4.0 Timing
Processor Clock:
The Electron clock changes speed depending on what is being accessed at
the time.
During accesses to the ROM the processor runs at 2MHz; PHI OUT is low for
250ns followed by high for 250ns (nominal).
During access to I/O and to RAM in modes 4-6 the processor runs at 1 MHz.
The transition from 2Mhz to 1MHz is accomplished by having PHI OUT low
time of 250ns followed by a high time of either 750 or 1250ns depending on
the phase of the 2MHz signal, see Figure 2. The reason for this is that
the processor will re-synchronise to the 1Mhz clock, making interfacing to
peripherals such as the 6522 possible. The 1MHz clock is not available
outside the ULA; it must be generated externally.
(Fig.2)
In modes 0-3 the processor is denied access to the RAM during the
displayed portion of the screen (40us out of 64us in 256 lines out of
312). If the processor requires access to the RAM during this time it is
forced to wait until the end of the 40us line display period. ROM access
during this time is allowed. The effect of all this is that the processor
clock may be stretched in the high state for a period of up to 40us.
4.1 Regeneration of PHI
The timing of signal supplied to the Electron expansion are 16MHz, PHI OUT
(the processor input clock), and 16M/13 (for baud rate generation).
Signals such as 1MHz and 2MHz are used inside the ULA but do not exist
outside. Since, for example, the 6522 needs a 1MHz clock in phase with
the processor clock, this must be generated externally, see Figure 3.
4.2 Interrupt Latency
The longest period for which interrupts (IRQs) are disabled determines the
frequency at which new interrupts can be serviced. When the Electron is
in modes 0-3 this period (known as interrupt latency) can be as long as
10ms worst case. This can cause problems for RS423, A/D conversion, etc.
In modes 4-6 the interrupt latency is 4ms worst case, so actions which
require fast access or high data rate must force the Electron into one of
these modes.
Use of an ACIA or UART with FIFO capability and/or a handshake will
increase data throughput.
5.0 Sideways ROMs
Decoding:
Decoding of sideways ROMs is carried out at location &FE05. Any expansion
module which uses sideways ROMs must include circuitry to intercept the
write to &FE05 and act appropriately. The ULA handles the keyboard (ROM
numbers 8 and 9) and BASIC (ROM numbers 10 and 11). These four ROM
numbers are decoded inside the Electron itself and are not available for
use by an expansion module. All other ROM calls must be decoded by the
expansion module at address &FE05.
Twelve sideways ROMs can be accommodated on the Electron expansion, and
four (ROM numbers 12 to 15) are accessible by a single write to &FE05.
D7 D6 D5 D4 D3 D2 D1 D0
Write at &FE05 0 0 0 0 1 1 R1 R0
Where R1 R0 selects which of the four ROMs is required. These four ROMs
are numbered 12 to 15.
Selection of a ROM number 12 to 13 will take the following form:
LDA# ROMnumber
STA &F4
STA &Fe05
The write to &F4 must be carried out before the write to &FE05 in case an
interrupt occurs. The write to &FE05 tells the ULA that a sideways ROM is
to be accessed and it passes control to the operating system. Hardware in
the expansion module must decode the write to &FE05 and select one of the
four ROMs.
Now that BASIC has been de-selected, a further write to &FE05 can be
decoded by the expansion module to select ROMs numbered from 0 to 7.
D7 D6 D5 D4 D3 D2 D1 D0
Write at &FE05 0 0 0 0 0 R2 R1 R0
where R2 R1 R0 select which of the eight ROMs is required. These eight
ROMs are numbered 0 to 7.
Once again, the write to &FE05 must be decoded by hardware in the
expansion module which selects one of the eight ROMs.
Selection of a ROM number 0 to 7 will take the following form:
LDA# &0C \to
STA &F4 \deselect
STA &FE05 \BASIC
LDA# ROMnumber
STA &F4
STA &FE05
On power-up, sideways ROMs are polled in the order 15 through to 0 to find
the first which is configured as a language ROM. Execution will then
commence in this ROM. As BASIC is ROM number 10/11, a ROM in an expansion
module which is required to power-up before BASIC must be numbered 12 to
15.
