3.1 Master 128 Memory Map
At the time of writing the memory map within the areas INFC and INFD in
the Master 128 computer are as follows:
&FCFF Paging register for memory in the &8000 to &BFFF
region.
Paging logic has to be implemented in each cartridge as necessary.
&FC82
&FC81 Speech system
&FC80 to &FCFE Reserved for use by Acorn.
3.2 Electron Memory Map
&FC18 to &FC1F Reserved for use by Acorn
&FC28 to &FC2F Reserved for Econet use
&FC30 to &FC3F Reserved for use by Acorn
&FC60 to &FC6F ACIA
&FC70 Analogue to digital converter
&FC71 Parallel printer port
&FC72 Status register
&FC73 ROM scrolling register
&FC78 to &FC7F Laser Disc
&FC80 to &FC8F Test Hardware
&FC90 to &FC9F Sound/Speech
&FCB0 to &FCBF VIA
&FCC0 to &FCCF Floppy Disc Controller
&FCE0 to &FCEF Tube
&FCFF Paged RAM register
1.0 Purpose of this application note
1 To describe the signals available on the expansion port at the rear of
the Electron microcomputer.
2 To define the specification which all expansion modules for the
Electron microcomputer must meet.
3 To describe Acorn Computers' philosophy for expansion of the Electron
microcomputer.
Note that both hardware and software must conform to the standards set out
in this note. Failure to do this will result in poor reliability, and
incompatibility with other expansion modules and the Electron itself.
Failure to comply with the power supply requirements may cause the thermal
fuse in the mains power adaptor to blow irretrievably.
1.1 Acorn Expansion Module Philosophy
The Electron is designed to take one or two expansion units fixed rigidly
to the main unit and to one another by screws which locate into recessed
brass bosses. More expansion units can be added with consequent loss of
rigidity.
Electrical connection is to the PCB edge connector at the back of the
Electron. Dimensions and specifications for the expansion connector are
given in section 2 and the Appendix.
2.0 Electron Expansion Connector
Pinout
To gain access to the Electron expansion connector, the plastic cover
which protects it must be removed. Any instructions supplied with an
expansion module must direct the user to remove this cover before
attempting to connect the module to the Electron, and to replace the cover
whenever the module is disconnected.
The Electron expansion connector is laid out as shown in Figure 1.
2.1 Signal Definitions
The function of each terminal on the Electron expansion connector is
described below.
18V AC (pins 1,2) These lines are connected directly to the output
AC RETURNS (pins 3,4) from the Electron mains power
adaptor. A total of 6W may be drawn from these
lines as long as no power is
taken from +5V (pins 9,10,49,50). For safety
reasons these lines must never
be used as an AC input to the Electron, see
Section 3.
-5V (pins 5,6) A -5V supply from the Electron. Up to 20mA
(total) may safely be drawn from this line by expansion modules.
0V (pins 7,8,47,48) Ground. Expansion modules with their own power
supply must have the 0V lines commoned with the Electron.
