80 column wordwrapped file. Eprom Emulator Instructions =========================== If you don't have access to a ROM board with sideways RAM socket(s) but,like me,have access to an Eprom programmer then you could bu ild this little device. It need not only be restricted to storing sideways ROM images,but may be used with other Eprom based devices that need to be continu ally redeveloped - for example it can also be used with Maplin's UM5100 speech programmer replay only board,which accepts Eproms onl y. PARTS... The circuit diagram shows electrically how to assemble the unit,requiring the following parts: 1x 62256 SRAM (28 pin) 1x 28 pin DIL socket 1x SPDT switch 1x Battery box to hold 3xAA batteries 2x IN4001 diodes In addition,it may be useful to have a ZIF socket mounted on the outside of your case,to reduce the stress on,levering the device in and out. BENEFITS... *Switches automatically between battery backup and system powersupply *Can emulate chips 27128/27256 *Low power CMOS static RAM lasts for weeks on a set of batteries *Cheaper than EEPROM (around 22) *Hardware selection of write enable/write protect - gets around protected ROM images BUILD... 1.As the pin outs on a 62256 and 27128 (or 27256) are virtually identical all but print 1,27,28 can be direct one to one connections . 2.Pin 1,27,28 can be bent out of shape carefully with a pair of pliers - being carefully not to stress the metal. 3.Solder a small wire to pin 1 and run this under the chip and plug it into pin 27 of the socket.This becomes address 14. 4.Not CS and Not OE are handled by the Eprom programmer or microprocessor so can be left aline. 5.Having bent pin 27 out of the way of the small wire you just soldered on attach this to the centre pole of the switch.The other tw o terminals of the switch go to pin 14 (GND) and 28 (VCC). 6.Pin 28 also must be split.The two diodes prevent the microprocessor's power supply from trying to recharge the batteries,and vice versa. 7.The battery clip and switch should be wire ended and insulated to prevent shorts in confined spaces and to allow the device to fit under the keyboard on a BBC B. HINTS... *Below around 2.5v the contents of SRAM may become corrupted or lost *I found this very useful to test out the suitability of ROM images before committing them to EPROM *I also fitted a ZIF socket to the ashtray (the punch out section on the left of the B's keyboard where the speech sockets would go) to save having to keep levering the pack in and out *If you do make a ZIF socket,there may be timing problems with piggy back ROMs such as Mega 3.Try connecting a 100nF capacitor from pin 28 to pin 14. *The auto power switching only works if there is a difference of around 0.6v between the main power supply and the battery pack - he nce the use of 4.5v of cells in the battery FROM... Robert Sprowson. (01625) 431067. Happy soldering!
00000000 0d 38 30 20 63 6f 6c 75 6d 6e 20 77 6f 72 64 77 |.80 column wordw| 00000010 72 61 70 70 65 64 20 66 69 6c 65 2e 0d 0d 45 70 |rapped file...Ep| 00000020 72 6f 6d 20 45 6d 75 6c 61 74 6f 72 20 49 6e 73 |rom Emulator Ins| 00000030 74 72 75 63 74 69 6f 6e 73 0d 3d 3d 3d 3d 3d 3d |tructions.======| 00000040 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d 3d |================| 00000050 3d 3d 3d 3d 3d 0d 49 66 20 79 6f 75 20 64 6f 6e |=====.If you don| 00000060 27 74 20 68 61 76 65 20 61 63 63 65 73 73 1a 20 |'t have access. | 00000070 74 6f 1a 20 61 1a 20 52 4f 4d 1a 20 62 6f 61 72 |to. a. ROM. boar| 00000080 64 1a 20 77 69 74 68 1a 20 73 69 64 65 77 61 79 |d. with. sideway| 00000090 73 1a 20 52 41 4d 20 73 6f 63 6b 65 74 28 73 29 |s. RAM socket(s)| 000000a0 0d 62 75 74 2c 6c 69 6b 65 1a 20 6d 65 2c 68 61 |.but,like. me,ha| 000000b0 76 65 20 61 63 63 65 73 73 20 74 6f 20 61 6e 20 |ve access to an | 000000c0 45 70 72 6f 6d 20 70 72 6f 67 72 61 6d 6d 65 72 |Eprom programmer| 000000d0 20 74 68 65 6e 20 79 6f 75 20 63 6f 75 6c 64 20 | then you could | 000000e0 62 75 20 69 6c 64 20 74 68 69 73 0d 6c 69 74 74 |bu ild this.litt| 000000f0 6c 65 20 64 65 76 69 63 65 2e 0d 0d 49 74 20 6e |le device...It n| 00000100 65 65 64 20 6e 6f 74 20 6f 6e 6c 79 20 62 65 20 |eed not only be | 00000110 72 65 73 74 72 69 63 74 65 64 20 74 6f 20 73 74 |restricted to st| 00000120 6f 72 69 6e 67 20 73 69 64 65 77 61 79 73 20 52 |oring sideways R| 00000130 4f 4d 20 69 6d 61 67 65 73 2c 62 75 74 20 6d 61 |OM images,but ma| 00000140 79 20 62 65 0d 75 73 65 64 20 77 69 74 68 20 6f |y be.used with o| 00000150 74 68 65 72 20 45 70 72 6f 6d 20 62 61 73 65 64 |ther Eprom based| 00000160 20 64 65 76 69 63 65 73 20 74 68 61 74 20 6e 65 | devices that ne| 00000170 65 64 20 74 6f 20 62 65 20 63 6f 6e 74 69 6e 75 |ed to be continu| 00000180 20 61 6c 6c 79 0d 72 65 64 65 76 65 6c 6f 70 65 | ally.redevelope| 00000190 64 20 2d 20 66 6f 72 20 65 78 61 6d 70 6c 65 20 |d - for example | 000001a0 69 74 20 63 61 6e 20 61 6c 73 6f 20 62 65 20 75 |it can also be u| 000001b0 73 65 64 20 77 69 74 68 20 4d 61 70 6c 69 6e 27 |sed with Maplin'| 000001c0 73 20 55 4d 35 31 30 30 20 73 70 65 65 63 68 0d |s UM5100 speech.| 000001d0 70 72 6f 67 72 61 6d 6d 65 72 20 72 65 70 6c 61 |programmer repla| 000001e0 79 20 6f 6e 6c 79 20 62 6f 61 72 64 2c 77 68 69 |y only board,whi| 000001f0 63 68 20 61 63 63 65 70 74 73 20 45 70 72 6f 6d |ch accepts Eprom| 00000200 73 20 6f 6e 6c 20 79 2e 0d 0d 50 41 52 54 53 2e |s onl y...PARTS.| 00000210 2e 2e 0d 54 68 65 20 63 69 72 63 75 69 74 20 64 |...The circuit d| 00000220 69 61 67 72 61 6d 20 73 68 6f 77 73 20 65 6c 65 |iagram shows ele| 00000230 63 74 72 69 63 61 6c 6c 79 20 68 6f 77 20 74 6f |ctrically how to| 00000240 20 61 73 73 65 6d 62 6c 65 20 74 68 65 20 75 6e | assemble the un| 00000250 69 74 2c 72 65 71 75 69 72 69 6e 67 0d 74 68 65 |it,requiring.the| 00000260 20 66 6f 6c 6c 6f 77 69 6e 67 20 70 61 72 74 73 | following parts| 00000270 3a 0d 0d 31 78 20 20 36 32 32 35 36 20 53 52 41 |:..1x 62256 SRA| 00000280 4d 20 28 32 38 20 70 69 6e 29 0d 31 78 20 20 32 |M (28 pin).1x 2| 00000290 38 20 70 69 6e 20 44 49 4c 20 73 6f 63 6b 65 74 |8 pin DIL socket| 000002a0 0d 31 78 20 20 53 50 44 54 20 73 77 69 74 63 68 |.1x SPDT switch| 000002b0 0d 31 78 20 20 42 61 74 74 65 72 79 20 62 6f 78 |.1x Battery box| 000002c0 20 74 6f 20 68 6f 6c 64 20 33 78 41 41 20 62 61 | to hold 3xAA ba| 000002d0 74 74 65 72 69 65 73 0d 32 78 20 20 49 4e 34 30 |tteries.2x IN40| 000002e0 30 31 20 64 69 6f 64 65 73 0d 0d 49 6e 20 61 64 |01 diodes..In ad| 000002f0 64 69 74 69 6f 6e 2c 69 74 20 6d 61 79 20 62 65 |dition,it may be| 00000300 20 75 73 65 66 75 6c 20 74 6f 20 68 61 76 65 20 | useful to have | 00000310 61 20 5a 49 46 20 73 6f 63 6b 65 74 20 6d 6f 75 |a ZIF socket mou| 00000320 6e 74 65 64 20 6f 6e 20 74 68 65 20 6f 75 74 73 |nted on the outs| 00000330 69 64 65 0d 6f 66 20 79 6f 75 72 20 63 61 73 65 |ide.of your case| 00000340 2c 74 6f 20 72 65 64 75 63 65 20 74 68 65 20 73 |,to reduce the s| 00000350 74 72 65 73 73 20 6f 6e 2c 6c 65 76 65 72 69 6e |tress on,leverin| 00000360 67 20 74 68 65 20 64 65 76 69 63 65 20 69 6e 20 |g the device in | 00000370 61 6e 64 20 6f 75 74 2e 0d 0d 42 45 4e 45 46 49 |and out...BENEFI| 00000380 54 53 2e 2e 2e 0d 2a 53 77 69 74 63 68 65 73 20 |TS....*Switches | 00000390 61 75 74 6f 6d 61 74 69 63 61 6c 6c 79 20 62 65 |automatically be| 000003a0 74 77 65 65 6e 20 62 61 74 74 65 72 79 20 62 61 |tween battery ba| 000003b0 63 6b 75 70 20 61 6e 64 20 73 79 73 74 65 6d 20 |ckup and system | 000003c0 70 6f 77 65 72 73 75 70 70 6c 79 0d 2a 43 61 6e |powersupply.*Can| 000003d0 20 65 6d 75 6c 61 74 65 20 63 68 69 70 73 20 32 | emulate chips 2| 000003e0 37 31 32 38 2f 32 37 32 35 36 0d 2a 4c 6f 77 20 |7128/27256.*Low | 000003f0 70 6f 77 65 72 20 43 4d 4f 53 20 73 74 61 74 69 |power CMOS stati| 00000400 63 20 52 41 4d 20 6c 61 73 74 73 20 66 6f 72 20 |c RAM lasts for | 00000410 77 65 65 6b 73 20 6f 6e 20 61 20 73 65 74 20 6f |weeks on a set o| 00000420 66 20 62 61 74 74 65 72 69 65 73 0d 2a 43 68 65 |f batteries.*Che| 00000430 61 70 65 72 20 74 68 61 6e 20 45 45 50 52 4f 4d |aper than EEPROM| 00000440 20 28 61 72 6f 75 6e 64 20 32 32 29 0d 2a 48 61 | (around 22).*Ha| 00000450 72 64 77 61 72 65 20 73 65 6c 65 63 74 69 6f 6e |rdware selection| 00000460 20 6f 66 20 77 72 69 74 65 20 65 6e 61 62 6c 65 | of write enable| 00000470 2f 77 72 69 74 65 20 70 72 6f 74 65 63 74 20 2d |/write protect -| 00000480 20 67 65 74 73 20 61 72 6f 75 6e 64 20 70 72 6f | gets around pro| 00000490 74 65 63 74 65 64 0d 52 4f 4d 20 69 6d 61 67 65 |tected.ROM image| 000004a0 73 0d 0d 42 55 49 4c 44 2e 2e 2e 0d 31 2e 41 73 |s..BUILD....1.As| 000004b0 20 74 68 65 20 70 69 6e 20 6f 75 74 73 20 6f 6e | the pin outs on| 000004c0 20 61 20 36 32 32 35 36 20 61 6e 64 20 32 37 31 | a 62256 and 271| 000004d0 32 38 20 28 6f 72 20 32 37 32 35 36 29 20 61 72 |28 (or 27256) ar| 000004e0 65 20 76 69 72 74 75 61 6c 6c 79 20 69 64 65 6e |e virtually iden| 000004f0 74 69 63 61 6c 0d 61 6c 6c 20 62 75 74 20 70 72 |tical.all but pr| 00000500 69 6e 74 20 31 2c 32 37 2c 32 38 20 63 61 6e 20 |int 1,27,28 can | 00000510 62 65 20 64 69 72 65 63 74 20 6f 6e 65 20 74 6f |be direct one to| 00000520 20 6f 6e 65 20 63 6f 6e 6e 65 63 74 69 6f 6e 73 | one connections| 00000530 20 2e 0d 32 2e 50 69 6e 20 31 2c 32 37 2c 32 38 | ..2.Pin 1,27,28| 00000540 20 63 61 6e 20 62 65 20 62 65 6e 74 20 6f 75 74 | can be bent out| 00000550 20 6f 66 20 73 68 61 70 65 20 63 61 72 65 66 75 | of shape carefu| 00000560 6c 6c 79 20 77 69 74 68 20 61 20 70 61 69 72 20 |lly with a pair | 00000570 6f 66 20 70 6c 69 65 72 73 20 2d 0d 62 65 69 6e |of pliers -.bein| 00000580 67 20 63 61 72 65 66 75 6c 6c 79 20 6e 6f 74 20 |g carefully not | 00000590 74 6f 20 73 74 72 65 73 73 20 74 68 65 20 6d 65 |to stress the me| 000005a0 74 61 6c 2e 0d 33 2e 53 6f 6c 64 65 72 20 61 20 |tal..3.Solder a | 000005b0 73 6d 61 6c 6c 20 77 69 72 65 20 74 6f 20 70 69 |small wire to pi| 000005c0 6e 20 31 20 61 6e 64 20 72 75 6e 20 74 68 69 73 |n 1 and run this| 000005d0 20 75 6e 64 65 72 20 74 68 65 20 63 68 69 70 20 | under the chip | 000005e0 61 6e 64 20 70 6c 75 67 20 69 74 0d 69 6e 74 6f |and plug it.into| 000005f0 20 70 69 6e 20 32 37 20 6f 66 20 74 68 65 20 73 | pin 27 of the s| 00000600 6f 63 6b 65 74 2e 54 68 69 73 20 62 65 63 6f 6d |ocket.This becom| 00000610 65 73 20 61 64 64 72 65 73 73 20 31 34 2e 0d 34 |es address 14..4| 00000620 2e 4e 6f 74 20 43 53 20 61 6e 64 20 4e 6f 74 20 |.Not CS and Not | 00000630 4f 45 20 61 72 65 20 68 61 6e 64 6c 65 64 20 62 |OE are handled b| 00000640 79 20 74 68 65 20 45 70 72 6f 6d 20 70 72 6f 67 |y the Eprom prog| 00000650 72 61 6d 6d 65 72 20 6f 72 20 6d 69 63 72 6f 70 |rammer or microp| 00000660 72 6f 63 65 73 73 6f 72 0d 73 6f 20 63 61 6e 20 |rocessor.so can | 00000670 62 65 20 6c 65 66 74 20 61 6c 69 6e 65 2e 0d 35 |be left aline..5| 00000680 2e 48 61 76 69 6e 67 20 62 65 6e 74 20 70 69 6e |.Having bent pin| 00000690 20 32 37 20 6f 75 74 20 6f 66 20 74 68 65 20 77 | 27 out of the w| 000006a0 61 79 20 6f 66 20 74 68 65 20 73 6d 61 6c 6c 20 |ay of the small | 000006b0 77 69 72 65 20 79 6f 75 20 6a 75 73 74 20 73 6f |wire you just so| 000006c0 6c 64 65 72 65 64 20 6f 6e 0d 61 74 74 61 63 68 |ldered on.attach| 000006d0 20 74 68 69 73 20 74 6f 20 74 68 65 20 63 65 6e | this to the cen| 000006e0 74 72 65 20 70 6f 6c 65 20 6f 66 20 74 68 65 20 |tre pole of the | 000006f0 73 77 69 74 63 68 2e 54 68 65 20 6f 74 68 65 72 |switch.The other| 00000700 20 74 77 20 6f 20 74 65 72 6d 69 6e 61 6c 73 20 | tw o terminals | 00000710 6f 66 0d 74 68 65 20 73 77 69 74 63 68 20 67 6f |of.the switch go| 00000720 20 74 6f 20 70 69 6e 20 31 34 20 28 47 4e 44 29 | to pin 14 (GND)| 00000730 20 61 6e 64 20 32 38 20 28 56 43 43 29 2e 0d 36 | and 28 (VCC)..6| 00000740 2e 50 69 6e 20 32 38 20 61 6c 73 6f 20 6d 75 73 |.Pin 28 also mus| 00000750 74 20 62 65 20 73 70 6c 69 74 2e 54 68 65 20 74 |t be split.The t| 00000760 77 6f 20 64 69 6f 64 65 73 20 70 72 65 76 65 6e |wo diodes preven| 00000770 74 20 74 68 65 20 6d 69 63 72 6f 70 72 6f 63 65 |t the microproce| 00000780 73 73 6f 72 27 73 0d 70 6f 77 65 72 20 73 75 70 |ssor's.power sup| 00000790 70 6c 79 20 66 72 6f 6d 20 74 72 79 69 6e 67 20 |ply from trying | 000007a0 74 6f 20 72 65 63 68 61 72 67 65 20 74 68 65 20 |to recharge the | 000007b0 62 61 74 74 65 72 69 65 73 2c 61 6e 64 20 76 69 |batteries,and vi| 000007c0 63 65 20 20 76 65 72 73 61 2e 0d 37 2e 54 68 65 |ce versa..7.The| 000007d0 20 62 61 74 74 65 72 79 20 63 6c 69 70 20 61 6e | battery clip an| 000007e0 64 20 73 77 69 74 63 68 20 73 68 6f 75 6c 64 20 |d switch should | 000007f0 62 65 20 77 69 72 65 20 65 6e 64 65 64 20 61 6e |be wire ended an| 00000800 64 20 69 6e 73 75 6c 61 74 65 64 20 74 6f 0d 70 |d insulated to.p| 00000810 72 65 76 65 6e 74 20 73 68 6f 72 74 73 20 69 6e |revent shorts in| 00000820 20 63 6f 6e 66 69 6e 65 64 20 73 70 61 63 65 73 | confined spaces| 00000830 20 61 6e 64 20 74 6f 20 61 6c 6c 6f 77 20 74 68 | and to allow th| 00000840 65 20 64 65 76 69 63 65 20 74 6f 20 66 69 74 0d |e device to fit.| 00000850 20 75 6e 64 65 72 20 74 68 65 20 6b 65 79 62 6f | under the keybo| 00000860 61 72 64 20 6f 6e 20 61 20 42 42 43 20 42 2e 0d |ard on a BBC B..| 00000870 0d 48 49 4e 54 53 2e 2e 2e 0d 2a 42 65 6c 6f 77 |.HINTS....*Below| 00000880 20 61 72 6f 75 6e 64 20 32 2e 35 76 20 74 68 65 | around 2.5v the| 00000890 20 63 6f 6e 74 65 6e 74 73 20 6f 66 20 53 52 41 | contents of SRA| 000008a0 4d 20 6d 61 79 20 62 65 63 6f 6d 65 20 63 6f 72 |M may become cor| 000008b0 72 75 70 74 65 64 20 6f 72 20 6c 6f 73 74 0d 2a |rupted or lost.*| 000008c0 49 20 66 6f 75 6e 64 20 74 68 69 73 20 76 65 72 |I found this ver| 000008d0 79 20 75 73 65 66 75 6c 20 74 6f 20 74 65 73 74 |y useful to test| 000008e0 20 6f 75 74 20 74 68 65 20 73 75 69 74 61 62 69 | out the suitabi| 000008f0 6c 69 74 79 20 6f 66 20 52 4f 4d 20 69 6d 61 67 |lity of ROM imag| 00000900 65 73 20 62 65 66 6f 72 65 0d 63 6f 6d 6d 69 74 |es before.commit| 00000910 74 69 6e 67 20 74 68 65 6d 20 74 6f 20 45 50 52 |ting them to EPR| 00000920 4f 4d 0d 2a 49 20 61 6c 73 6f 20 66 69 74 74 65 |OM.*I also fitte| 00000930 64 20 61 20 5a 49 46 20 73 6f 63 6b 65 74 20 74 |d a ZIF socket t| 00000940 6f 20 74 68 65 20 61 73 68 74 72 61 79 20 28 74 |o the ashtray (t| 00000950 68 65 20 70 75 6e 63 68 20 6f 75 74 20 73 65 63 |he punch out sec| 00000960 74 69 6f 6e 20 6f 6e 20 74 68 65 0d 6c 65 66 74 |tion on the.left| 00000970 20 6f 66 20 74 68 65 20 42 27 73 20 6b 65 79 62 | of the B's keyb| 00000980 6f 61 72 64 20 77 68 65 72 65 20 74 68 65 20 73 |oard where the s| 00000990 70 65 65 63 68 20 73 6f 63 6b 65 74 73 20 77 6f |peech sockets wo| 000009a0 75 6c 64 20 67 6f 29 0d 20 74 6f 20 73 61 76 65 |uld go). to save| 000009b0 20 68 61 76 69 6e 67 20 74 6f 20 6b 65 65 70 20 | having to keep | 000009c0 6c 65 76 65 72 69 6e 67 20 74 68 65 20 70 61 63 |levering the pac| 000009d0 6b 20 69 6e 20 61 6e 64 20 6f 75 74 0d 2a 49 66 |k in and out.*If| 000009e0 20 79 6f 75 20 64 6f 20 6d 61 6b 65 20 61 20 5a | you do make a Z| 000009f0 49 46 20 73 6f 63 6b 65 74 2c 74 68 65 72 65 20 |IF socket,there | 00000a00 6d 61 79 20 62 65 20 74 69 6d 69 6e 67 20 70 72 |may be timing pr| 00000a10 6f 62 6c 65 6d 73 20 77 69 74 68 20 70 69 67 67 |oblems with pigg| 00000a20 79 20 62 61 63 6b 0d 52 4f 4d 73 20 73 75 63 68 |y back.ROMs such| 00000a30 20 61 73 20 4d 65 67 61 20 33 2e 54 72 79 20 63 | as Mega 3.Try c| 00000a40 6f 6e 6e 65 63 74 69 6e 67 20 61 20 31 30 30 6e |onnecting a 100n| 00000a50 46 20 63 61 70 61 63 69 74 6f 72 20 66 72 6f 6d |F capacitor from| 00000a60 20 20 70 69 6e 20 32 38 20 74 6f 20 70 69 6e 0d | pin 28 to pin.| 00000a70 31 34 2e 0d 2a 54 68 65 20 61 75 74 6f 20 70 6f |14..*The auto po| 00000a80 77 65 72 20 73 77 69 74 63 68 69 6e 67 20 6f 6e |wer switching on| 00000a90 6c 79 20 77 6f 72 6b 73 20 69 66 20 74 68 65 72 |ly works if ther| 00000aa0 65 20 69 73 20 61 20 64 69 66 66 65 72 65 6e 63 |e is a differenc| 00000ab0 65 20 6f 66 20 61 72 6f 75 6e 64 0d 30 2e 36 76 |e of around.0.6v| 00000ac0 20 62 65 74 77 65 65 6e 20 74 68 65 20 6d 61 69 | between the mai| 00000ad0 6e 20 70 6f 77 65 72 20 73 75 70 70 6c 79 20 61 |n power supply a| 00000ae0 6e 64 20 74 68 65 20 62 61 74 74 65 72 79 20 70 |nd the battery p| 00000af0 61 63 6b 20 2d 20 68 65 20 6e 63 65 20 74 68 65 |ack - he nce the| 00000b00 20 75 73 65 0d 6f 66 20 34 2e 35 76 20 6f 66 20 | use.of 4.5v of | 00000b10 63 65 6c 6c 73 20 69 6e 20 74 68 65 20 62 61 74 |cells in the bat| 00000b20 74 65 72 79 0d 0d 46 52 4f 4d 2e 2e 2e 0d 52 6f |tery..FROM....Ro| 00000b30 62 65 72 74 20 53 70 72 6f 77 73 6f 6e 2e 0d 28 |bert Sprowson..(| 00000b40 30 31 36 32 35 29 20 34 33 31 30 36 37 2e 0d 48 |01625) 431067..H| 00000b50 61 70 70 79 20 73 6f 6c 64 65 72 69 6e 67 21 0d |appy soldering!.| 00000b60
