MM1
This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.
Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.
| Tape/disk: | Home » Personal collection » Acorn ADFS disks » Electron_User_Group » EUG_10.ADF |
| Filename: | MM1 |
| Read OK: | ✔ |
| File size: | 172A bytes |
| Load address: | FFFF1D00 |
| Exec address: | FFFF8023 |
File contents
10REM ***************************
20REM Print Electron Memory Map
30REM by R.A.Dimond February 1993
40REM ***************************
50REM Pages 0 and 1
60MODE6
70PRINTTAB(6,1)"Memory Map 1 (Pages Zero & 1)"
80PRINT'"Screen or Printer? (S/P)"
90REPEATUNTILINKEY-82 ORINKEY-56
100IFINKEY-82 MODE3:VDU14 ELSEMODE3:VDU15,2,1,27,1,54,1,27,1,116,1,1
110PRINTTAB(0);CHR$201;STRING$(68,CHR$205);CHR$187
120PROCprintct("ELECTRON MEMORY MAP - Zero Page")
130PRINTCHR$199;STRING$(13,CHR$196);CHR$194;STRING$(54,CHR$196);CHR$182
140PROCprint(" Address","Use")
150PRINTCHR$199;STRING$(13,CHR$196);CHR$197;STRING$(54,CHR$196);CHR$182
160PROCprint(" &00/&01","LOMEM")
170PROCprint(" &02/&03","Heap pointer - top of variable stack")
180PROCprint(" &04/&05","Basic stack pointer")
190PROCprint(" &06/&07","HIMEM")
200PROCprint(" &08/&09","ERL")
210PROCprint(" &0A","PTRA offset - index to current statement")
220PROCprint(" &0B/&0C","PTRA base - pointer to start of current statement")
230PROCprint(" &0D-&11","Pseudo random number for RND")
240PROCprint(" &12/&13","TOP")
250PROCprint(" &14","Size of print field")
260PROCprint(" &15","Hex print flag")
270PROCprint(" &16/&17","ON ERROR pointer")
280PROCprint(" &18","High byte of PAGE - low byte assumed to be zero")
290PROCprint(" &19/&1A","PTRB base -start of current expression")
300PROCprint(" &1B","PTRB offset - index to current expression")
310PROCprint(" &1C/&1D","Pointer to next DATA item")
320PROCprint(" &1E","COUNT value")
330PROCprint(" &1F","LISTO option")
340PROCprint(""," Bit0 - space after line number")
350PROCprint(""," Bit1 - indent FORs")
360PROCprint(""," Bit2 - indent REPEATs")
370PROCprint(" &20","TRACE flag")
380PROCprint(" &21/&22","Maximum TRACE line number")
390PROCprint(" &23","WIDTH")
400PROCprint(" &24","REPEAT/UNTIL loop depth counter")
410PROCprint(" &25","GOSUB depth counter")
420PROCprint(" &26","FOR/NEXT loop depth counter")
430PROCprint(" &28","OPT assembler value:")
440PROCprint(""," Bit0 - Produce listing")
450PROCprint(""," Bit1 - give errors")
460PROCprint(""," Bit2 - relocate")
470PROCprint(" &2A-&2D","IntA - workspace for integer calculations")
480PROCprint(" &2E-&35","FPA - workspace for floating point calculations")
490PROCprint(" &36","StrA - length of string at &600")
500PROCprint(" &3B-&42","FPB - workspace for floating point calculations")
510PROCprint(" &4F-&8F","Not used")
520PROCprint(" &90-/&9F","Econet - not available on the Electron")
530PROCprint("","so won't be used")
540PROCprint(" &A0-&A7","NMI workspace - used by disc systems")
550PROCprint("","free if cassette only")
560PROCprint(" &A8/&AF","Used by star commands, free if none used")
570PROCprint(" &B0-&BF","Filing system workspace")
580PROCprint(" &C0-&CF","Used by currnetly active filing system")
590PROCprint(" &D0","VDU status byte:")
600PROCprint(""," Bit0 - Printer output status")
610PROCprint(""," Bit1 - Scrolling disabled")
620PROCprint(""," Bit2 - Paged mode selected")
630PROCprint(""," Bit3 - Software scroll")
640PROCprint(""," Bit4 - Not uesd")
650PROCprint(""," Bit5 - VDU5 enabled")
660PROCprint(""," Bit6 - Cursor split status")
670PROCprint(""," Bit7 - VDU disable status")
680PROCprint(" &D1","Mask for current graphics point")
690PRINTCHR$200;STRING$(13,CHR$205);CHR$207;STRING$(54,CHR$205);CHR$188
700PRINT'
710PRINTCHR$201;STRING$(68,CHR$205);CHR$187
720PROCprintct("ELECTRON MEMORY MAP - Zero Page (contd)")
730PRINTCHR$199;STRING$(13,CHR$196);CHR$194;STRING$(54,CHR$196);CHR$182
740PROCprint(" Address","Use")
750PRINTCHR$199;STRING$(13,CHR$196);CHR$197;STRING$(54,CHR$196);CHR$182
760PROCprint(" &D2/&D3","Text colour bytes to be ORed and EORed into memory")
770PROCprint(" &D4/&D5","Graphics colour bytes to be ORed and EORed")
780PROCprint("","into memory")
790PROCprint(" &D6/&D7","Address of current graphics character cell")
800PROCprint(" &D8/&D9","Address of current text character cell")
810PROCprint(" &DA-&DF","Temporary workspace")
820PROCprint(" &E0/&E1","Not used")
830PROCprint(" &E2","Cassette filing system status byte:")
840PROCprint(""," Bit0 - Input file open")
850PROCprint(""," Bit1 - Output file open")
860PROCprint(""," Bit2 - Not used")
870PROCprint(""," Bit3 - Set if cataloguing")
880PROCprint(""," Bit4 - Not used")
890PROCprint(""," Bit5 - Not used")
900PROCprint(""," Bit6 - At end of file?")
910PROCprint(""," Bit7 - End of file warning given?")
920PROCprint(" &E3","Cassette *OPT options in low nibble")
930PROCprint(" &E4-&E6","Operating system workspace")
940PROCprint(" &E7","Auto repeat countdown timer")
950PROCprint(" &E8/&E9","Address of input buffer - used by osword 0")
960PROCprint(" &EA","RS423 timeout counter, free if no RS423")
970PROCprint(" &EB","Used by cassette system")
980PROCprint(" &EC","Internal key number of last key pressed")
990PROCprint(" &ED","Internal key number of first key if")
1000PROCprint("","more than one pressed")
1010PROCprint(" &EE","Internal key number of key to be ignored")
1020PROCprint(" &EF","Copy of A register of last osbyte or osword")
1030PROCprint(" &F0","Copy of X register of last osbyte or osword")
1040PROCprint(" &F1","Copy of Y register of last osbyte or osword")
1050PROCprint(" &F2/&F3","Text pointer to star commands and filenames")
1060PROCprint(" &F4","Number of currently selected rom")
1070PROCprint(" &F5-&F9","Not used")
1080PROCprint(" &FA/&FB","Operating system workspace")
1090PROCprint(" &FC","Copy of A register at last interrupt")
1100PROCprint(" &FD/&FE","Points to byte after last BRK or")
1110PROCprint("","language version string")
1120PROCprint(" &FF","Escape flag")
1130PRINTCHR$200;STRING$(13,CHR$205);CHR$207;STRING$(54,CHR$205);CHR$188
1140PRINT
1150PRINTCHR$201;STRING$(68,CHR$205);CHR$187
1160PROCprintct("ELECTRON MEMORY MAP - Page 1")
1170PRINTCHR$199;STRING$(13,CHR$196);CHR$194;STRING$(54,CHR$196);CHR$182
1180PROCprint(" Address","Use")
1190PRINTCHR$199;STRING$(13,CHR$196);CHR$197;STRING$(54,CHR$196);CHR$182
1200PROCprint(" &100/&1FF","6502 stack - stacks from &1FF downwards")
1210PROCprint("","Lower half may be used as scratch pad")
1220PROCprint("","Paged ROM service routines may use the bottom")
1230PROCprint("","to store error messages")
1240PRINTCHR$200;STRING$(13,CHR$205);CHR$207;STRING$(54,CHR$205);CHR$188
1250PRINT
1260VDU3
1261PRINT''"PLEASE PRESS <F> FOR NEXT FILE, <M> FOR MAIN MENU"
1262REPEAT:UNTIL GET$="F" OR GET$="M"
1263IF GET$="F" THEN CHAIN"$.MM2"
1264IF GET$="M" THEN CHAIN"$.MENU"
1270END
1280DEFPROCprintct(t$):PRINTCHR$186;TAB(68/2-LENt$/2);t$;TAB(69);CHR$186:ENDPROC
1290DEFPROCprint(a$,b$):PRINTCHR$186;TAB(2)a$;TAB(14);CHR$179;TAB(16);b$;TAB(69);CHR$186:ENDPROC
!� ***************************
� Print Electron Memory Map
!� by R.A.Dimond February 1993
(!� ***************************
2� Pages 0 and 1
<�6
F)�6,1)"Memory Map 1 (Pages Zero & 1)"
P �'"Screen or Printer? (S/P)"
Z���-82 ��-56
d3�-82 �3:�14 ��3:�15,2,1,27,1,54,1,27,1,116,1,1
n �0);�201;�68,�205);�187
x/�printct("ELECTRON MEMORY MAP - Zero Page")
�'�199;�13,�196);�194;�54,�196);�182
� �print(" Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
� �print(" &00/&01","LOMEM")
�>�print(" &02/&03","Heap pointer - top of variable stack")
�-�print(" &04/&05","Basic stack pointer")
� �print(" &06/&07","HIMEM")
� �print(" &08/&09","ERL")
�>�print(" &0A","PTRA offset - index to current statement")
�K�print(" &0B/&0C","PTRA base - pointer to start of current statement")
�6�print(" &0D-&11","Pseudo random number for RND")
� �print(" &12/&13","TOP")
�)�print(" &14","Size of print field")
$�print(" &15","Hex print flag")
*�print(" &16/&17","ON ERROR pointer")
E�print(" &18","High byte of PAGE - low byte assumed to be zero")
"@�print(" &19/&1A","PTRB base -start of current expression")
,?�print(" &1B","PTRB offset - index to current expression")
63�print(" &1C/&1D","Pointer to next DATA item")
@!�print(" &1E","COUNT value")
J"�print(" &1F","LISTO option")
T2�print(""," Bit0 - space after line number")
^&�print(""," Bit1 - indent FORs")
h)�print(""," Bit2 - indent REPEATs")
r �print(" &20","TRACE flag")
|3�print(" &21/&22","Maximum TRACE line number")
��print(" &23","WIDTH")
�5�print(" &24","REPEAT/UNTIL loop depth counter")
�)�print(" &25","GOSUB depth counter")
�1�print(" &26","FOR/NEXT loop depth counter")
�*�print(" &28","OPT assembler value:")
�*�print(""," Bit0 - Produce listing")
�&�print(""," Bit1 - give errors")
�#�print(""," Bit2 - relocate")
�C�print(" &2A-&2D","IntA - workspace for integer calculations")
�I�print(" &2E-&35","FPA - workspace for floating point calculations")
�5�print(" &36","StrA - length of string at &600")
�I�print(" &3B-&42","FPB - workspace for floating point calculations")
�"�print(" &4F-&8F","Not used")
A�print(" &90-/&9F","Econet - not available on the Electron")
!�print("","so won't be used")
>�print(" &A0-&A7","NMI workspace - used by disc systems")
&&�print("","free if cassette only")
0B�print(" &A8/&AF","Used by star commands, free if none used")
:1�print(" &B0-&BF","Filing system workspace")
D@�print(" &C0-&CF","Used by currnetly active filing system")
N&�print(" &D0","VDU status byte:")
X4�print(""," Bit0 - Printer output status")
b1�print(""," Bit1 - Scrolling disabled")
l2�print(""," Bit2 - Paged mode selected")
v.�print(""," Bit3 - Software scroll")
�'�print(""," Bit4 - Not uesd")
�+�print(""," Bit5 - VDU5 enabled")
�2�print(""," Bit6 - Cursor split status")
�1�print(""," Bit7 - VDU disable status")
�5�print(" &D1","Mask for current graphics point")
�'�200;�13,�205);�207;�54,�205);�188
��'
��201;�68,�205);�187
�7�printct("ELECTRON MEMORY MAP - Zero Page (contd)")
�'�199;�13,�196);�194;�54,�196);�182
� �print(" Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�L�print(" &D2/&D3","Text colour bytes to be ORed and EORed into memory")
D�print(" &D4/&D5","Graphics colour bytes to be ORed and EORed")
�print("","into memory")
D�print(" &D6/&D7","Address of current graphics character cell")
@�print(" &D8/&D9","Address of current text character cell")
*-�print(" &DA-&DF","Temporary workspace")
4"�print(" &E0/&E1","Not used")
>9�print(" &E2","Cassette filing system status byte:")
H/�print(""," Bit0 - Input file open")
R0�print(""," Bit1 - Output file open")
\(�print(""," Bit2 - Not used")
f2�print(""," Bit3 - Set if cataloguing")
p(�print(""," Bit4 - Not used")
z(�print(""," Bit5 - Not used")
�/�print(""," Bit6 - At end of file?")
�:�print(""," Bit7 - End of file warning given?")
�9�print(" &E3","Cassette *OPT options in low nibble")
�4�print(" &E4-&E6","Operating system workspace")
�1�print(" &E7","Auto repeat countdown timer")
�D�print(" &E8/&E9","Address of input buffer - used by osword 0")
�=�print(" &EA","RS423 timeout counter, free if no RS423")
�-�print(" &EB","Used by cassette system")
�=�print(" &EC","Internal key number of last key pressed")
�9�print(" &ED","Internal key number of first key if")
�&�print("","more than one pressed")
�>�print(" &EE","Internal key number of key to be ignored")
�A�print(" &EF","Copy of A register of last osbyte or osword")
A�print(" &F0","Copy of X register of last osbyte or osword")
A�print(" &F1","Copy of Y register of last osbyte or osword")
E�print(" &F2/&F3","Text pointer to star commands and filenames")
$6�print(" &F4","Number of currently selected rom")
."�print(" &F5-&F9","Not used")
84�print(" &FA/&FB","Operating system workspace")
B:�print(" &FC","Copy of A register at last interrupt")
L:�print(" &FD/&FE","Points to byte after last BRK or")
V(�print("","language version string")
`!�print(" &FF","Escape flag")
j'�200;�13,�205);�207;�54,�205);�188
t�
~�201;�68,�205);�187
�,�printct("ELECTRON MEMORY MAP - Page 1")
�'�199;�13,�196);�194;�54,�196);�182
� �print(" Address","Use")
�'�199;�13,�196);�197;�54,�196);�182
�B�print(" &100/&1FF","6502 stack - stacks from &1FF downwards")
�6�print("","Lower half may be used as scratch pad")
�>�print("","Paged ROM service routines may use the bottom")
�(�print("","to store error messages")
�'�200;�13,�205);�207;�54,�205);�188
��
��3
�:�''"PLEASE PRESS <F> FOR NEXT FILE, <M> FOR MAIN MENU"
��:� �="F" � �="M"
�� �="F" � �"$.MM2"
�� �="M" � �"$.MENU"
��
3��printct(t$):�186;�68/2-�t$/2);t$;�69);�186:�
<��print(a$,b$):�186;�2)a$;�14);�179;�16);b$;�69);�186:�
� 00000000 0d 00 0a 21 f4 20 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a |...!. **********|
00000010 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a |****************|
00000020 2a 0d 00 14 1f f4 20 50 72 69 6e 74 20 45 6c 65 |*..... Print Ele|
00000030 63 74 72 6f 6e 20 4d 65 6d 6f 72 79 20 4d 61 70 |ctron Memory Map|
00000040 0d 00 1e 21 f4 20 62 79 20 52 2e 41 2e 44 69 6d |...!. by R.A.Dim|
00000050 6f 6e 64 20 46 65 62 72 75 61 72 79 20 31 39 39 |ond February 199|
00000060 33 0d 00 28 21 f4 20 2a 2a 2a 2a 2a 2a 2a 2a 2a |3..(!. *********|
00000070 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a 2a |****************|
00000080 2a 2a 0d 00 32 13 f4 20 50 61 67 65 73 20 30 20 |**..2.. Pages 0 |
00000090 61 6e 64 20 31 0d 00 3c 06 eb 36 0d 00 46 29 f1 |and 1..<..6..F).|
000000a0 8a 36 2c 31 29 22 4d 65 6d 6f 72 79 20 4d 61 70 |.6,1)"Memory Map|
000000b0 20 31 20 28 50 61 67 65 73 20 5a 65 72 6f 20 26 | 1 (Pages Zero &|
000000c0 20 31 29 22 0d 00 50 20 f1 27 22 53 63 72 65 65 | 1)"..P .'"Scree|
000000d0 6e 20 6f 72 20 50 72 69 6e 74 65 72 3f 20 28 53 |n or Printer? (S|
000000e0 2f 50 29 22 0d 00 5a 10 f5 fd a6 2d 38 32 20 84 |/P)"..Z....-82 .|
000000f0 a6 2d 35 36 0d 00 64 33 e7 a6 2d 38 32 20 eb 33 |.-56..d3..-82 .3|
00000100 3a ef 31 34 20 8b eb 33 3a ef 31 35 2c 32 2c 31 |:.14 ..3:.15,2,1|
00000110 2c 32 37 2c 31 2c 35 34 2c 31 2c 32 37 2c 31 2c |,27,1,54,1,27,1,|
00000120 31 31 36 2c 31 2c 31 0d 00 6e 1c f1 8a 30 29 3b |116,1,1..n...0);|
00000130 bd 32 30 31 3b c4 36 38 2c bd 32 30 35 29 3b bd |.201;.68,.205);.|
00000140 31 38 37 0d 00 78 2f f2 70 72 69 6e 74 63 74 28 |187..x/.printct(|
00000150 22 45 4c 45 43 54 52 4f 4e 20 4d 45 4d 4f 52 59 |"ELECTRON MEMORY|
00000160 20 4d 41 50 20 2d 20 5a 65 72 6f 20 50 61 67 65 | MAP - Zero Page|
00000170 22 29 0d 00 82 27 f1 bd 31 39 39 3b c4 31 33 2c |")...'..199;.13,|
00000180 bd 31 39 36 29 3b bd 31 39 34 3b c4 35 34 2c bd |.196);.194;.54,.|
00000190 31 39 36 29 3b bd 31 38 32 0d 00 8c 1d f2 70 72 |196);.182.....pr|
000001a0 69 6e 74 28 22 20 20 41 64 64 72 65 73 73 22 2c |int(" Address",|
000001b0 22 55 73 65 22 29 0d 00 96 27 f1 bd 31 39 39 3b |"Use")...'..199;|
000001c0 c4 31 33 2c bd 31 39 36 29 3b bd 31 39 37 3b c4 |.13,.196);.197;.|
000001d0 35 34 2c bd 31 39 36 29 3b bd 31 38 32 0d 00 a0 |54,.196);.182...|
000001e0 1f f2 70 72 69 6e 74 28 22 20 20 26 30 30 2f 26 |..print(" &00/&|
000001f0 30 31 22 2c 22 4c 4f 4d 45 4d 22 29 0d 00 aa 3e |01","LOMEM")...>|
00000200 f2 70 72 69 6e 74 28 22 20 20 26 30 32 2f 26 30 |.print(" &02/&0|
00000210 33 22 2c 22 48 65 61 70 20 70 6f 69 6e 74 65 72 |3","Heap pointer|
00000220 20 2d 20 74 6f 70 20 6f 66 20 76 61 72 69 61 62 | - top of variab|
00000230 6c 65 20 73 74 61 63 6b 22 29 0d 00 b4 2d f2 70 |le stack")...-.p|
00000240 72 69 6e 74 28 22 20 20 26 30 34 2f 26 30 35 22 |rint(" &04/&05"|
00000250 2c 22 42 61 73 69 63 20 73 74 61 63 6b 20 70 6f |,"Basic stack po|
00000260 69 6e 74 65 72 22 29 0d 00 be 1f f2 70 72 69 6e |inter").....prin|
00000270 74 28 22 20 20 26 30 36 2f 26 30 37 22 2c 22 48 |t(" &06/&07","H|
00000280 49 4d 45 4d 22 29 0d 00 c8 1d f2 70 72 69 6e 74 |IMEM").....print|
00000290 28 22 20 20 26 30 38 2f 26 30 39 22 2c 22 45 52 |(" &08/&09","ER|
000002a0 4c 22 29 0d 00 d2 3e f2 70 72 69 6e 74 28 22 20 |L")...>.print(" |
000002b0 20 26 30 41 22 2c 22 50 54 52 41 20 6f 66 66 73 | &0A","PTRA offs|
000002c0 65 74 20 2d 20 69 6e 64 65 78 20 74 6f 20 63 75 |et - index to cu|
000002d0 72 72 65 6e 74 20 73 74 61 74 65 6d 65 6e 74 22 |rrent statement"|
000002e0 29 0d 00 dc 4b f2 70 72 69 6e 74 28 22 20 20 26 |)...K.print(" &|
000002f0 30 42 2f 26 30 43 22 2c 22 50 54 52 41 20 62 61 |0B/&0C","PTRA ba|
00000300 73 65 20 2d 20 70 6f 69 6e 74 65 72 20 74 6f 20 |se - pointer to |
00000310 73 74 61 72 74 20 6f 66 20 63 75 72 72 65 6e 74 |start of current|
00000320 20 73 74 61 74 65 6d 65 6e 74 22 29 0d 00 e6 36 | statement")...6|
00000330 f2 70 72 69 6e 74 28 22 20 20 26 30 44 2d 26 31 |.print(" &0D-&1|
00000340 31 22 2c 22 50 73 65 75 64 6f 20 72 61 6e 64 6f |1","Pseudo rando|
00000350 6d 20 6e 75 6d 62 65 72 20 66 6f 72 20 52 4e 44 |m number for RND|
00000360 22 29 0d 00 f0 1d f2 70 72 69 6e 74 28 22 20 20 |").....print(" |
00000370 26 31 32 2f 26 31 33 22 2c 22 54 4f 50 22 29 0d |&12/&13","TOP").|
00000380 00 fa 29 f2 70 72 69 6e 74 28 22 20 20 26 31 34 |..).print(" &14|
00000390 22 2c 22 53 69 7a 65 20 6f 66 20 70 72 69 6e 74 |","Size of print|
000003a0 20 66 69 65 6c 64 22 29 0d 01 04 24 f2 70 72 69 | field")...$.pri|
000003b0 6e 74 28 22 20 20 26 31 35 22 2c 22 48 65 78 20 |nt(" &15","Hex |
000003c0 70 72 69 6e 74 20 66 6c 61 67 22 29 0d 01 0e 2a |print flag")...*|
000003d0 f2 70 72 69 6e 74 28 22 20 20 26 31 36 2f 26 31 |.print(" &16/&1|
000003e0 37 22 2c 22 4f 4e 20 45 52 52 4f 52 20 70 6f 69 |7","ON ERROR poi|
000003f0 6e 74 65 72 22 29 0d 01 18 45 f2 70 72 69 6e 74 |nter")...E.print|
00000400 28 22 20 20 26 31 38 22 2c 22 48 69 67 68 20 62 |(" &18","High b|
00000410 79 74 65 20 6f 66 20 50 41 47 45 20 2d 20 6c 6f |yte of PAGE - lo|
00000420 77 20 62 79 74 65 20 61 73 73 75 6d 65 64 20 74 |w byte assumed t|
00000430 6f 20 62 65 20 7a 65 72 6f 22 29 0d 01 22 40 f2 |o be zero").."@.|
00000440 70 72 69 6e 74 28 22 20 20 26 31 39 2f 26 31 41 |print(" &19/&1A|
00000450 22 2c 22 50 54 52 42 20 62 61 73 65 20 2d 73 74 |","PTRB base -st|
00000460 61 72 74 20 6f 66 20 63 75 72 72 65 6e 74 20 65 |art of current e|
00000470 78 70 72 65 73 73 69 6f 6e 22 29 0d 01 2c 3f f2 |xpression")..,?.|
00000480 70 72 69 6e 74 28 22 20 20 26 31 42 22 2c 22 50 |print(" &1B","P|
00000490 54 52 42 20 6f 66 66 73 65 74 20 2d 20 69 6e 64 |TRB offset - ind|
000004a0 65 78 20 74 6f 20 63 75 72 72 65 6e 74 20 65 78 |ex to current ex|
000004b0 70 72 65 73 73 69 6f 6e 22 29 0d 01 36 33 f2 70 |pression")..63.p|
000004c0 72 69 6e 74 28 22 20 20 26 31 43 2f 26 31 44 22 |rint(" &1C/&1D"|
000004d0 2c 22 50 6f 69 6e 74 65 72 20 74 6f 20 6e 65 78 |,"Pointer to nex|
000004e0 74 20 44 41 54 41 20 69 74 65 6d 22 29 0d 01 40 |t DATA item")..@|
000004f0 21 f2 70 72 69 6e 74 28 22 20 20 26 31 45 22 2c |!.print(" &1E",|
00000500 22 43 4f 55 4e 54 20 76 61 6c 75 65 22 29 0d 01 |"COUNT value")..|
00000510 4a 22 f2 70 72 69 6e 74 28 22 20 20 26 31 46 22 |J".print(" &1F"|
00000520 2c 22 4c 49 53 54 4f 20 6f 70 74 69 6f 6e 22 29 |,"LISTO option")|
00000530 0d 01 54 32 f2 70 72 69 6e 74 28 22 22 2c 22 20 |..T2.print(""," |
00000540 20 20 42 69 74 30 20 2d 20 73 70 61 63 65 20 61 | Bit0 - space a|
00000550 66 74 65 72 20 6c 69 6e 65 20 6e 75 6d 62 65 72 |fter line number|
00000560 22 29 0d 01 5e 26 f2 70 72 69 6e 74 28 22 22 2c |")..^&.print("",|
00000570 22 20 20 20 42 69 74 31 20 2d 20 69 6e 64 65 6e |" Bit1 - inden|
00000580 74 20 46 4f 52 73 22 29 0d 01 68 29 f2 70 72 69 |t FORs")..h).pri|
00000590 6e 74 28 22 22 2c 22 20 20 20 42 69 74 32 20 2d |nt(""," Bit2 -|
000005a0 20 69 6e 64 65 6e 74 20 52 45 50 45 41 54 73 22 | indent REPEATs"|
000005b0 29 0d 01 72 20 f2 70 72 69 6e 74 28 22 20 20 26 |)..r .print(" &|
000005c0 32 30 22 2c 22 54 52 41 43 45 20 66 6c 61 67 22 |20","TRACE flag"|
000005d0 29 0d 01 7c 33 f2 70 72 69 6e 74 28 22 20 20 26 |)..|3.print(" &|
000005e0 32 31 2f 26 32 32 22 2c 22 4d 61 78 69 6d 75 6d |21/&22","Maximum|
000005f0 20 54 52 41 43 45 20 6c 69 6e 65 20 6e 75 6d 62 | TRACE line numb|
00000600 65 72 22 29 0d 01 86 1b f2 70 72 69 6e 74 28 22 |er").....print("|
00000610 20 20 26 32 33 22 2c 22 57 49 44 54 48 22 29 0d | &23","WIDTH").|
00000620 01 90 35 f2 70 72 69 6e 74 28 22 20 20 26 32 34 |..5.print(" &24|
00000630 22 2c 22 52 45 50 45 41 54 2f 55 4e 54 49 4c 20 |","REPEAT/UNTIL |
00000640 6c 6f 6f 70 20 64 65 70 74 68 20 63 6f 75 6e 74 |loop depth count|
00000650 65 72 22 29 0d 01 9a 29 f2 70 72 69 6e 74 28 22 |er")...).print("|
00000660 20 20 26 32 35 22 2c 22 47 4f 53 55 42 20 64 65 | &25","GOSUB de|
00000670 70 74 68 20 63 6f 75 6e 74 65 72 22 29 0d 01 a4 |pth counter")...|
00000680 31 f2 70 72 69 6e 74 28 22 20 20 26 32 36 22 2c |1.print(" &26",|
00000690 22 46 4f 52 2f 4e 45 58 54 20 6c 6f 6f 70 20 64 |"FOR/NEXT loop d|
000006a0 65 70 74 68 20 63 6f 75 6e 74 65 72 22 29 0d 01 |epth counter")..|
000006b0 ae 2a f2 70 72 69 6e 74 28 22 20 20 26 32 38 22 |.*.print(" &28"|
000006c0 2c 22 4f 50 54 20 61 73 73 65 6d 62 6c 65 72 20 |,"OPT assembler |
000006d0 76 61 6c 75 65 3a 22 29 0d 01 b8 2a f2 70 72 69 |value:")...*.pri|
000006e0 6e 74 28 22 22 2c 22 20 20 20 42 69 74 30 20 2d |nt(""," Bit0 -|
000006f0 20 50 72 6f 64 75 63 65 20 6c 69 73 74 69 6e 67 | Produce listing|
00000700 22 29 0d 01 c2 26 f2 70 72 69 6e 74 28 22 22 2c |")...&.print("",|
00000710 22 20 20 20 42 69 74 31 20 2d 20 67 69 76 65 20 |" Bit1 - give |
00000720 65 72 72 6f 72 73 22 29 0d 01 cc 23 f2 70 72 69 |errors")...#.pri|
00000730 6e 74 28 22 22 2c 22 20 20 20 42 69 74 32 20 2d |nt(""," Bit2 -|
00000740 20 72 65 6c 6f 63 61 74 65 22 29 0d 01 d6 43 f2 | relocate")...C.|
00000750 70 72 69 6e 74 28 22 20 20 26 32 41 2d 26 32 44 |print(" &2A-&2D|
00000760 22 2c 22 49 6e 74 41 20 2d 20 77 6f 72 6b 73 70 |","IntA - worksp|
00000770 61 63 65 20 66 6f 72 20 69 6e 74 65 67 65 72 20 |ace for integer |
00000780 63 61 6c 63 75 6c 61 74 69 6f 6e 73 22 29 0d 01 |calculations")..|
00000790 e0 49 f2 70 72 69 6e 74 28 22 20 20 26 32 45 2d |.I.print(" &2E-|
000007a0 26 33 35 22 2c 22 46 50 41 20 2d 20 77 6f 72 6b |&35","FPA - work|
000007b0 73 70 61 63 65 20 66 6f 72 20 66 6c 6f 61 74 69 |space for floati|
000007c0 6e 67 20 70 6f 69 6e 74 20 63 61 6c 63 75 6c 61 |ng point calcula|
000007d0 74 69 6f 6e 73 22 29 0d 01 ea 35 f2 70 72 69 6e |tions")...5.prin|
000007e0 74 28 22 20 20 26 33 36 22 2c 22 53 74 72 41 20 |t(" &36","StrA |
000007f0 2d 20 6c 65 6e 67 74 68 20 6f 66 20 73 74 72 69 |- length of stri|
00000800 6e 67 20 61 74 20 26 36 30 30 22 29 0d 01 f4 49 |ng at &600")...I|
00000810 f2 70 72 69 6e 74 28 22 20 20 26 33 42 2d 26 34 |.print(" &3B-&4|
00000820 32 22 2c 22 46 50 42 20 2d 20 77 6f 72 6b 73 70 |2","FPB - worksp|
00000830 61 63 65 20 66 6f 72 20 66 6c 6f 61 74 69 6e 67 |ace for floating|
00000840 20 70 6f 69 6e 74 20 63 61 6c 63 75 6c 61 74 69 | point calculati|
00000850 6f 6e 73 22 29 0d 01 fe 22 f2 70 72 69 6e 74 28 |ons")...".print(|
00000860 22 20 20 26 34 46 2d 26 38 46 22 2c 22 4e 6f 74 |" &4F-&8F","Not|
00000870 20 75 73 65 64 22 29 0d 02 08 41 f2 70 72 69 6e | used")...A.prin|
00000880 74 28 22 20 20 26 39 30 2d 2f 26 39 46 22 2c 22 |t(" &90-/&9F","|
00000890 45 63 6f 6e 65 74 20 2d 20 6e 6f 74 20 61 76 61 |Econet - not ava|
000008a0 69 6c 61 62 6c 65 20 6f 6e 20 74 68 65 20 45 6c |ilable on the El|
000008b0 65 63 74 72 6f 6e 22 29 0d 02 12 21 f2 70 72 69 |ectron")...!.pri|
000008c0 6e 74 28 22 22 2c 22 73 6f 20 77 6f 6e 27 74 20 |nt("","so won't |
000008d0 62 65 20 75 73 65 64 22 29 0d 02 1c 3e f2 70 72 |be used")...>.pr|
000008e0 69 6e 74 28 22 20 20 26 41 30 2d 26 41 37 22 2c |int(" &A0-&A7",|
000008f0 22 4e 4d 49 20 77 6f 72 6b 73 70 61 63 65 20 2d |"NMI workspace -|
00000900 20 75 73 65 64 20 62 79 20 64 69 73 63 20 73 79 | used by disc sy|
00000910 73 74 65 6d 73 22 29 0d 02 26 26 f2 70 72 69 6e |stems")..&&.prin|
00000920 74 28 22 22 2c 22 66 72 65 65 20 69 66 20 63 61 |t("","free if ca|
00000930 73 73 65 74 74 65 20 6f 6e 6c 79 22 29 0d 02 30 |ssette only")..0|
00000940 42 f2 70 72 69 6e 74 28 22 20 20 26 41 38 2f 26 |B.print(" &A8/&|
00000950 41 46 22 2c 22 55 73 65 64 20 62 79 20 73 74 61 |AF","Used by sta|
00000960 72 20 63 6f 6d 6d 61 6e 64 73 2c 20 66 72 65 65 |r commands, free|
00000970 20 69 66 20 6e 6f 6e 65 20 75 73 65 64 22 29 0d | if none used").|
00000980 02 3a 31 f2 70 72 69 6e 74 28 22 20 20 26 42 30 |.:1.print(" &B0|
00000990 2d 26 42 46 22 2c 22 46 69 6c 69 6e 67 20 73 79 |-&BF","Filing sy|
000009a0 73 74 65 6d 20 77 6f 72 6b 73 70 61 63 65 22 29 |stem workspace")|
000009b0 0d 02 44 40 f2 70 72 69 6e 74 28 22 20 20 26 43 |..D@.print(" &C|
000009c0 30 2d 26 43 46 22 2c 22 55 73 65 64 20 62 79 20 |0-&CF","Used by |
000009d0 63 75 72 72 6e 65 74 6c 79 20 61 63 74 69 76 65 |currnetly active|
000009e0 20 66 69 6c 69 6e 67 20 73 79 73 74 65 6d 22 29 | filing system")|
000009f0 0d 02 4e 26 f2 70 72 69 6e 74 28 22 20 20 26 44 |..N&.print(" &D|
00000a00 30 22 2c 22 56 44 55 20 73 74 61 74 75 73 20 62 |0","VDU status b|
00000a10 79 74 65 3a 22 29 0d 02 58 34 f2 70 72 69 6e 74 |yte:")..X4.print|
00000a20 28 22 22 2c 22 20 20 20 20 20 20 20 42 69 74 30 |(""," Bit0|
00000a30 20 2d 20 50 72 69 6e 74 65 72 20 6f 75 74 70 75 | - Printer outpu|
00000a40 74 20 73 74 61 74 75 73 22 29 0d 02 62 31 f2 70 |t status")..b1.p|
00000a50 72 69 6e 74 28 22 22 2c 22 20 20 20 20 20 20 20 |rint(""," |
00000a60 42 69 74 31 20 2d 20 53 63 72 6f 6c 6c 69 6e 67 |Bit1 - Scrolling|
00000a70 20 64 69 73 61 62 6c 65 64 22 29 0d 02 6c 32 f2 | disabled")..l2.|
00000a80 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 20 20 |print(""," |
00000a90 20 42 69 74 32 20 2d 20 50 61 67 65 64 20 6d 6f | Bit2 - Paged mo|
00000aa0 64 65 20 73 65 6c 65 63 74 65 64 22 29 0d 02 76 |de selected")..v|
00000ab0 2e f2 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 |..print(""," |
00000ac0 20 20 20 42 69 74 33 20 2d 20 53 6f 66 74 77 61 | Bit3 - Softwa|
00000ad0 72 65 20 73 63 72 6f 6c 6c 22 29 0d 02 80 27 f2 |re scroll")...'.|
00000ae0 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 20 20 |print(""," |
00000af0 20 42 69 74 34 20 2d 20 4e 6f 74 20 75 65 73 64 | Bit4 - Not uesd|
00000b00 22 29 0d 02 8a 2b f2 70 72 69 6e 74 28 22 22 2c |")...+.print("",|
00000b10 22 20 20 20 20 20 20 20 42 69 74 35 20 2d 20 56 |" Bit5 - V|
00000b20 44 55 35 20 65 6e 61 62 6c 65 64 22 29 0d 02 94 |DU5 enabled")...|
00000b30 32 f2 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 |2.print(""," |
00000b40 20 20 20 42 69 74 36 20 2d 20 43 75 72 73 6f 72 | Bit6 - Cursor|
00000b50 20 73 70 6c 69 74 20 73 74 61 74 75 73 22 29 0d | split status").|
00000b60 02 9e 31 f2 70 72 69 6e 74 28 22 22 2c 22 20 20 |..1.print(""," |
00000b70 20 20 20 20 20 42 69 74 37 20 2d 20 56 44 55 20 | Bit7 - VDU |
00000b80 64 69 73 61 62 6c 65 20 73 74 61 74 75 73 22 29 |disable status")|
00000b90 0d 02 a8 35 f2 70 72 69 6e 74 28 22 20 20 26 44 |...5.print(" &D|
00000ba0 31 22 2c 22 4d 61 73 6b 20 66 6f 72 20 63 75 72 |1","Mask for cur|
00000bb0 72 65 6e 74 20 67 72 61 70 68 69 63 73 20 70 6f |rent graphics po|
00000bc0 69 6e 74 22 29 0d 02 b2 27 f1 bd 32 30 30 3b c4 |int")...'..200;.|
00000bd0 31 33 2c bd 32 30 35 29 3b bd 32 30 37 3b c4 35 |13,.205);.207;.5|
00000be0 34 2c bd 32 30 35 29 3b bd 31 38 38 0d 02 bc 06 |4,.205);.188....|
00000bf0 f1 27 0d 02 c6 18 f1 bd 32 30 31 3b c4 36 38 2c |.'......201;.68,|
00000c00 bd 32 30 35 29 3b bd 31 38 37 0d 02 d0 37 f2 70 |.205);.187...7.p|
00000c10 72 69 6e 74 63 74 28 22 45 4c 45 43 54 52 4f 4e |rintct("ELECTRON|
00000c20 20 4d 45 4d 4f 52 59 20 4d 41 50 20 2d 20 5a 65 | MEMORY MAP - Ze|
00000c30 72 6f 20 50 61 67 65 20 28 63 6f 6e 74 64 29 22 |ro Page (contd)"|
00000c40 29 0d 02 da 27 f1 bd 31 39 39 3b c4 31 33 2c bd |)...'..199;.13,.|
00000c50 31 39 36 29 3b bd 31 39 34 3b c4 35 34 2c bd 31 |196);.194;.54,.1|
00000c60 39 36 29 3b bd 31 38 32 0d 02 e4 1d f2 70 72 69 |96);.182.....pri|
00000c70 6e 74 28 22 20 20 41 64 64 72 65 73 73 22 2c 22 |nt(" Address","|
00000c80 55 73 65 22 29 0d 02 ee 27 f1 bd 31 39 39 3b c4 |Use")...'..199;.|
00000c90 31 33 2c bd 31 39 36 29 3b bd 31 39 37 3b c4 35 |13,.196);.197;.5|
00000ca0 34 2c bd 31 39 36 29 3b bd 31 38 32 0d 02 f8 4c |4,.196);.182...L|
00000cb0 f2 70 72 69 6e 74 28 22 20 20 26 44 32 2f 26 44 |.print(" &D2/&D|
00000cc0 33 22 2c 22 54 65 78 74 20 63 6f 6c 6f 75 72 20 |3","Text colour |
00000cd0 62 79 74 65 73 20 74 6f 20 62 65 20 4f 52 65 64 |bytes to be ORed|
00000ce0 20 61 6e 64 20 45 4f 52 65 64 20 69 6e 74 6f 20 | and EORed into |
00000cf0 6d 65 6d 6f 72 79 22 29 0d 03 02 44 f2 70 72 69 |memory")...D.pri|
00000d00 6e 74 28 22 20 20 26 44 34 2f 26 44 35 22 2c 22 |nt(" &D4/&D5","|
00000d10 47 72 61 70 68 69 63 73 20 63 6f 6c 6f 75 72 20 |Graphics colour |
00000d20 62 79 74 65 73 20 74 6f 20 62 65 20 4f 52 65 64 |bytes to be ORed|
00000d30 20 61 6e 64 20 45 4f 52 65 64 22 29 0d 03 0c 1c | and EORed")....|
00000d40 f2 70 72 69 6e 74 28 22 22 2c 22 69 6e 74 6f 20 |.print("","into |
00000d50 6d 65 6d 6f 72 79 22 29 0d 03 16 44 f2 70 72 69 |memory")...D.pri|
00000d60 6e 74 28 22 20 20 26 44 36 2f 26 44 37 22 2c 22 |nt(" &D6/&D7","|
00000d70 41 64 64 72 65 73 73 20 6f 66 20 63 75 72 72 65 |Address of curre|
00000d80 6e 74 20 67 72 61 70 68 69 63 73 20 63 68 61 72 |nt graphics char|
00000d90 61 63 74 65 72 20 63 65 6c 6c 22 29 0d 03 20 40 |acter cell").. @|
00000da0 f2 70 72 69 6e 74 28 22 20 20 26 44 38 2f 26 44 |.print(" &D8/&D|
00000db0 39 22 2c 22 41 64 64 72 65 73 73 20 6f 66 20 63 |9","Address of c|
00000dc0 75 72 72 65 6e 74 20 74 65 78 74 20 63 68 61 72 |urrent text char|
00000dd0 61 63 74 65 72 20 63 65 6c 6c 22 29 0d 03 2a 2d |acter cell")..*-|
00000de0 f2 70 72 69 6e 74 28 22 20 20 26 44 41 2d 26 44 |.print(" &DA-&D|
00000df0 46 22 2c 22 54 65 6d 70 6f 72 61 72 79 20 77 6f |F","Temporary wo|
00000e00 72 6b 73 70 61 63 65 22 29 0d 03 34 22 f2 70 72 |rkspace")..4".pr|
00000e10 69 6e 74 28 22 20 20 26 45 30 2f 26 45 31 22 2c |int(" &E0/&E1",|
00000e20 22 4e 6f 74 20 75 73 65 64 22 29 0d 03 3e 39 f2 |"Not used")..>9.|
00000e30 70 72 69 6e 74 28 22 20 20 26 45 32 22 2c 22 43 |print(" &E2","C|
00000e40 61 73 73 65 74 74 65 20 66 69 6c 69 6e 67 20 73 |assette filing s|
00000e50 79 73 74 65 6d 20 73 74 61 74 75 73 20 62 79 74 |ystem status byt|
00000e60 65 3a 22 29 0d 03 48 2f f2 70 72 69 6e 74 28 22 |e:")..H/.print("|
00000e70 22 2c 22 20 20 20 20 20 20 20 20 42 69 74 30 20 |"," Bit0 |
00000e80 2d 20 49 6e 70 75 74 20 66 69 6c 65 20 6f 70 65 |- Input file ope|
00000e90 6e 22 29 0d 03 52 30 f2 70 72 69 6e 74 28 22 22 |n")..R0.print(""|
00000ea0 2c 22 20 20 20 20 20 20 20 20 42 69 74 31 20 2d |," Bit1 -|
00000eb0 20 4f 75 74 70 75 74 20 66 69 6c 65 20 6f 70 65 | Output file ope|
00000ec0 6e 22 29 0d 03 5c 28 f2 70 72 69 6e 74 28 22 22 |n")..\(.print(""|
00000ed0 2c 22 20 20 20 20 20 20 20 20 42 69 74 32 20 2d |," Bit2 -|
00000ee0 20 4e 6f 74 20 75 73 65 64 22 29 0d 03 66 32 f2 | Not used")..f2.|
00000ef0 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 20 20 |print(""," |
00000f00 20 20 42 69 74 33 20 2d 20 53 65 74 20 69 66 20 | Bit3 - Set if |
00000f10 63 61 74 61 6c 6f 67 75 69 6e 67 22 29 0d 03 70 |cataloguing")..p|
00000f20 28 f2 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 |(.print(""," |
00000f30 20 20 20 20 42 69 74 34 20 2d 20 4e 6f 74 20 75 | Bit4 - Not u|
00000f40 73 65 64 22 29 0d 03 7a 28 f2 70 72 69 6e 74 28 |sed")..z(.print(|
00000f50 22 22 2c 22 20 20 20 20 20 20 20 20 42 69 74 35 |""," Bit5|
00000f60 20 2d 20 4e 6f 74 20 75 73 65 64 22 29 0d 03 84 | - Not used")...|
00000f70 2f f2 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 |/.print(""," |
00000f80 20 20 20 20 42 69 74 36 20 2d 20 41 74 20 65 6e | Bit6 - At en|
00000f90 64 20 6f 66 20 66 69 6c 65 3f 22 29 0d 03 8e 3a |d of file?")...:|
00000fa0 f2 70 72 69 6e 74 28 22 22 2c 22 20 20 20 20 20 |.print(""," |
00000fb0 20 20 20 42 69 74 37 20 2d 20 45 6e 64 20 6f 66 | Bit7 - End of|
00000fc0 20 66 69 6c 65 20 77 61 72 6e 69 6e 67 20 67 69 | file warning gi|
00000fd0 76 65 6e 3f 22 29 0d 03 98 39 f2 70 72 69 6e 74 |ven?")...9.print|
00000fe0 28 22 20 20 26 45 33 22 2c 22 43 61 73 73 65 74 |(" &E3","Casset|
00000ff0 74 65 20 2a 4f 50 54 20 6f 70 74 69 6f 6e 73 20 |te *OPT options |
00001000 69 6e 20 6c 6f 77 20 6e 69 62 62 6c 65 22 29 0d |in low nibble").|
00001010 03 a2 34 f2 70 72 69 6e 74 28 22 20 20 26 45 34 |..4.print(" &E4|
00001020 2d 26 45 36 22 2c 22 4f 70 65 72 61 74 69 6e 67 |-&E6","Operating|
00001030 20 73 79 73 74 65 6d 20 77 6f 72 6b 73 70 61 63 | system workspac|
00001040 65 22 29 0d 03 ac 31 f2 70 72 69 6e 74 28 22 20 |e")...1.print(" |
00001050 20 26 45 37 22 2c 22 41 75 74 6f 20 72 65 70 65 | &E7","Auto repe|
00001060 61 74 20 63 6f 75 6e 74 64 6f 77 6e 20 74 69 6d |at countdown tim|
00001070 65 72 22 29 0d 03 b6 44 f2 70 72 69 6e 74 28 22 |er")...D.print("|
00001080 20 20 26 45 38 2f 26 45 39 22 2c 22 41 64 64 72 | &E8/&E9","Addr|
00001090 65 73 73 20 6f 66 20 69 6e 70 75 74 20 62 75 66 |ess of input buf|
000010a0 66 65 72 20 2d 20 75 73 65 64 20 62 79 20 6f 73 |fer - used by os|
000010b0 77 6f 72 64 20 30 22 29 0d 03 c0 3d f2 70 72 69 |word 0")...=.pri|
000010c0 6e 74 28 22 20 20 26 45 41 22 2c 22 52 53 34 32 |nt(" &EA","RS42|
000010d0 33 20 74 69 6d 65 6f 75 74 20 63 6f 75 6e 74 65 |3 timeout counte|
000010e0 72 2c 20 66 72 65 65 20 69 66 20 6e 6f 20 52 53 |r, free if no RS|
000010f0 34 32 33 22 29 0d 03 ca 2d f2 70 72 69 6e 74 28 |423")...-.print(|
00001100 22 20 20 26 45 42 22 2c 22 55 73 65 64 20 62 79 |" &EB","Used by|
00001110 20 63 61 73 73 65 74 74 65 20 73 79 73 74 65 6d | cassette system|
00001120 22 29 0d 03 d4 3d f2 70 72 69 6e 74 28 22 20 20 |")...=.print(" |
00001130 26 45 43 22 2c 22 49 6e 74 65 72 6e 61 6c 20 6b |&EC","Internal k|
00001140 65 79 20 6e 75 6d 62 65 72 20 6f 66 20 6c 61 73 |ey number of las|
00001150 74 20 6b 65 79 20 70 72 65 73 73 65 64 22 29 0d |t key pressed").|
00001160 03 de 39 f2 70 72 69 6e 74 28 22 20 20 26 45 44 |..9.print(" &ED|
00001170 22 2c 22 49 6e 74 65 72 6e 61 6c 20 6b 65 79 20 |","Internal key |
00001180 6e 75 6d 62 65 72 20 6f 66 20 66 69 72 73 74 20 |number of first |
00001190 6b 65 79 20 69 66 22 29 0d 03 e8 26 f2 70 72 69 |key if")...&.pri|
000011a0 6e 74 28 22 22 2c 22 6d 6f 72 65 20 74 68 61 6e |nt("","more than|
000011b0 20 6f 6e 65 20 70 72 65 73 73 65 64 22 29 0d 03 | one pressed")..|
000011c0 f2 3e f2 70 72 69 6e 74 28 22 20 20 26 45 45 22 |.>.print(" &EE"|
000011d0 2c 22 49 6e 74 65 72 6e 61 6c 20 6b 65 79 20 6e |,"Internal key n|
000011e0 75 6d 62 65 72 20 6f 66 20 6b 65 79 20 74 6f 20 |umber of key to |
000011f0 62 65 20 69 67 6e 6f 72 65 64 22 29 0d 03 fc 41 |be ignored")...A|
00001200 f2 70 72 69 6e 74 28 22 20 20 26 45 46 22 2c 22 |.print(" &EF","|
00001210 43 6f 70 79 20 6f 66 20 41 20 72 65 67 69 73 74 |Copy of A regist|
00001220 65 72 20 6f 66 20 6c 61 73 74 20 6f 73 62 79 74 |er of last osbyt|
00001230 65 20 6f 72 20 6f 73 77 6f 72 64 22 29 0d 04 06 |e or osword")...|
00001240 41 f2 70 72 69 6e 74 28 22 20 20 26 46 30 22 2c |A.print(" &F0",|
00001250 22 43 6f 70 79 20 6f 66 20 58 20 72 65 67 69 73 |"Copy of X regis|
00001260 74 65 72 20 6f 66 20 6c 61 73 74 20 6f 73 62 79 |ter of last osby|
00001270 74 65 20 6f 72 20 6f 73 77 6f 72 64 22 29 0d 04 |te or osword")..|
00001280 10 41 f2 70 72 69 6e 74 28 22 20 20 26 46 31 22 |.A.print(" &F1"|
00001290 2c 22 43 6f 70 79 20 6f 66 20 59 20 72 65 67 69 |,"Copy of Y regi|
000012a0 73 74 65 72 20 6f 66 20 6c 61 73 74 20 6f 73 62 |ster of last osb|
000012b0 79 74 65 20 6f 72 20 6f 73 77 6f 72 64 22 29 0d |yte or osword").|
000012c0 04 1a 45 f2 70 72 69 6e 74 28 22 20 20 26 46 32 |..E.print(" &F2|
000012d0 2f 26 46 33 22 2c 22 54 65 78 74 20 70 6f 69 6e |/&F3","Text poin|
000012e0 74 65 72 20 74 6f 20 73 74 61 72 20 63 6f 6d 6d |ter to star comm|
000012f0 61 6e 64 73 20 61 6e 64 20 66 69 6c 65 6e 61 6d |ands and filenam|
00001300 65 73 22 29 0d 04 24 36 f2 70 72 69 6e 74 28 22 |es")..$6.print("|
00001310 20 20 26 46 34 22 2c 22 4e 75 6d 62 65 72 20 6f | &F4","Number o|
00001320 66 20 63 75 72 72 65 6e 74 6c 79 20 73 65 6c 65 |f currently sele|
00001330 63 74 65 64 20 72 6f 6d 22 29 0d 04 2e 22 f2 70 |cted rom")...".p|
00001340 72 69 6e 74 28 22 20 20 26 46 35 2d 26 46 39 22 |rint(" &F5-&F9"|
00001350 2c 22 4e 6f 74 20 75 73 65 64 22 29 0d 04 38 34 |,"Not used")..84|
00001360 f2 70 72 69 6e 74 28 22 20 20 26 46 41 2f 26 46 |.print(" &FA/&F|
00001370 42 22 2c 22 4f 70 65 72 61 74 69 6e 67 20 73 79 |B","Operating sy|
00001380 73 74 65 6d 20 77 6f 72 6b 73 70 61 63 65 22 29 |stem workspace")|
00001390 0d 04 42 3a f2 70 72 69 6e 74 28 22 20 20 26 46 |..B:.print(" &F|
000013a0 43 22 2c 22 43 6f 70 79 20 6f 66 20 41 20 72 65 |C","Copy of A re|
000013b0 67 69 73 74 65 72 20 61 74 20 6c 61 73 74 20 69 |gister at last i|
000013c0 6e 74 65 72 72 75 70 74 22 29 0d 04 4c 3a f2 70 |nterrupt")..L:.p|
000013d0 72 69 6e 74 28 22 20 20 26 46 44 2f 26 46 45 22 |rint(" &FD/&FE"|
000013e0 2c 22 50 6f 69 6e 74 73 20 74 6f 20 62 79 74 65 |,"Points to byte|
000013f0 20 61 66 74 65 72 20 6c 61 73 74 20 42 52 4b 20 | after last BRK |
00001400 6f 72 22 29 0d 04 56 28 f2 70 72 69 6e 74 28 22 |or")..V(.print("|
00001410 22 2c 22 6c 61 6e 67 75 61 67 65 20 76 65 72 73 |","language vers|
00001420 69 6f 6e 20 73 74 72 69 6e 67 22 29 0d 04 60 21 |ion string")..`!|
00001430 f2 70 72 69 6e 74 28 22 20 20 26 46 46 22 2c 22 |.print(" &FF","|
00001440 45 73 63 61 70 65 20 66 6c 61 67 22 29 0d 04 6a |Escape flag")..j|
00001450 27 f1 bd 32 30 30 3b c4 31 33 2c bd 32 30 35 29 |'..200;.13,.205)|
00001460 3b bd 32 30 37 3b c4 35 34 2c bd 32 30 35 29 3b |;.207;.54,.205);|
00001470 bd 31 38 38 0d 04 74 05 f1 0d 04 7e 18 f1 bd 32 |.188..t....~...2|
00001480 30 31 3b c4 36 38 2c bd 32 30 35 29 3b bd 31 38 |01;.68,.205);.18|
00001490 37 0d 04 88 2c f2 70 72 69 6e 74 63 74 28 22 45 |7...,.printct("E|
000014a0 4c 45 43 54 52 4f 4e 20 4d 45 4d 4f 52 59 20 4d |LECTRON MEMORY M|
000014b0 41 50 20 2d 20 50 61 67 65 20 31 22 29 0d 04 92 |AP - Page 1")...|
000014c0 27 f1 bd 31 39 39 3b c4 31 33 2c bd 31 39 36 29 |'..199;.13,.196)|
000014d0 3b bd 31 39 34 3b c4 35 34 2c bd 31 39 36 29 3b |;.194;.54,.196);|
000014e0 bd 31 38 32 0d 04 9c 1d f2 70 72 69 6e 74 28 22 |.182.....print("|
000014f0 20 20 41 64 64 72 65 73 73 22 2c 22 55 73 65 22 | Address","Use"|
00001500 29 0d 04 a6 27 f1 bd 31 39 39 3b c4 31 33 2c bd |)...'..199;.13,.|
00001510 31 39 36 29 3b bd 31 39 37 3b c4 35 34 2c bd 31 |196);.197;.54,.1|
00001520 39 36 29 3b bd 31 38 32 0d 04 b0 42 f2 70 72 69 |96);.182...B.pri|
00001530 6e 74 28 22 20 26 31 30 30 2f 26 31 46 46 22 2c |nt(" &100/&1FF",|
00001540 22 36 35 30 32 20 73 74 61 63 6b 20 2d 20 73 74 |"6502 stack - st|
00001550 61 63 6b 73 20 66 72 6f 6d 20 26 31 46 46 20 64 |acks from &1FF d|
00001560 6f 77 6e 77 61 72 64 73 22 29 0d 04 ba 36 f2 70 |ownwards")...6.p|
00001570 72 69 6e 74 28 22 22 2c 22 4c 6f 77 65 72 20 68 |rint("","Lower h|
00001580 61 6c 66 20 6d 61 79 20 62 65 20 75 73 65 64 20 |alf may be used |
00001590 61 73 20 73 63 72 61 74 63 68 20 70 61 64 22 29 |as scratch pad")|
000015a0 0d 04 c4 3e f2 70 72 69 6e 74 28 22 22 2c 22 50 |...>.print("","P|
000015b0 61 67 65 64 20 52 4f 4d 20 73 65 72 76 69 63 65 |aged ROM service|
000015c0 20 72 6f 75 74 69 6e 65 73 20 6d 61 79 20 75 73 | routines may us|
000015d0 65 20 74 68 65 20 62 6f 74 74 6f 6d 22 29 0d 04 |e the bottom")..|
000015e0 ce 28 f2 70 72 69 6e 74 28 22 22 2c 22 74 6f 20 |.(.print("","to |
000015f0 73 74 6f 72 65 20 65 72 72 6f 72 20 6d 65 73 73 |store error mess|
00001600 61 67 65 73 22 29 0d 04 d8 27 f1 bd 32 30 30 3b |ages")...'..200;|
00001610 c4 31 33 2c bd 32 30 35 29 3b bd 32 30 37 3b c4 |.13,.205);.207;.|
00001620 35 34 2c bd 32 30 35 29 3b bd 31 38 38 0d 04 e2 |54,.205);.188...|
00001630 05 f1 0d 04 ec 06 ef 33 0d 04 ed 3a f1 27 27 22 |.......3...:.''"|
00001640 50 4c 45 41 53 45 20 50 52 45 53 53 20 3c 46 3e |PLEASE PRESS <F>|
00001650 20 46 4f 52 20 4e 45 58 54 20 46 49 4c 45 2c 20 | FOR NEXT FILE, |
00001660 3c 4d 3e 20 46 4f 52 20 4d 41 49 4e 20 4d 45 4e |<M> FOR MAIN MEN|
00001670 55 22 0d 04 ee 15 f5 3a fd 20 be 3d 22 46 22 20 |U".....:. .="F" |
00001680 84 20 be 3d 22 4d 22 0d 04 ef 16 e7 20 be 3d 22 |. .="M"..... .="|
00001690 46 22 20 8c 20 d7 22 24 2e 4d 4d 32 22 0d 04 f0 |F" . ."$.MM2"...|
000016a0 17 e7 20 be 3d 22 4d 22 20 8c 20 d7 22 24 2e 4d |.. .="M" . ."$.M|
000016b0 45 4e 55 22 0d 04 f6 05 e0 0d 05 00 33 dd f2 70 |ENU"........3..p|
000016c0 72 69 6e 74 63 74 28 74 24 29 3a f1 bd 31 38 36 |rintct(t$):..186|
000016d0 3b 8a 36 38 2f 32 2d a9 74 24 2f 32 29 3b 74 24 |;.68/2-.t$/2);t$|
000016e0 3b 8a 36 39 29 3b bd 31 38 36 3a e1 0d 05 0a 3c |;.69);.186:....<|
000016f0 dd f2 70 72 69 6e 74 28 61 24 2c 62 24 29 3a f1 |..print(a$,b$):.|
00001700 bd 31 38 36 3b 8a 32 29 61 24 3b 8a 31 34 29 3b |.186;.2)a$;.14);|
00001710 bd 31 37 39 3b 8a 31 36 29 3b 62 24 3b 8a 36 39 |.179;.16);b$;.69|
00001720 29 3b bd 31 38 36 3a e1 0d ff |);.186:...|
0000172a
MM1.m0
MM1.m1
MM1.m2
MM1.m4
MM1.m5
.
