19 ADOUT - System audio output
This is the filtered output of the sum of all audio inputs to the
host computer. No significant load should be taken from this node.
20 AGND - Audio Ground
This is the zero volt return for ADOUT. It should be used instead
of the system zero volt connection to reduce audio noise.
21 ADIN - Cartridge audio output
In the Electron:
This is merely a connection from one cartridge to the other.
In the Master 128:
This is an output to the host computer audio circuitry. It 'sees'
an impedance of at least 1.0kOhms. Two cartridges with audio output
should not be inserted into the host computer at the same time.
22 0V - Zero volts
This is the system earth return for digital signals.
SIDE 'B'
1 +5V - Power supply
This is the system logic supply rail. No more than 150mA should be
drawn by a cartridge in a fully configured Master 128 computer, ie with
internal Second Processor fitted. No more than 10mA should be drawn by a
cartridge fitted to the Electron.
2 A10 - Address line 10 : Input with TTL levels
3 D3 - Data bus line 3 : Input/Output with TTL levels
4 A11 - Address line 11 : Input with TTL levels
5 A9 - Address line 9 : Input with TTL levels
6 D7 - Most significant data bus line : Input/Output with TTL levels
7 D6 - Data bus line 6 : Input/Output with TTL levels
8 D5 - Data bus line 5 : Input/Output with TTL levels
9 D4 - Data bus line 4 : Input/Output with TTL levels
10 nOE2 - Output Enable : Input with TTL levels
This line provides an additional active low output enable for ROMs
in the Electron. This corresponds to ROM position 13 and consequently
responds quickly to service calls. it is low during the active low
portion of PH12. It is not guaranteed to be high at other times.
LPSTB - Light pen strobe
A connection with a pull up to +5V is provided to the CRTC light pen
strobe and system interrupt structure. When an on-board link is removed,
this connection is merely a link from one cartridge to the other.
11 BA7 - Buffered address line 7 : Input with TTL levels
The buffered address lines hold addresses valid for 125ns after PH12
goes low. They are not buffered or held valid for an extended period in
the Electron.
12 BA6 - Buffered address line 6 : Input with TTL levels
13 BA5 - Buffered address line 5 : Input with TTL levels
14 BA4 - Buffered address line 4 : Input with TTL levels
15 BA3 - Buffered address line 3 : Input with TTL levels
16 BA2 - Buffered address line 2 : Input with TTL levels
17 BA1 - Buffered address line 1 : Input with TTL levels
18 BA0 - Buffered address line 0 : Input with TTL levels
19 D0 - Data bus line 0 : Input/Output with TTL levels
20 D2 - Data bus line 2 : Input/Output with TTL levels
21 D1 - Data bus line 1 : Input/Output with TTL levels
22 0V - Zero volts
This is the earth return for digital signals
Where two or more cartridges are fitted, any host computer links
affect ALL cartridges.
3.0 Memory Map
All accesses to the cartridges are performed at 2MHz. The memory map
within the area &FC00 to &FD00 differs between the Electron and the Master
128:
3.1 Master 128 Memory Map
At the time of writing the memory map within the areas INFC and INFD in
the Master 128 computer are as follows:
&FCFF Paging register for memory in the &8000 to &BFFF
region.
Paging logic has to be implemented in each cartridge as necessary.
&FC82
&FC81 Speech system
&FC80 to &FCFE Reserved for use by Acorn.
