   10REM AdvCAD - Main program
   20REM (C) Dominic Ford 1998
   30HIMEM=&4000:PROCinit:stop=FALSE:joy=(?&5210=1):mouse=(?&5211=1)
   40ONERRORIFERR=17THEN50ELSEMODE7:OSCLI"FX15,1":PRINT"Fatal Error":END
   50PROCdrawscr:REPEAT?!&5212=&EA:PROCcursor:PROCcompsel:IFFNfire THENPROCmenu
   60IFNOTmouse THEN90ELSEA%=64:X%=&80:Y%=0:CALL&FFF1:!&70=x:!&72=y:CALLwhatover
   70IF?&86=&A0 AND?&77<>0THENPROCmove:PROCdrawscr
   80IF?&86=&60 AND?&77=0THENPROCput:PROCdrawscr
   90UNTILstop:MODE7:OSCLI"FX15,1":END
  100DEFFNfire:IFINKEY(-74)THEN=1ELSEIFjoy THENA%=&80:X%=0:IF(USR(&FFF4)AND(512+256))<>0THEN=1
  110IFmouse THENA%=64:X%=&80:Y%=0:CALL&FFF1:IF?&86=&C0THEN=1
  120=0
  130DEFPROCinit
  140drawcomps=&5200:whatover=&5203:delete=&5206:getlink=&5209:pinbase=&520C:x=640:y=512:DIMmenu$(10),t%(15,1):!&47FC=0:?&4800=0:$&4801="  <Untitled>   ":st$="":READc%:DIMcnam$(c%+1):FORc=1TOc%:READcnam$(c)
  150cnam$(c)=cnam$(c)+STRING$(15-LEN(cnam$(c))," "):NEXT:cnam$(0)=STRING$(15," "):cnam$(c%+1)=STRING$(15," "):cp%=1:ENDPROC
  160DEFPROCdrawscr:CLS:PRINT" Advanced CAD V1.0 by Dominic Ford 1998"
  170GCOL0,1:MOVE0,992:DRAW1280,992:MOVE0,892:DRAW1280,892:MOVE0,884:DRAW1280,884
  180GCOL0,1:CALLdrawcomps:PROCdcu:VDU23,1,0;0;0;0;
  190PRINTTAB(0,1)cnam$(cp%-1):COLOUR129:COLOUR0:PRINTcnam$(cp%):COLOUR128:COLOUR1:PRINTcnam$(cp%+1);
  200T=TIME:REPEATUNTIL(TIME>T+25)OR(NOT(INKEY(-58)ORINKEY(-42)))
  210PRINTTAB(16,1)"Status: Ready       ":PRINTTAB(16,3);:FORr=0TO14:PRINTCHR$?(&4801+r);:NEXT
  220ENDPROC
  230DEFPROCcompsel
  240co%=cp%:IFINKEY(-58)ANDcp%<>1THENcp%=cp%-1
  250IFINKEY(-42)ANDcp%<>c%THENcp%=cp%+1
  260IFcp%<>co%THEN190
  270ENDPROC
  280DEFPROCput
  290IF?&4800=128THENVDU7:ENDPROC
  300?&4800=?&4800+1:c=&4800+16*?&4800:IFcp%=8THEN?(c+5)=FNpins
  310?c=cp%-1:!(c+1)=x+65536*y:FORr=c+8TOc+15:?r=32:NEXT:PROCdcu
  320REPEATUNTILNOTINKEY(-74)
  330ENDPROC
  340DEFFNpins
  350xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
  360n%=10:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
  370w%=3:menu$(0)="Pin":menu$(1)="  6":menu$(2)="  8":menu$(3)=" 14":menu$(4)=" 16":menu$(5)=" 18":menu$(6)=" 20":menu$(7)=" 24":menu$(8)=" 28":menu$(9)=" 32":menu$(10)=" 40":PROCdomenu
  380=?(!pinbase+mo%)
  390DEFPROCmenu
  400PROCdcu:!&70=x:!&72=y:CALLwhatover
  410n%=6:w%=6:IFx<1248-32*w%THENxm=(x AND &FFE0)ELSExm=1248-32*w%
  420IFy>32*(n%+2)THENym=(y AND &FFE0)ELSEym=32*(n%+2)
  430IF?&77=0THENPROCcadmenu:GOTO500
  440menu$(0)="Object":menu$(1)="File "+CHR$255:menu$(2)="Move  ":menu$(3)="Delete":menu$(4)="Label"+CHR$255:menu$(5)="Link "+CHR$255:menu$(6)="Cancel":PROCdomenu
  450IFmo%=0THENPROCfile:GOTO500
  460IFmo%=1THENPROCmove:GOTO500
  470IFmo%=2THENIFFNsure("Delete Object")THENCALLdelete:GOTO500
  480IFmo%=3THENPROClabel:GOTO500
  490IFmo%=4THENPROClink
  500PROCdrawscr
  510ENDPROC
  520DEFPROCcadmenu
  530n%=3:menu$(0)="AdvCAD":menu$(1)="File "+CHR$255:menu$(2)="Add   ":menu$(3)="Cancel":PROCdomenu
  540IFmo%=0THENPROCfile:GOTO560
  550IFmo%=1THENPROCput
  560ENDPROC
  570DEFPROCfile
  580xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
  590n%=9:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
  600menu$(0)=" File ":menu$(1)="New   ":menu$(2)="Open  ":menu$(3)="Save  ":menu$(4)="SaveAs":menu$(5)="Export":menu$(6)="Name "+CHR$255:menu$(7)="MOS(*)":menu$(8)="Exit  ":menu$(9)="Cancel":PROCdomenu
  610IFmo%=0THENIFFNsure("Clear Circuit")THEN!&47FC=0:?&4800=0:$&4801="  <Untitled>   ":st$="":ENDPROC
  620IFmo%=1THENPROCopen:ENDPROC
  630IFmo%=2THENPROCsave(0):ENDPROC
  640IFmo%=3THENPROCsave(1):ENDPROC
  650IFmo%=4THENPROCexport:ENDPROC
  660IFmo%=5THENPROCname:ENDPROC
  670IFmo%=6THENPROCmos:ENDPROC
  680IFmo%=7THENIFFNsure("Exit CAD")THENstop=TRUE:ENDPROC
  690ENDPROC
  700DEFPROCopen
  710w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
  720st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:OSCLI"LOAD "+st$
  730ENDPROC
  740DEFPROCsave(st)
  750IFst=1ORst$=""THENw%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox:st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT
  760min=&47FC-4*!&47FC:max=&4810+16*?&4800:OSCLI"SAVE "+st$+" "+STR$~min+" "+STR$~max
  770ENDPROC
  780DEFPROCexport
  790w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
  800st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:CLS:CALLdrawcomps:OSCLI"SAVE "+st$+" 5800 8000"
  810ENDPROC
  820DEFPROCdomenu
  830xc=xm DIV32:yc=32-(ym DIV32):FORr=0TOn%:PRINTTAB(xc,yc+r)menu$(r);:NEXT
  840GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4:MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
  850MOVExm-4,ym-32:DRAWxm+32*w%+4,ym-32
  860ad=&5800+&140*yc+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT:IFmouse THENA%=64:X%=&80:Y%=0:CALL&FFF1:B%=(!&82)AND&FFFF:C%=B%
  870GCOL3,1:mi%=0:REPEAT ad=&5940+&140*(yc+mi%)+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT:mo%=mi%
  880REPEATUNTILNOT(INKEY(-58)ORINKEY(-42)ORINKEY(-73)ORINKEY(-105))
  890IFjoy THENREPEATUNTILADVAL(2)<40000ANDADVAL(2)>24000
  900REPEAT IFINKEY(-58)ORINKEY(-73)OR(joy ANDADVAL(2)>40000)THENmi%=mi%-1
  910IFINKEY(-42)ORINKEY(-105)OR(joy ANDADVAL(2)<24000)THENmi%=mi%+1
  920IFFNfire THENmi%=-5
  930IFNOTmouse THEN960ELSEA%=64:X%=&80:Y%=0:CALL&FFF1:C%=(!&82)AND&FFFF
  940IFC%<(B%-31)THENmi%=mo%+1:B%=C%
  950IFC%>(B%+31)THENmi%=mo%-1:B%=C%
  960UNTILmi%<>mo%:IFmi%<>-5THENmi%=(mi%+n%)MODn%
  970IFmi%<>-5THENFORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT
  980UNTILmi%=-5
  990ENDPROC
 1000DEFFNsure(s$)
 1010FORr=0TO3:PRINTTAB(14,14+r)SPC(13):NEXT:PRINTTAB(20-INT(0.5*LEN(s$)),14)s$;TAB(14,16)"Are you sure?";TAB(14,17)"(Y)es or (N)o":FORr=&69F0TO&6A57:?r=?r EOR255:NEXT
 1020GCOL0,1:MOVE448,448:DRAW864,448:DRAW864,576:DRAW448,576:DRAW448,448:MOVE440,440:DRAW872,440:DRAW872,584:DRAW440,584:DRAW440,440
 1030r=-5:REPEAT IFINKEY(-69)THENr=TRUE
 1040IFINKEY(-86)THENr=FALSE
 1050UNTILr<>-5:=r
 1060DEFPROCmos
 1070CLS:PRINT"MOS Command Prompt"''"Enter blank line to return to CAD"':ONERRORREPORT:PRINT:GOTO1080
 1080OSCLI"FX15,1":REPEAT PRINT:INPUT"*"s$:OSCLIs$
 1090UNTILs$="":ONERRORIFERR=17THEN50ELSEMODE7:OSCLI"FX15,1":PRINT"Fatal Error":END
 1100*FX125
 1110DEFPROCname
 1120w%=15:n%=0:ym=ym-256:xm=768:FORrx=0TO15:t%(rx,0)=?(&4801+rx):NEXT:PROCtextbox
 1130FORrx=0TO15:?(&4801+rx)=t%(rx,0):NEXT
 1140ENDPROC
 1150DEFPROClabel
 1160xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
 1170n%=1:ym=ym-128:w%=4:FORrx=0TOw%-1:FORry=0TOn%:t%(rx,ry)=?(&4808+16*?&77+rx+4*ry):NEXT,:PROCtextbox
 1180FORrx=0TO3:FORry=0TO1:?(&4808+16*?&77+rx+4*ry)=t%(rx,ry):NEXT,
 1190ENDPROC
 1200DEFPROCtextbox
 1210xc=xm DIV32:yc=32-(ym DIV32):mx=0:my=0:GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4
 1220MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
 1230REPEAT FORry=0TOn%:PRINTTAB(xc,yc+ry);:FORrx=0TOw%-1:PRINTCHR$t%(rx,ry);:NEXT,:ad=&5800+8*(xc+mx)+&140*(yc+my):FORr=ad TOad+7:?r=?r EOR255:NEXT
 1240st=0:REPEATUNTILINKEY(0)=-1:REPEAT IFINKEY(-58)ANDmy<>0THENmy=my-1:st=1
 1250IFINKEY(-42)ANDmy<>n%THENmy=my+1:st=1
 1260IFINKEY(-26)ANDmx<>0THENmx=mx-1:st=1
 1270IFINKEY(-122)ANDmx<>(w%-1)THENmx=mx+1:st=1
 1280IFINKEY(-74)THENst=2
 1290IFst=0THENr=INKEY(0):IFr>31ANDr<127THENt%(mx,my)=r:st=1:IFmx<>(w%-1)THENmx=mx+1
 1300UNTILst<>0:UNTILst=2
 1310ENDPROC
 1320DEFPROClink
 1330co1%=?&77:xm=xm+32*(w%+1):ym=ym-160:PROCprelinks:IFmo%=n%-1THENENDPROC
 1340cp1%=mo%:PROCdrawscr:PRINTTAB(16,1)"Status: Linking     ":REPEATUNTILNOTFNfire
 1350REPEAT PROCcursor:UNTILFNfire:CALLwhatover:IF?&77=0THENVDU7:REPEATUNTILNOTFNfire:GOTO1350
 1360co2%=?&77:xm=(x AND &FFE0):ym=(y AND &FFE0):PROCprelinks
 1370IFmo%=n%-1THENENDPROC
 1380!&47FC=!&47FC+1:ad=&47FC-4*!&47FC:?ad=co1%:?(ad+1)=cp1%:?(ad+2)=co2%:?(ad+3)=mo%
 1390ENDPROC
 1400DEFPROCprelinks
 1410?&70=?(&4800+16*?&77):CALLgetlink:n%=-1:w%=7:IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
 1420IF?&73=10AND?&72=160THENPROCleads:GOTO1460
 1430ad=?&72+256*?&73:REPEAT n%=n%+1:menu$(n%)="":FORr=ad TOad+6:menu$(n%)=menu$(n%)+CHR$?r:NEXT:ad=ad+8:UNTIL?(ad-1)=0:n%=n%+1:menu$(n%)="Cancel "
 1440IFym<(n%+2)*32THENym=(n%+2)*32
 1450PROCdomenu
 1460ENDPROC
 1470DEFPROCleads
 1480ml%=?(&4805+16*?&77)*2:n%=(ml%DIV5)+2:menu$(0)="Lead No":menu$(1)="1 - 4  ":FORr=2TOn%-1
 1490IF(5*(r-1))=ml%THENmenu$(r)=STR$(5*(r-1)):GOTO1510
 1500IF(5*(r-1)+4)>=ml%THENmenu$(r)=STR$(5*(r-1))+" - "+STR$(ml%)ELSEmenu$(r)=STR$(5*(r-1))+" - "+STR$(5*r-1)
 1510IFLEN(menu$(r))<7THENmenu$(r)=menu$(r)+STRING$(7-LEN(menu$(r))," ")
 1520NEXT:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
 1530PROCdomenu:IFmo%=n%-1THENENDPROC
 1540IF(mo%=n%-1)AND(ml%MOD5)=0THENmo%=ml%-1:n%=999:ENDPROC
 1550min=VAL(menu$(mo%+1)):max=VAL(MID$(menu$(mo%+1),5,3)):FORr=min TOmax:menu$(1+r-min)=STRING$(7-LEN(STR$r)," ")+STR$r:NEXT:n%=max-min+2:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
 1560xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-96*(w%+1)
 1570PROCdomenu:IFmo%=n%-1THENENDPROC
 1580mo%=mo%+min:n%=999:ENDPROC
 1590DEFPROCmove
 1600PROCdrawscr:PROCdcu:PRINTTAB(16,1)"Status: Moving      ":REPEATUNTILNOTFNfire
 1610?!&5212=&60:!&70=x:!&72=y:CALLwhatover:ad=&4801+16*?&77:x=?ad+256*?(ad+1):y=?(ad+2)+256*?(ad+3):!&70=x:!&72=y:CALL&5006
 1620REPEAT CALL&5009:x=(!&70)AND&FFFF:y=!&72:UNTILFNfire:!ad=x+65536*y:ENDPROC
 1630DEFPROCcursor:GCOL3,1:!&70=x:!&72=y:CALL&5000:x=(!&70)AND&FFFF:y=!&72:ENDPROC
 1640DEFPROCdcu:GCOL3,1:!&74=x:!&76=y:CALL&5003:ENDPROC
 1650DATA20,"Capacitor","Capacitor(E)","Cell","Battery","Diode","Diode(Zener)","Ground","IC","Inductor","Logic AND","Logic NOT","Logic OR","Node","OpAmp","Resistor","Resistor(Var)"
 1660DATA"Switch","Transistor(NPN)","Transistor(PNP)","Transistor(FET)"
