10 nOE2 - Output Enable : Input with TTL levels
This line provides an additional active low output enable for ROMs
in the Electron. This corresponds to ROM position 13 and
consequently responds quickly to service calls. It is low during the
active low portion of PH12.
It is not guaranteed to be high at other times.
LPSTB - Light pen strobe
A connection with a pull up to +5V is provided to the CRTC light pen
strobe and system interrupt structure. When an on-board link is
removed, this connection is merely a link from one cartridge to the
other.
11 BA7 - Buffered address line 7 : Input with TTL levels
The buffered address lines hold addresses valid for 125ns after
PH12 goes low. They are not buffered or held valid for an
extended period in the Electron.
12 BA6 - Buffered address line 6 : Input with TTL levels
13 BA5 - Buffered address line 5 : Input with TTL levels
14 BA4 - Buffered address line 4 : Input with TTL levels
15 BA3 - Buffered address line 3 : Input with TTL levels
16 BA2 - Buffered address line 2 : Input with TTL levels
17 BA1 - Buffered address line 1 : Input with TTL levels
18 BA0 - Buffered address line 0 : Input with TTL levels
19 D0 - Data bus line 0 : Input/Output with TTL levels
20 D2 - Data bus line 2 : Input/Output with TTL levels
21 D1 - Data bus line 1 : Input/Output with TTL levels
22 0V - Zero volts
This is the earth return for digital signals
Where two or more cartridges are fitted, any host computer links affect
ALL cartridges.
3.0 Memory Map
All accesses to the cartridges are performed at 2MHz. The memory map
within the area &FC00 to &FD00 differs between the Electron an d the
Master 128:
3.1 Master 128 Memory Map
At the time of writing the memory map within the areas INFC and INFD in
the Master 128 computer are as follows:
&FCFF Paging register for memory in the &8000 to &BFFF
region.Paging logic has to be implemented in each
cartridge as necessary.
&FC82
&FC81 Speech system
&FC80 to &FCFE Reserved for use by Acorn.
3.2 Electron Memory Map
&FC18 to &FC1F Reserved for use by Acorn
&FC28 to &FC2F Reserved for Econet use
&FC30 to &FC3F Reserved for use by Acorn
&FC60 to &FC6F ACIA
&FC70 Analogue to digital converter
&FC71 Parallel printer port
&FC72 Status register
&FC73 ROM scrolling register
&FC78 to &FC7F Laser Disc
&FC80 to &FC8F Test Hardware
&FC90 to &FC9F Sound/Speech
&FCB0 to &FCBF VIA
&FCC0 to &FCCF Floppy Disc Controller
&FCE0 to &FCEF Tube
&FCFF Paged RAM register
