This website contains an archive of files for the Acorn Electron, BBC Micro, Acorn Archimedes, Commodore 16 and Commodore 64 computers, which Dominic Ford has rescued from his private collection of floppy disks and cassettes.

Some of these files were originally commercial releases in the 1980s and 1990s, but they are now widely available online. I assume that copyright over them is no longer being asserted. If you own the copyright and would like files to be removed, please contact me.

Tape/disk:	Home » Personal collection » Acorn ADFS disks » Greaseweazled » dfs_box04_disk02b_eug_scripts.adf
Filename:	CAD/CADNew/CAD2
Read OK:	✔
File size:	1D31 bytes
Load address:	FFFF0E00
Exec address:	FFFF802B

Duplicates

There are 2 duplicate copies of this file in the archive:

Personal collection » Acorn ADFS disks » Electron_User_Group » EUG_41.ADF » P/CAD2
Personal collection » Acorn ADFS disks » Greaseweazled » dfs_box04_disk02b_eug_scripts.adf » CAD/CADNew/CAD2
Personal collection » Acorn hard disk » zipped_disks » elk06 » eug41/P/CAD2

File contents

   10REM AdvCAD - Main program
   20REM (C) Dominic Ford 1998
   30HIMEM=&4000:PROCinit:stop=FALSE:joy=(?&5210=1):mouse=(?&5211=1)
   40ONERRORIFERR=17THEN50ELSEMODE7:OSCLI"FX15,1":PRINT"Fatal Error":END
   50PROCdrawscr:REPEAT?!&5212=&EA:PROCcursor:PROCcompsel:IFFNfire THENPROCmenu
   60IFNOTmouse THEN90ELSEA%=64:X%=&80:Y%=0:CALL&FFF1:!&70=x:!&72=y:CALLwhatover
   70IF?&86=&A0 AND?&77<>0THENPROCmove:PROCdrawscr
   80IF?&86=&60 AND?&77=0THENPROCput:PROCdrawscr
   90UNTILstop:MODE7:OSCLI"FX15,1":END
  100DEFFNfire:IFINKEY(-74)THEN=1ELSEIFjoy THENA%=&80:X%=0:IF(USR(&FFF4)AND(512+256))<>0THEN=1
  110IFmouse THENA%=64:X%=&80:Y%=0:CALL&FFF1:IF?&86=&C0THEN=1
  120=0
  130DEFPROCinit
  140drawcomps=&5200:whatover=&5203:delete=&5206:getlink=&5209:pinbase=&520C:x=640:y=512:DIMmenu$(10),t%(15,1):!&47FC=0:?&4800=0:$&4801="  <Untitled>   ":st$="":READc%:DIMcnam$(c%+1):FORc=1TOc%:READcnam$(c)
  150cnam$(c)=cnam$(c)+STRING$(15-LEN(cnam$(c))," "):NEXT:cnam$(0)=STRING$(15," "):cnam$(c%+1)=STRING$(15," "):cp%=1:ENDPROC
  160DEFPROCdrawscr:CLS:PRINT" Advanced CAD V1.0 by Dominic Ford 1998"
  170GCOL0,1:MOVE0,992:DRAW1280,992:MOVE0,892:DRAW1280,892:MOVE0,884:DRAW1280,884
  180GCOL0,1:CALLdrawcomps:PROCdcu:VDU23,1,0;0;0;0;
  190PRINTTAB(0,1)cnam$(cp%-1):COLOUR129:COLOUR0:PRINTcnam$(cp%):COLOUR128:COLOUR1:PRINTcnam$(cp%+1);
  200T=TIME:REPEATUNTIL(TIME>T+25)OR(NOT(INKEY(-58)ORINKEY(-42)))
  210PRINTTAB(16,1)"Status: Ready       ":PRINTTAB(16,3);:FORr=0TO14:PRINTCHR$?(&4801+r);:NEXT
  220ENDPROC
  230DEFPROCcompsel
  240co%=cp%:IFINKEY(-58)ANDcp%<>1THENcp%=cp%-1
  250IFINKEY(-42)ANDcp%<>c%THENcp%=cp%+1
  260IFcp%<>co%THEN190
  270ENDPROC
  280DEFPROCput
  290IF?&4800=128THENVDU7:ENDPROC
  300?&4800=?&4800+1:c=&4800+16*?&4800:IFcp%=8THEN?(c+5)=FNpins
  310?c=cp%-1:!(c+1)=x+65536*y:FORr=c+8TOc+15:?r=32:NEXT:PROCdcu
  320REPEATUNTILNOTINKEY(-74)
  330ENDPROC
  340DEFFNpins
  350xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
  360n%=10:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
  370w%=3:menu$(0)="Pin":menu$(1)="  6":menu$(2)="  8":menu$(3)=" 14":menu$(4)=" 16":menu$(5)=" 18":menu$(6)=" 20":menu$(7)=" 24":menu$(8)=" 28":menu$(9)=" 32":menu$(10)=" 40":PROCdomenu
  380=?(!pinbase+mo%)
  390DEFPROCmenu
  400PROCdcu:!&70=x:!&72=y:CALLwhatover
  410n%=6:w%=6:IFx<1248-32*w%THENxm=(x AND &FFE0)ELSExm=1248-32*w%
  420IFy>32*(n%+2)THENym=(y AND &FFE0)ELSEym=32*(n%+2)
  430IF?&77=0THENPROCcadmenu:GOTO500
  440menu$(0)="Object":menu$(1)="File "+CHR$255:menu$(2)="Move  ":menu$(3)="Delete":menu$(4)="Label"+CHR$255:menu$(5)="Link "+CHR$255:menu$(6)="Cancel":PROCdomenu
  450IFmo%=0THENPROCfile:GOTO500
  460IFmo%=1THENPROCmove:GOTO500
  470IFmo%=2THENIFFNsure("Delete Object")THENCALLdelete:GOTO500
  480IFmo%=3THENPROClabel:GOTO500
  490IFmo%=4THENPROClink
  500PROCdrawscr
  510ENDPROC
  520DEFPROCcadmenu
  530n%=3:menu$(0)="AdvCAD":menu$(1)="File "+CHR$255:menu$(2)="Add   ":menu$(3)="Cancel":PROCdomenu
  540IFmo%=0THENPROCfile:GOTO560
  550IFmo%=1THENPROCput
  560ENDPROC
  570DEFPROCfile
  580xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
  590n%=9:IFym>(n%+3)*32THENym=ym-32ELSEym=(n%+2)*32
  600menu$(0)=" File ":menu$(1)="New   ":menu$(2)="Open  ":menu$(3)="Save  ":menu$(4)="SaveAs":menu$(5)="Export":menu$(6)="Name "+CHR$255:menu$(7)="MOS(*)":menu$(8)="Exit  ":menu$(9)="Cancel":PROCdomenu
  610IFmo%=0THENIFFNsure("Clear Circuit")THEN!&47FC=0:?&4800=0:$&4801="  <Untitled>   ":st$="":ENDPROC
  620IFmo%=1THENPROCopen:ENDPROC
  630IFmo%=2THENPROCsave(0):ENDPROC
  640IFmo%=3THENPROCsave(1):ENDPROC
  650IFmo%=4THENPROCexport:ENDPROC
  660IFmo%=5THENPROCname:ENDPROC
  670IFmo%=6THENPROCmos:ENDPROC
  680IFmo%=7THENIFFNsure("Exit CAD")THENstop=TRUE:ENDPROC
  690ENDPROC
  700DEFPROCopen
  710w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
  720st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:OSCLI"LOAD "+st$
  730ENDPROC
  740DEFPROCsave(st)
  750IFst=1ORst$=""THENw%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox:st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT
  760min=&47FC-4*!&47FC:max=&4810+16*?&4800:OSCLI"SAVE "+st$+" "+STR$~min+" "+STR$~max
  770ENDPROC
  780DEFPROCexport
  790w%=7:n%=0:ym=ym-64:xm=768:FORrx=0TO6:t%(rx,0)=32:NEXT:PROCtextbox
  800st$="":FORrx=0TO6:st$=st$+CHR$t%(rx,0):NEXT:CLS:CALLdrawcomps:OSCLI"SAVE "+st$+" 5800 8000"
  810ENDPROC
  820DEFPROCdomenu
  830xc=xm DIV32:yc=32-(ym DIV32):FORr=0TOn%:PRINTTAB(xc,yc+r)menu$(r);:NEXT
  840GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4:MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
  850MOVExm-4,ym-32:DRAWxm+32*w%+4,ym-32
  860ad=&5800+&140*yc+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT:IFmouse THENA%=64:X%=&80:Y%=0:CALL&FFF1:B%=(!&82)AND&FFFF:C%=B%
  870GCOL3,1:mi%=0:REPEAT ad=&5940+&140*(yc+mi%)+8*xc:FORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT:mo%=mi%
  880REPEATUNTILNOT(INKEY(-58)ORINKEY(-42)ORINKEY(-73)ORINKEY(-105))
  890IFjoy THENREPEATUNTILADVAL(2)<40000ANDADVAL(2)>24000
  900REPEAT IFINKEY(-58)ORINKEY(-73)OR(joy ANDADVAL(2)>40000)THENmi%=mi%-1
  910IFINKEY(-42)ORINKEY(-105)OR(joy ANDADVAL(2)<24000)THENmi%=mi%+1
  920IFFNfire THENmi%=-5
  930IFNOTmouse THEN960ELSEA%=64:X%=&80:Y%=0:CALL&FFF1:C%=(!&82)AND&FFFF
  940IFC%<(B%-31)THENmi%=mo%+1:B%=C%
  950IFC%>(B%+31)THENmi%=mo%-1:B%=C%
  960UNTILmi%<>mo%:IFmi%<>-5THENmi%=(mi%+n%)MODn%
  970IFmi%<>-5THENFORr=ad TOad+8*w%-1:?r=?r EOR255:NEXT
  980UNTILmi%=-5
  990ENDPROC
 1000DEFFNsure(s$)
 1010FORr=0TO3:PRINTTAB(14,14+r)SPC(13):NEXT:PRINTTAB(20-INT(0.5*LEN(s$)),14)s$;TAB(14,16)"Are you sure?";TAB(14,17)"(Y)es or (N)o":FORr=&69F0TO&6A57:?r=?r EOR255:NEXT
 1020GCOL0,1:MOVE448,448:DRAW864,448:DRAW864,576:DRAW448,576:DRAW448,448:MOVE440,440:DRAW872,440:DRAW872,584:DRAW440,584:DRAW440,440
 1030r=-5:REPEAT IFINKEY(-69)THENr=TRUE
 1040IFINKEY(-86)THENr=FALSE
 1050UNTILr<>-5:=r
 1060DEFPROCmos
 1070CLS:PRINT"MOS Command Prompt"''"Enter blank line to return to CAD"':ONERRORREPORT:PRINT:GOTO1080
 1080OSCLI"FX15,1":REPEAT PRINT:INPUT"*"s$:OSCLIs$
 1090UNTILs$="":ONERRORIFERR=17THEN50ELSEMODE7:OSCLI"FX15,1":PRINT"Fatal Error":END
 1100*FX125
 1110DEFPROCname
 1120w%=15:n%=0:ym=ym-256:xm=768:FORrx=0TO15:t%(rx,0)=?(&4801+rx):NEXT:PROCtextbox
 1130FORrx=0TO15:?(&4801+rx)=t%(rx,0):NEXT
 1140ENDPROC
 1150DEFPROClabel
 1160xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
 1170n%=1:ym=ym-128:w%=4:FORrx=0TOw%-1:FORry=0TOn%:t%(rx,ry)=?(&4808+16*?&77+rx+4*ry):NEXT,:PROCtextbox
 1180FORrx=0TO3:FORry=0TO1:?(&4808+16*?&77+rx+4*ry)=t%(rx,ry):NEXT,
 1190ENDPROC
 1200DEFPROCtextbox
 1210xc=xm DIV32:yc=32-(ym DIV32):mx=0:my=0:GCOL0,1:MOVExm-4,ym+4:DRAWxm+32*w%+4,ym+4:DRAWxm+32*w%+4,ym-32*n%-36:DRAWxm-4,ym-32*n%-36:DRAWxm-4,ym+4
 1220MOVExm-12,ym+12:DRAWxm+32*w%+12,ym+12:DRAWxm+32*w%+12,ym-32*n%-44:DRAWxm-12,ym-32*n%-44:DRAWxm-12,ym+12
 1230REPEAT FORry=0TOn%:PRINTTAB(xc,yc+ry);:FORrx=0TOw%-1:PRINTCHR$t%(rx,ry);:NEXT,:ad=&5800+8*(xc+mx)+&140*(yc+my):FORr=ad TOad+7:?r=?r EOR255:NEXT
 1240st=0:REPEATUNTILINKEY(0)=-1:REPEAT IFINKEY(-58)ANDmy<>0THENmy=my-1:st=1
 1250IFINKEY(-42)ANDmy<>n%THENmy=my+1:st=1
 1260IFINKEY(-26)ANDmx<>0THENmx=mx-1:st=1
 1270IFINKEY(-122)ANDmx<>(w%-1)THENmx=mx+1:st=1
 1280IFINKEY(-74)THENst=2
 1290IFst=0THENr=INKEY(0):IFr>31ANDr<127THENt%(mx,my)=r:st=1:IFmx<>(w%-1)THENmx=mx+1
 1300UNTILst<>0:UNTILst=2
 1310ENDPROC
 1320DEFPROClink
 1330co1%=?&77:xm=xm+32*(w%+1):ym=ym-160:PROCprelinks:IFmo%=n%-1THENENDPROC
 1340cp1%=mo%:PROCdrawscr:PRINTTAB(16,1)"Status: Linking     ":REPEATUNTILNOTFNfire
 1350REPEAT PROCcursor:UNTILFNfire:CALLwhatover:IF?&77=0THENVDU7:REPEATUNTILNOTFNfire:GOTO1350
 1360co2%=?&77:xm=(x AND &FFE0):ym=(y AND &FFE0):PROCprelinks
 1370IFmo%=n%-1THENENDPROC
 1380!&47FC=!&47FC+1:ad=&47FC-4*!&47FC:?ad=co1%:?(ad+1)=cp1%:?(ad+2)=co2%:?(ad+3)=mo%
 1390ENDPROC
 1400DEFPROCprelinks
 1410?&70=?(&4800+16*?&77):CALLgetlink:n%=-1:w%=7:IFxm>(1248-32*w%)THENxm=xm-64*(w%+1)
 1420IF?&73=10AND?&72=160THENPROCleads:GOTO1460
 1430ad=?&72+256*?&73:REPEAT n%=n%+1:menu$(n%)="":FORr=ad TOad+6:menu$(n%)=menu$(n%)+CHR$?r:NEXT:ad=ad+8:UNTIL?(ad-1)=0:n%=n%+1:menu$(n%)="Cancel "
 1440IFym<(n%+2)*32THENym=(n%+2)*32
 1450PROCdomenu
 1460ENDPROC
 1470DEFPROCleads
 1480ml%=?(&4805+16*?&77)*2:n%=(ml%DIV5)+2:menu$(0)="Lead No":menu$(1)="1 - 4  ":FORr=2TOn%-1
 1490IF(5*(r-1))=ml%THENmenu$(r)=STR$(5*(r-1)):GOTO1510
 1500IF(5*(r-1)+4)>=ml%THENmenu$(r)=STR$(5*(r-1))+" - "+STR$(ml%)ELSEmenu$(r)=STR$(5*(r-1))+" - "+STR$(5*r-1)
 1510IFLEN(menu$(r))<7THENmenu$(r)=menu$(r)+STRING$(7-LEN(menu$(r))," ")
 1520NEXT:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
 1530PROCdomenu:IFmo%=n%-1THENENDPROC
 1540IF(mo%=n%-1)AND(ml%MOD5)=0THENmo%=ml%-1:n%=999:ENDPROC
 1550min=VAL(menu$(mo%+1)):max=VAL(MID$(menu$(mo%+1),5,3)):FORr=min TOmax:menu$(1+r-min)=STRING$(7-LEN(STR$r)," ")+STR$r:NEXT:n%=max-min+2:menu$(n%)="Cancel ":IFym<(n%+2)*32THENym=(n%+2)*32
 1560xm=xm+32*(w%+1):IFxm>(1248-32*w%)THENxm=xm-96*(w%+1)
 1570PROCdomenu:IFmo%=n%-1THENENDPROC
 1580mo%=mo%+min:n%=999:ENDPROC
 1590DEFPROCmove
 1600PROCdrawscr:PROCdcu:PRINTTAB(16,1)"Status: Moving      ":REPEATUNTILNOTFNfire
 1610?!&5212=&60:!&70=x:!&72=y:CALLwhatover:ad=&4801+16*?&77:x=?ad+256*?(ad+1):y=?(ad+2)+256*?(ad+3):!&70=x:!&72=y:CALL&5006
 1620REPEAT CALL&5009:x=(!&70)AND&FFFF:y=!&72:UNTILFNfire:!ad=x+65536*y:ENDPROC
 1630DEFPROCcursor:GCOL3,1:!&70=x:!&72=y:CALL&5000:x=(!&70)AND&FFFF:y=!&72:ENDPROC
 1640DEFPROCdcu:GCOL3,1:!&74=x:!&76=y:CALL&5003:ENDPROC
 1650DATA20,"Capacitor","Capacitor(E)","Cell","Battery","Diode","Diode(Zener)","Ground","IC","Inductor","Logic AND","Logic NOT","Logic OR","Node","OpAmp","Resistor","Resistor(Var)"
 1660DATA"Switch","Transistor(NPN)","Transistor(PNP)","Transistor(FET)"
