This approach is necessary for compatibility with the Electron.
5 A8 - Address line 8 : Input with TTL levels
6 A13 - Address line 13 : Input with TTL levels
7 A12 - Address line 12 : Input with TTL levels
8 PH12 - CPU clock : Input with CMOS levels
This input is the host computer PH12out.
9 -5V - The negative supply voltage
No more than 20mA per cartridge should be drawn from this supply.
10 CSYNC/MADET
On the Electron:
This is a "no connect" on the Electron.
On the Master 128:
This pin has two functions dependant on the position of a link in
the host computer:-
E/nB: this is the default function. It allows hardware in
cartridges to "know" which into which type of computer it is plugged. It
is a direct connection to+0V in the Master 128 and a floating node in the
Electron.
CSYNC - Composite Synchronisation: Input with TTL levels
The system composite vertical and horizontal synchronisation is made
available. It is intended to be used in genlock applications.
11 RNW/READY
This has different functions on the Electron and the Master 128.
On the Electron:
READY - CPU wait state control : Open collector output
When driven low, this line will cause the CPU to extend its cycle
until READY is released. This will only work on Electrons with CMOS CPUs.
With NMOS CPUs it will only work on read cycles.
On the Master 128:
R/W - Data Direction Control : Input with TTL levels
This is the system data buffer direction control. If low, cartridges
are being written to; if high and selected they may drive the bus
during PH12.
12 nNMI - Non maskable interrupt : Open collector output
This signal is connected to the system NMI line. It is active low.
13 nIRQ - Interrupt request : Open collector output
This signal is connected to the system IRQ line. It is active low.
14 nINFC - Internal Page &FC : Memory active decode input : TTL active low
When bit IFJ is set in the Master 128 ACCCON register, all accesses
to the address range &FC00 to
&FCFF will cause this select to become active. The ACCCON access is
not applicable to the Electron.
15 nINFD - Internal page &FD : Memory active decode input : TTL active low
When bit IFJ is set in the Master 128 ACCCON register, all accesses
to the address range &FD00 to
&FDFF will cause this select to become active. The ACCCON access is
not applicable to the Electron.
16 ROMQA - Memory paging select : Input with TTL levels
This is the least significant bit of the ROM select latch located at
&FE30 in the Master 128 and at &FE05 in the Electron.
17 Clock
This connection has different uses in the Electron and Master 128:
In the Electron:
Clock is a 16MHz input with TTL levels.
In the Master 128:
Clock is a strap selectable function:
a) 16MHz input with TTL levels.
b) 8 MHz input with TTL levels.
The functions are selected by links on the host computer. The user
should ensure that the links are correct for a given application and
that proper termination is provided.
18 nROMSTB/nCRTCRST
This has different functions on the Electron and Master 128:
On the Electron:
nROMSTB is an active low input using TTL levels which selects the
location &FC73. This is intended to be used as a paging register.
On the Master 128:
nCRTCRST is an active low output signal meeting TTL levels of the
system CRTC reset input. It is provided for use in genlock
applications.
