002650 6c 61 79 65 64 2e 20 20 54 68 65 20 70 69 74 63 |layed. The pitc| 00002660 68 20 69 73 20 73 68 6f 77 6e 20 6d 6f 72 65 0a |h is shown more.| 00002670 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00002680 20 7c 20 20 20 67 72 61 70 68 69 63 61 6c 6c 79 | | graphically| 00002690 20 69 6e 20 27 4b 65 79 62 6f 61 72 64 27 2e 0a | in 'Keyboard'..| 000026a0 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 000026b0 20 7c 0a 20 7c 20 53 61 6d 70 6c 65 20 49 6e 66 | |. | Sample Inf| 000026c0 6f 20 20 20 7c 20 2d 20 54 68 69 73 20 77 69 6e |o | - This win| 000026d0 64 6f 77 20 77 69 6c 6c 20 73 74 61 79 20 6f 6e |dow will stay on| 000026e0 20 74 68 65 20 73 63 72 65 65 6e 20 75 6e 74 69 | the screen unti| 000026f0 6c 20 69 74 20 69 73 20 0a 20 7c 20 20 20 20 20 |l it is . | | 00002700 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 65 78 | | ex| 00002710 70 6c 69 63 69 74 6c 79 20 63 6c 6f 73 65 64 2e |plicitly closed.| 00002720 20 20 49 74 20 73 68 6f 77 73 20 69 6e 66 6f 72 | It shows infor| 00002730 6d 61 74 69 6f 6e 20 61 62 6f 75 74 20 74 68 65 |mation about the| 00002740 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00002750 20 20 7c 20 20 20 73 61 6d 70 6c 65 73 20 75 73 | | samples us| 00002760 65 64 20 62 79 20 74 68 65 20 74 75 6e 65 2e 20 |ed by the tune. | 00002770 20 54 68 65 20 66 69 72 73 74 20 63 6f 6c 75 6d | The first colum| 00002780 6e 20 69 73 20 74 68 65 0a 20 7c 20 20 20 20 20 |n is the. | | 00002790 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 73 61 | | sa| 000027a0 6d 70 6c 65 20 6e 75 6d 62 65 72 2c 20 74 68 65 |mple number, the| 000027b0 20 73 65 63 6f 6e 64 20 69 73 20 74 68 65 20 73 | second is the s| 000027c0 61 6d 70 6c 65 20 6e 61 6d 65 2e 20 20 54 68 65 |ample name. The| 000027d0 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 000027e0 20 20 7c 20 20 20 74 68 69 72 64 20 63 6f 6c 75 | | third colu| 000027f0 6d 6e 20 69 73 20 74 68 65 20 73 61 6d 70 6c 65 |mn is the sample| 00002800 20 6c 65 6e 67 74 68 20 28 69 6e 20 62 79 74 65 | length (in byte| 00002810 73 29 2e 20 20 54 68 65 0a 20 7c 20 20 20 20 20 |s). The. | | 00002820 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 66 69 | | fi| 00002830 6e 61 6c 20 63 6f 6c 75 6d 6e 20 69 73 20 74 68 |nal column is th| 00002840 65 20 64 65 66 61 75 6c 74 20 76 6f 6c 75 6d 65 |e default volume| 00002850 20 6f 66 20 74 68 65 20 73 61 6d 70 6c 65 2e 0a | of the sample..| 00002860 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00002870 20 7c 20 20 20 42 79 20 63 6c 69 63 6b 69 6e 67 | | By clicking| 00002880 20 69 6e 20 74 68 65 20 6e 61 6d 65 20 63 6f 6c | in the name col| 00002890 75 6d 6e 2c 20 74 68 65 20 73 61 6d 70 6c 65 20 |umn, the sample | 000028a0 63 6c 69 63 6b 65 64 20 6f 6e 0a 20 7c 20 20 20 |clicked on. | | 000028b0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 000028c0 77 69 6c 6c 20 62 65 63 6f 6d 65 20 74 68 65 20 |will become the | 000028d0 63 75 72 72 65 6e 74 20 73 61 6d 70 6c 65 20 66 |current sample f| 000028e0 6f 72 20 27 50 6c 61 79 20 53 61 6d 70 6c 65 27 |or 'Play Sample'| 000028f0 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 |.. | | 00002900 20 20 20 7c 20 20 20 43 6c 69 63 6b 69 6e 67 20 | | Clicking | 00002910 6d 65 6e 75 20 6f 6e 20 74 68 69 73 20 77 69 6e |menu on this win| 00002920 64 6f 77 20 77 69 6c 6c 20 70 6f 70 20 75 70 20 |dow will pop up | 00002930 61 20 6d 65 6e 75 0a 20 7c 20 20 20 20 20 20 20 |a menu. | | 00002940 20 20 20 20 20 20 20 20 7c 20 20 20 61 6c 6c 6f | | allo| 00002950 77 69 6e 67 20 72 61 77 20 73 61 6d 70 6c 65 20 |wing raw sample | 00002960 64 61 74 61 20 74 6f 20 62 65 20 73 61 76 65 64 |data to be saved| 00002970 2e 20 20 54 68 65 20 66 69 72 73 74 20 65 6e 74 |. The first ent| 00002980 72 79 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |ry. | | 00002990 20 20 20 20 7c 20 20 20 6c 65 61 64 73 20 6f 66 | | leads of| 000029a0 66 20 74 6f 20 61 20 73 75 62 6d 65 6e 75 20 69 |f to a submenu i| 000029b0 6e 20 77 68 69 63 68 20 74 68 65 20 6e 75 6d 62 |n which the numb| 000029c0 65 72 20 6f 66 20 74 68 65 20 0a 20 7c 20 20 20 |er of the . | | 000029d0 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 000029e0 73 61 6d 70 6c 65 20 74 6f 20 62 65 20 73 61 76 |sample to be sav| 000029f0 65 64 20 69 73 20 65 6e 74 65 72 65 64 2e 20 20 |ed is entered. | 00002a00 54 68 65 20 73 65 63 6f 6e 64 20 65 6e 74 72 79 |The second entry| 00002a10 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00002a20 20 20 7c 20 20 20 6c 65 61 64 73 20 6f 66 66 20 | | leads off | 00002a30 74 6f 20 61 20 73 61 76 65 20 64 69 61 6c 6f 67 |to a save dialog| 00002a40 75 65 20 62 6f 78 2e 20 20 54 68 65 20 73 61 6d |ue box. The sam| 00002a50 70 6c 65 20 64 61 74 61 0a 20 7c 20 20 20 20 20 |ple data. | | 00002a60 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 63 61 | | ca| 00002a70 6e 20 62 65 20 73 61 76 65 20 69 6e 20 74 68 65 |n be save in the| 00002a80 20 6e 6f 72 6d 61 6c 20 6d 61 6e 6e 65 72 2e 20 | normal manner. | 00002a90 20 54 68 65 20 73 61 76 65 20 73 61 6d 70 6c 65 | The save sample| 00002aa0 20 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 | . | | 00002ab0 20 20 20 7c 20 20 20 64 69 61 6c 6f 67 75 65 20 | | dialogue | 00002ac0 62 6f 78 20 77 69 6c 6c 20 6e 6f 74 20 73 68 6f |box will not sho| 00002ad0 77 20 69 66 20 6e 6f 20 74 75 6e 65 20 69 73 20 |w if no tune is | 00002ae0 6c 6f 61 64 65 64 2e 0a 20 7c 20 20 20 20 20 20 |loaded.. | | 00002af0 20 20 20 20 20 20 20 20 20 7c 0a 20 7c 20 50 6c | |. | Pl| 00002b00 61 79 20 53 61 6d 70 6c 65 20 2d 3e 7c 20 2d 20 |ay Sample ->| - | 00002b10 54 6f 20 6f 70 65 6e 20 74 68 65 20 77 69 6e 64 |To open the wind| 00002b20 6f 77 2c 20 63 6c 69 63 6b 20 6f 6e 20 74 68 65 |ow, click on the| 00002b30 20 50 6c 61 79 20 53 61 6d 70 6c 65 20 65 6e 74 | Play Sample ent| 00002b40 72 79 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 |ry.. | | 00002b50 20 20 20 20 20 7c 20 20 20 54 6f 20 75 73 65 20 | | To use | 00002b60 74 68 65 20 73 75 62 6d 65 6e 75 20 6f 70 74 69 |the submenu opti| 00002b70 6f 6e 73 2c 20 6d 6f 76 65 20 74 68 65 20 6d 6f |ons, move the mo| 00002b80 75 73 65 20 61 63 72 6f 73 73 2e 0a 20 7c 20 20 |use across.. | | 00002b90 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 | | | 00002ba0 20 54 68 69 73 20 77 69 6e 64 6f 77 20 77 69 6c | This window wil| 00002bb0 6c 20 73 74 61 79 20 6f 6e 20 74 68 65 20 73 63 |l stay on the sc| 00002bc0 72 65 65 6e 20 75 6e 74 69 6c 20 69 74 20 69 73 |reen until it is| 00002bd0 20 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 | . | | 00002be0 20 20 20 7c 20 20 20 65 78 70 6c 69 63 69 74 6c | | explicitl| 00002bf0 79 20 63 6c 6f 73 65 64 2e 20 20 54 68 69 73 20 |y closed. This | 00002c00 77 69 6e 64 6f 77 20 61 6c 6c 6f 77 73 20 74 68 |window allows th| 00002c10 65 20 70 6c 61 79 69 6e 67 20 6f 66 0a 20 7c 20 |e playing of. | | 00002c20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 | | | 00002c30 20 20 74 68 65 20 73 61 6d 70 6c 65 73 20 75 73 | the samples us| 00002c40 65 64 20 62 79 20 74 68 65 20 74 75 6e 65 2e 20 |ed by the tune. | 00002c50 20 54 68 65 79 20 63 61 6e 20 6f 6e 6c 79 20 62 | They can only b| 00002c60 65 20 70 6c 61 79 65 64 0a 20 7c 20 20 20 20 20 |e played. | | 00002c70 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 77 68 | | wh| 00002c80 69 6c 65 20 74 68 65 20 74 75 6e 65 20 69 73 20 |ile the tune is | 00002c90 70 61 75 73 65 64 20 28 74 68 65 20 67 72 65 79 |paused (the grey| 00002ca0 20 62 6f 78 20 61 74 20 74 68 65 20 62 6f 74 74 | box at the bott| 00002cb0 6f 6d 20 6f 66 0a 20 7c 20 20 20 20 20 20 20 20 |om of. | | 00002cc0 20 20 20 20 20 20 20 7c 20 20 20 74 68 65 20 77 | | the w| 00002cd0 69 6e 64 6f 77 20 77 69 6c 6c 20 63 68 61 6e 67 |indow will chang| 00002ce0 65 20 74 6f 20 72 65 76 65 61 6c 20 61 20 27 50 |e to reveal a 'P| 00002cf0 6c 61 79 20 53 61 6d 70 6c 65 27 20 69 63 6f 6e |lay Sample' icon| 00002d00 29 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |).. | | 00002d10 20 20 20 20 7c 20 20 20 41 6c 6c 20 6f 66 20 74 | | All of t| 00002d20 68 65 20 66 69 65 6c 64 73 20 61 72 65 20 73 65 |he fields are se| 00002d30 6c 66 20 65 78 70 6c 61 6e 61 74 6f 72 79 20 2d |lf explanatory -| 00002d40 20 63 6c 69 63 6b 20 6f 6e 20 74 68 65 0a 20 7c | click on the. || 00002d50 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00002d60 20 20 20 61 72 72 6f 77 73 20 74 6f 20 63 68 61 | arrows to cha| 00002d70 6e 67 65 20 74 68 65 20 76 61 6c 75 65 2c 20 61 |nge the value, a| 00002d80 6e 64 20 27 50 6c 61 79 20 53 61 6d 70 6c 65 27 |nd 'Play Sample'| 00002d90 20 74 6f 20 70 6c 61 79 0a 20 7c 20 20 20 20 20 | to play. | | 00002da0 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 74 68 | | th| 00002db0 65 20 73 61 6d 70 6c 65 2e 0a 20 7c 20 20 20 20 |e sample.. | | 00002dc0 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 41 | | A| 00002dd0 20 63 6f 75 70 6c 65 20 6f 66 20 69 74 65 6d 73 | couple of items| 00002de0 20 68 61 76 65 20 62 65 65 6e 20 61 64 64 65 64 | have been added| 00002df0 20 74 6f 20 74 6f 20 65 61 73 65 20 74 68 65 0a | to to ease the.| 00002e00 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00002e10 20 7c 20 20 20 70 6c 61 79 69 6e 67 20 6f 66 20 | | playing of | 00002e20 73 61 6d 70 6c 65 73 3a 20 20 0a 20 7c 20 20 20 |samples: . | | 00002e30 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 | | | 00002e40 20 31 29 20 42 79 20 63 6c 69 63 6b 69 6e 67 20 | 1) By clicking | 00002e50 6f 6e 20 74 68 65 20 6e 6f 74 65 73 20 6f 6e 20 |on the notes on | 00002e60 74 68 65 20 6b 65 79 62 6f 61 72 64 2c 20 74 68 |the keyboard, th| 00002e70 65 20 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 |e . | | 00002e80 20 20 20 20 7c 20 20 20 20 20 20 20 50 69 74 63 | | Pitc| 00002e90 68 20 66 69 65 6c 64 20 69 6e 20 74 68 65 20 77 |h field in the w| 00002ea0 69 6e 64 6f 77 20 77 69 6c 6c 20 62 65 20 73 65 |indow will be se| 00002eb0 74 20 74 6f 20 74 6f 20 76 61 6c 75 65 0a 20 7c |t to to value. || 00002ec0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c | || 00002ed0 20 20 20 20 20 20 20 6f 66 20 74 68 65 20 6e 6f | of the no| 00002ee0 74 65 20 63 6c 69 63 6b 65 64 20 6f 6e 2e 20 20 |te clicked on. | 00002ef0 41 64 64 69 74 69 6f 6e 61 6c 6c 79 2c 20 69 66 |Additionally, if| 00002f00 20 74 68 65 20 74 68 65 0a 20 7c 20 20 20 20 20 | the the. | | 00002f10 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 20 20 | | | 00002f20 20 20 4b 65 79 62 6f 61 72 64 20 65 6e 74 72 79 | Keyboard entry| 00002f30 20 6f 6e 20 74 68 65 20 73 75 62 6d 65 6e 75 20 | on the submenu | 00002f40 69 73 20 74 69 63 6b 65 64 2c 20 74 68 65 20 0a |is ticked, the .| 00002f50 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | | 00002f60 20 7c 20 20 20 20 20 20 20 73 61 6d 70 6c 65 20 | | sample | 00002f70 77 69 6c 6c 20 61 6c 73 6f 20 62 65 20 70 6c 61 |will also be pla| 00002f80 79 65 64 2e 0a 20 7c 20 20 20 20 20 20 20 20 20 |yed.. | | 00002f90 20 20 20 20 20 20 7c 20 20 20 20 32 29 20 42 79 | | 2) By| 00002fa0 20 63 6c 69 63 6b 69 6e 67 20 6f 6e 20 74 68 65 | clicking on the| 00002fb0 20 73 61 6d 70 6c 65 20 6e 61 6d 65 20 28 6e 6f | sample name (no| 00002fc0 74 20 6e 75 6d 62 65 72 29 20 69 6e 20 74 68 65 |t number) in the| 00002fd0 0a 20 7c 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | | 00002fe0 20 20 7c 20 20 20 20 20 20 20 73 61 6d 70 6c 65 | | sample| 00002ff0 20 69 6e 66 6f 20 77 69 6e 64 6f 77 2c 20 74 68 | info window, th| 00003000 65 20 73 61 6d 70 6c 65 20 66 69 65 6c 64 20 69 |e sample field i| 00003010 6e 20 74 68 65 20 77 69 6e 64 6f 77 0a 20 7c 20 |n the window. | | 00003020 20 20 20 20 20 20 20 20 20 20 20 20 20 20 7c 20 | | | 00003030 20 20 20 20 20 20 77 69 6c 6c 20 62 65 20 73 65 | will be se| 00003040 74 20 74 6f 20 74 68 65 20 76 61 6c 75 65 20 6f |t to the value o| 00003050 66 20 74 68 65 20 73 61 6d 70 6c 65 20 63 6c 69 |f the sample cli| 00003060 63 6b 65 64 20 6f 6e 2e 0a 20 7c 20 20 20 20 20 |cked on.. | | 00003070 20 20 20 20 20 20 20 20 20 20 7c 20 20 20 20 20 | | | 00003080 20 20 41 64 64 69 74 69 6f 6e 61 6c 6c 79 2c 20 | Additionally, | 00003090 69 66 20 74 68 65 20 53 61 6d 70 6c 65 73 20 65 |if the Samples e| 000030a0 6e 74 72 79 20 6f 6e 20 74 68 65 20 73 75 62 6d |ntry on the subm| 000030b0 65 6e 75 0a 20 7c 20 20 20 20 20 20 20 20 20 20 |enu. | | 000030c0 20 20 20 20 20 7c 20 20 20 20 20 20 20 69 73 20 | | is | 000030d0 74 69 63 6b 65 64 2c 20 74 68 65 6e 20 74 68 65 |ticked, then the| 000030e0 20 73 61 6d 70 6c 65 20 77 69 6c 6c 20 62 65 20 | sample will be | 000030f0 70 6c 61 79 65 64 20 61 73 20 77 65 6c 6c 2e 0a |played as well..| 00003100 20 2b 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d 2d | +--------------| 00003110 2d 2b 0a 0a 0a 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |-+...===========| 00003120 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| * 00003160 3d 0a 0a 20 20 20 20 54 68 69 73 20 70 72 6f 67 |=.. This prog| 00003170 72 61 6d 20 77 61 73 20 77 72 69 74 74 65 6e 20 |ram was written | 00003180 69 6e 20 41 63 6f 72 6e 27 73 20 43 20 28 72 65 |in Acorn's C (re| 00003190 6c 65 61 73 65 20 33 29 20 61 6e 64 20 63 6f 6d |lease 3) and com| 000031a0 70 69 6c 65 64 20 6f 6e 20 61 20 0a 32 6d 65 67 |piled on a .2meg| 000031b0 20 41 33 30 30 30 2e 20 0a 0a 20 20 20 20 49 66 | A3000. .. If| 000031c0 20 61 6e 79 6f 6e 65 20 77 69 73 68 65 73 20 74 | anyone wishes t| 000031d0 6f 20 63 6f 6e 74 61 63 74 20 6d 65 20 28 66 6f |o contact me (fo| 000031e0 72 20 64 6f 6e 61 74 69 6f 6e 73 2c 20 69 64 65 |r donations, ide| 000031f0 61 73 20 66 6f 72 20 6d 6f 64 69 66 69 63 61 74 |as for modificat| 00003200 69 6f 6e 73 2f 0a 65 78 74 65 6e 73 69 6f 6e 73 |ions/.extensions| 00003210 2c 20 72 65 70 6f 72 74 69 6e 67 20 6f 66 20 62 |, reporting of b| 00003220 75 67 73 2c 20 72 65 71 75 65 73 74 73 20 66 6f |ugs, requests fo| 00003230 72 20 73 6f 75 72 63 65 20 63 6f 64 65 2c 20 6d |r source code, m| 00003240 6f 64 69 66 69 63 61 74 69 6f 6e 73 20 65 74 63 |odifications etc| 00003250 29 2c 20 0a 49 20 63 61 6e 20 62 65 20 63 6f 6e |), .I can be con| 00003260 74 61 63 74 65 64 20 61 74 20 74 68 65 20 66 6f |tacted at the fo| 00003270 6c 6c 6f 77 69 6e 67 20 70 6c 61 63 65 73 3a 0a |llowing places:.| 00003280 0a 20 20 20 20 20 20 20 20 53 6e 61 69 6c 20 4d |. Snail M| 00003290 61 69 6c 20 20 20 2d 20 20 57 69 6c 6c 69 61 6d |ail - William| 000032a0 20 44 65 6c 76 65 73 0a 20 20 20 20 20 20 20 20 | Delves. | 000032b0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 000032c0 50 6f 75 6e 64 20 48 6f 75 73 65 2c 0a 20 20 20 |Pound House,. | 000032d0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 000032e0 20 20 20 20 20 50 6f 75 6e 64 20 4c 61 6e 65 2c | Pound Lane,| 000032f0 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | 00003300 20 20 20 20 20 20 20 20 20 48 61 64 6c 65 69 67 | Hadleig| 00003310 68 2c 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 |h,. | 00003320 20 20 20 20 20 20 20 20 20 20 20 53 75 66 66 6f | Suffo| 00003330 6c 6b 2c 0a 20 20 20 20 20 20 20 20 20 20 20 20 |lk,. | 00003340 20 20 20 20 20 20 20 20 20 20 20 20 49 50 37 20 | IP7 | 00003350 35 45 51 2e 0a 0a 20 20 20 20 20 20 20 20 56 69 |5EQ... Vi| 00003360 61 20 4d 6f 64 65 6d 20 20 20 20 2d 20 20 41 72 |a Modem - Ar| 00003370 63 61 64 65 20 42 42 53 20 2d 20 30 38 31 20 36 |cade BBS - 081 6| 00003380 35 34 20 32 32 31 32 20 2d 20 55 73 65 72 4e 61 |54 2212 - UserNa| 00003390 6d 65 3a 20 44 65 6c 65 76 65 73 0a 20 20 20 20 |me: Deleves. | 000033a0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | * 000033d0 55 73 65 72 4e 6f 2e 20 3a 20 23 31 30 32 0a 20 |UserNo. : #102. | 000033e0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | * 00003400 20 20 0a 20 20 20 54 68 69 73 20 70 72 6f 67 72 | . This progr| 00003410 61 6d 20 69 73 20 70 75 62 6c 69 63 20 64 6f 6d |am is public dom| 00003420 61 69 6e 2c 20 61 6e 64 20 74 68 65 72 65 66 6f |ain, and therefo| 00003430 72 65 20 6d 61 79 20 62 65 20 66 72 65 65 6c 79 |re may be freely| 00003440 20 63 6f 70 69 65 64 2e 20 20 41 0a 63 68 61 72 | copied. A.char| 00003450 67 65 20 6d 61 79 20 62 65 20 6d 61 64 65 2c 20 |ge may be made, | 00003460 62 75 74 20 6f 6e 6c 79 20 74 6f 20 63 6f 76 65 |but only to cove| 00003470 72 20 63 6f 73 74 73 20 6f 66 20 6d 65 64 69 61 |r costs of media| 00003480 2c 20 61 64 76 65 72 74 69 73 69 6e 67 20 61 6e |, advertising an| 00003490 64 20 0a 70 6f 73 74 61 67 65 2e 20 20 54 68 69 |d .postage. Thi| 000034a0 73 20 61 70 70 6c 69 63 61 74 69 6f 6e 20 6d 75 |s application mu| 000034b0 73 74 20 62 65 20 64 69 73 74 72 69 62 75 74 65 |st be distribute| 000034c0 64 20 69 6e 20 69 74 73 20 65 6e 74 69 72 65 74 |d in its entiret| 000034d0 79 2c 20 77 69 74 68 20 6e 6f 0a 61 6c 74 65 72 |y, with no.alter| 000034e0 61 74 69 6f 6e 73 20 74 6f 20 61 6e 79 20 6f 66 |ations to any of| 000034f0 20 74 68 65 20 66 69 6c 65 73 2e 20 20 41 6e 79 | the files. Any| 00003500 20 6d 6f 64 69 66 69 63 61 74 69 6f 6e 73 20 6d | modifications m| 00003510 75 73 74 20 62 65 20 73 65 6e 74 20 74 6f 20 6d |ust be sent to m| 00003520 65 0a 61 74 20 74 68 65 20 61 64 64 72 65 73 73 |e.at the address| 00003530 20 61 62 6f 76 65 2e 0a 0a 43 68 61 6e 67 65 73 | above...Changes| 00003540 2e 0a 3d 3d 3d 3d 3d 3d 3d 3d 0a 0a 56 65 72 73 |..========..Vers| 00003550 69 6f 6e 20 20 44 61 74 65 20 20 20 20 20 20 20 |ion Date | 00003560 43 68 61 6e 67 65 0a 0a 76 34 2e 30 31 20 20 20 |Change..v4.01 | 00003570 20 30 31 2d 30 39 2d 39 31 20 20 20 4f 70 65 6e | 01-09-91 Open| 00003580 69 6e 67 20 6f 66 20 77 69 6e 64 6f 77 73 20 6e |ing of windows n| 00003590 6f 77 20 70 75 74 20 6f 6e 74 6f 20 61 20 73 75 |ow put onto a su| 000035a0 62 6d 65 6e 75 2e 0a 0a 76 34 2e 30 32 20 20 20 |bmenu...v4.02 | 000035b0 20 30 35 2d 31 30 2d 39 31 20 20 20 43 68 61 6e | 05-10-91 Chan| 000035c0 67 65 64 20 74 6f 20 61 63 63 6f 6d 6d 6f 64 61 |ged to accommoda| 000035d0 74 65 20 54 72 61 63 6b 65 72 4d 6f 64 75 6c 65 |te TrackerModule| 000035e0 20 76 34 2e 30 34 0a 20 20 20 20 20 20 20 20 20 | v4.04. | 000035f0 20 20 20 20 20 20 20 20 20 20 20 20 20 2d 20 43 | - C| 00003600 68 61 6e 6e 65 6c 20 31 20 6f 66 20 70 6c 61 79 |hannel 1 of play| 00003610 73 61 6d 70 6c 65 20 6e 6f 77 20 77 6f 72 6b 73 |sample now works| 00003620 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | 00003630 20 20 20 20 20 20 20 2d 20 43 68 61 6e 6e 65 6c | - Channel| 00003640 20 6d 75 74 65 20 6e 6f 77 20 75 73 65 73 20 54 | mute now uses T| 00003650 72 61 63 6b 65 72 20 53 57 49 73 0a 20 20 20 20 |racker SWIs. | 00003660 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003670 20 20 2d 20 4e 65 77 20 6d 65 6e 75 20 6f 70 74 | - New menu opt| 00003680 69 6f 6e 20 2d 20 73 61 6d 70 6c 65 20 72 61 74 |ion - sample rat| 00003690 65 2e 20 20 41 6c 6c 6f 77 73 20 70 65 6f 70 6c |e. Allows peopl| 000036a0 65 20 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 |e . | 000036b0 20 20 20 20 20 20 20 20 20 20 20 20 77 69 74 68 | with| 000036c0 20 56 49 44 43 20 65 6e 68 61 6e 63 65 72 73 20 | VIDC enhancers | 000036d0 74 6f 20 68 65 61 72 20 74 68 65 20 74 75 6e 65 |to hear the tune| 000036e0 20 61 74 20 74 68 65 20 70 72 6f 70 65 72 0a 20 | at the proper. | 000036f0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003700 20 20 20 20 20 20 20 20 70 69 74 63 68 2e 20 20 | pitch. | 00003710 48 61 6c 66 20 73 61 6d 70 6c 65 20 72 61 74 65 |Half sample rate| 00003720 20 61 6c 73 6f 20 61 76 61 69 6c 61 62 6c 65 2e | also available.| 00003730 20 44 65 66 61 75 6c 74 20 0a 20 20 20 20 20 20 | Default . | 00003740 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003750 20 20 20 69 73 20 6e 6f 72 6d 61 6c 20 77 69 74 | is normal wit| 00003760 68 20 6e 6f 20 56 49 44 43 20 65 6e 68 61 6e 63 |h no VIDC enhanc| 00003770 65 72 2e 0a 0a 76 34 2e 30 33 20 20 20 20 30 38 |er...v4.03 08| 00003780 2d 31 30 2d 39 31 20 20 20 43 6f 6e 74 72 6f 6c |-10-91 Control| 00003790 2c 20 50 6c 61 79 73 61 6d 70 6c 65 20 61 6e 64 |, Playsample and| 000037a0 20 53 74 65 72 65 6f 20 73 65 74 74 69 6e 67 20 | Stereo setting | 000037b0 77 69 6e 64 6f 77 73 20 6e 6f 77 0a 20 20 20 20 |windows now. | 000037c0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 000037d0 20 63 68 61 6e 67 65 64 20 74 6f 20 33 44 2e 0a | changed to 3D..| 000037e0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 000037f0 20 20 20 20 43 68 61 6e 6e 65 6c 20 30 20 6f 6e | Channel 0 on| 00003800 20 50 6c 61 79 53 61 6d 70 6c 65 20 6d 65 61 6e | PlaySample mean| 00003810 73 20 74 68 61 74 20 74 68 65 20 73 61 6d 70 6c |s that the sampl| 00003820 65 20 69 73 20 70 6c 61 79 65 64 0a 20 20 20 20 |e is played. | 00003830 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003840 20 6f 6e 20 61 6c 6c 20 63 68 61 6e 6e 65 6c 73 | on all channels| 00003850 20 73 69 6d 75 6c 74 61 6e 65 6f 75 73 74 79 2e | simultaneousty.| 00003860 0a 0a 76 34 2e 31 30 20 20 20 20 31 38 2d 31 31 |..v4.10 18-11| 00003870 2d 39 31 20 20 20 43 6f 6d 70 6c 65 74 65 20 72 |-91 Complete r| 00003880 65 2d 77 72 69 74 65 2e 0a 20 20 20 20 20 20 20 |e-write.. | 00003890 20 20 20 20 20 20 20 20 20 20 20 20 20 41 6c 6c | All| 000038a0 20 77 69 6e 64 6f 77 73 20 6e 6f 77 20 27 33 44 | windows now '3D| 000038b0 27 2e 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 |'.. | 000038c0 20 20 20 20 20 20 20 54 75 6e 65 73 20 77 69 6c | Tunes wil| 000038d0 6c 20 6c 6f 61 64 20 70 72 6f 70 65 72 6c 79 20 |l load properly | 000038e0 77 68 65 6e 20 70 72 6f 67 72 61 6d 20 6e 6f 74 |when program not| 000038f0 20 6c 6f 61 64 65 64 2e 0a 20 20 20 20 20 20 20 | loaded.. | 00003900 20 20 20 20 20 20 20 20 20 20 20 20 20 57 69 6c | Wil| 00003910 6c 20 6e 6f 20 6c 6f 6e 67 65 72 20 63 72 61 73 |l no longer cras| 00003920 68 20 77 69 74 68 20 63 65 72 74 61 69 6e 20 74 |h with certain t| 00003930 75 6e 65 73 2e 0a 20 20 20 20 20 20 20 20 20 20 |unes.. | 00003940 20 20 20 20 20 20 20 20 20 20 53 74 65 72 65 6f | Stereo| 00003950 20 73 65 74 74 69 6e 67 20 6e 6f 77 20 6d 75 63 | setting now muc| 00003960 68 20 62 65 74 74 65 72 20 28 70 72 65 73 65 74 |h better (preset| 00003970 73 20 61 64 64 65 64 29 2e 0a 20 20 20 20 20 20 |s added).. | 00003980 20 20 20 20 20 20 20 20 20 20 20 20 20 20 55 73 | Us| 00003990 65 72 20 63 68 6f 69 63 65 20 6f 66 20 77 69 6e |er choice of win| 000039a0 64 6f 77 73 20 6f 70 65 6e 65 64 20 6f 6e 20 69 |dows opened on i| 000039b0 63 6f 6e 20 62 61 72 20 63 6c 69 63 6b 2e 0a 20 |con bar click.. | 000039c0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 000039d0 20 20 20 43 68 61 6e 6e 65 6c 20 30 20 70 6c 61 | Channel 0 pla| 000039e0 79 73 61 6d 70 6c 65 20 6f 70 74 69 6f 6e 20 6e |ysample option n| 000039f0 6f 77 20 77 6f 72 6b 73 2e 0a 20 20 20 20 20 20 |ow works.. | 00003a00 20 20 20 20 20 20 20 20 20 20 20 20 20 20 55 73 | Us| 00003a10 65 72 20 63 68 6f 69 63 65 20 6f 66 20 70 6c 61 |er choice of pla| 00003a20 79 69 6e 67 20 73 61 6d 70 6c 65 20 6f 72 20 6e |ying sample or n| 00003a30 6f 74 20 77 68 65 6e 20 63 6c 69 63 6b 69 6e 67 |ot when clicking| 00003a40 0a 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 |. | 00003a50 20 20 20 20 20 20 6f 6e 20 6b 65 79 62 6f 61 72 | on keyboar| 00003a60 64 20 61 6e 64 20 73 61 6d 70 6c 65 20 77 69 6e |d and sample win| 00003a70 64 6f 77 73 2e 0a 0a 76 34 2e 31 31 20 20 20 20 |dows...v4.11 | 00003a80 32 34 2d 31 31 2d 39 31 20 20 20 41 64 64 65 64 |24-11-91 Added| 00003a90 20 6f 76 65 72 61 6c 6c 20 76 6f 6c 75 6d 65 20 | overall volume | 00003aa0 63 6f 6e 74 72 6f 6c 20 28 75 73 69 6e 67 20 74 |control (using t| 00003ab0 68 65 20 6e 65 77 20 54 72 61 63 6b 65 72 5f 0a |he new Tracker_.| 00003ac0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003ad0 20 20 20 20 20 56 6f 6c 75 6d 65 20 53 57 49 29 | Volume SWI)| 00003ae0 20 74 6f 20 73 74 65 72 65 6f 20 77 69 6e 64 6f | to stereo windo| 00003af0 77 2e 20 20 0a 20 20 20 20 20 20 20 20 20 20 20 |w. . | 00003b00 20 20 20 20 20 20 20 20 20 53 61 6d 70 6c 65 20 | Sample | 00003b10 6c 69 73 74 20 73 68 6f 75 6c 64 20 6e 6f 20 6c |list should no l| 00003b20 6f 6e 67 65 72 20 68 61 76 65 20 73 74 72 61 6e |onger have stran| 00003b30 67 65 20 63 68 61 72 61 63 74 65 72 73 0a 20 20 |ge characters. | 00003b40 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003b50 20 20 20 69 6e 20 65 6d 70 74 79 20 73 6c 6f 74 | in empty slot| 00003b60 73 20 28 77 61 73 20 62 75 67 20 69 6e 20 6d 6f |s (was bug in mo| 00003b70 64 75 6c 65 29 2e 0a 20 20 20 20 20 20 20 20 20 |dule).. | 00003b80 20 20 20 20 20 20 20 20 20 20 20 4e 6f 77 20 72 | Now r| 00003b90 65 71 75 69 72 65 73 20 76 34 2e 30 35 20 6f 66 |equires v4.05 of| 00003ba0 20 54 72 61 63 6b 65 72 4d 6f 64 75 6c 65 2e 0a | TrackerModule..| 00003bb0 0a 76 34 2e 31 32 20 20 20 20 20 33 30 2d 31 31 |.v4.12 30-11| 00003bc0 2d 39 31 20 20 56 61 72 69 6f 75 73 20 6d 69 6e |-91 Various min| 00003bd0 6f 72 20 62 75 67 73 20 66 69 78 65 64 20 28 69 |or bugs fixed (i| 00003be0 6e 63 6c 75 64 69 6e 67 20 6f 76 65 72 61 6c 6c |ncluding overall| 00003bf0 20 76 6f 6c 75 6d 65 29 0a 0a 76 34 2e 31 33 20 | volume)..v4.13 | 00003c00 20 20 20 20 32 34 2d 31 31 2d 39 32 20 20 57 69 | 24-11-92 Wi| 00003c10 6e 64 6f 77 20 73 74 72 75 63 74 75 72 65 73 20 |ndow structures | 00003c20 6e 6f 77 20 63 72 65 61 74 65 64 20 6f 6e 6c 79 |now created only| 00003c30 20 77 68 65 6e 20 72 65 71 75 65 73 74 65 64 0a | when requested.| 00003c40 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003c50 20 20 20 20 20 2d 20 73 68 6f 75 6c 64 20 61 6c | - should al| 00003c60 6c 6f 77 20 66 6f 72 20 6d 6f 72 65 20 70 72 6f |low for more pro| 00003c70 67 72 61 6d 73 20 74 6f 20 72 75 6e 20 77 69 74 |grams to run wit| 00003c80 68 20 53 54 72 61 63 6b 65 72 0a 20 20 20 20 20 |h STracker. | 00003c90 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 53 | S| 00003ca0 61 76 65 20 72 61 77 20 73 61 6d 70 6c 65 20 64 |ave raw sample d| 00003cb0 61 74 61 20 6d 65 6e 75 20 61 64 64 65 64 2e 0a |ata menu added..| 00003cc0 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 20 | | 00003cd0 20 20 20 20 4e 6f 77 20 72 65 71 75 69 72 65 73 | Now requires| 00003ce0 20 76 34 2e 30 36 20 6f 66 20 54 72 61 63 6b 65 | v4.06 of Tracke| 00003cf0 72 4d 6f 64 75 6c 65 2e 0a |rModule..| 00003cf9
!STracker/!Help.m0
!STracker/!Help.m1
!STracker/!Help.m2
!STracker/!Help.m4
!STracker/!Help.m5
.
